6. Internal waves Consider a continuously stratified fluid with ρo(z) the vertical density profile. z ρ p' ξ p ρο(z) Figure by MIT OpenCourseWare. Figure 1. At a point P raise a parcel of water by small amount ξ from its equilibrium position P adiabatically. The change in pressure experienced by the parcel is dp = -ρo gξ dp if ρo(z) is the medium density, while the change in density is dρ = 2 [Remember the cs ⎛ ∂p ⎞ definition of adiabatic compressibility ⎜ ⎟ = c2s]. The buoyancy force acting on the ⎝ ∂ρ ⎠ particle induces an acceleration because the density of the particle at the displaced position is different from the background density of the medium ρ o | P'= ρ o | P + dρ o ξ and dz ρ |particle at P' = ρ |particle at P+dρ ρ = o −ρ ogξ cs2 1 d2ξ ρ gξ = g[(ρ o + ρ oz ξ) − (ρ o − o2 )] dt cs ρo 2 d2ξ dt 2 = g ρ g [(ρ oz + o2 )ξ] ρo cs d2ξ gρ oz g 2 + (− − 2 )ξ = 0 ρo dt 2 cs Define N 2 (z) = d 2ξ dt 2 2 −g dρ o g 2 the Brünt-Vaisala frequency or buoyancy frequency − ρ o dz cs2 + N 2ξ = 0 is the equation of the harmonic oscillator with solution e±iNt. Thus the parcel oscillates about its equilibrium position and the Brünt-Vaisala frequency is the natural frequency of oscillation determined by the local density stratification and the fluid’s compressibility. As we saw, in the ocean compressibility effects are negligible and we can assume N2 = −g ∂ρ o ρ o ∂z The motion is the oscillation of the particle around the equilibrium position with frequency N. Let us compare the frequency of surface gravity waves with the buoyancy frequency and use deep water gravity waves Δρ N 1 ∂ρ o 1 / 2 1 ∂ρ o 1 / 2 ω int . ) ~ (− λ) ≈ o( o )1 / 2 = = (− ωsurf. ρo kρ o ∂z ρ o ∂z gk k~ 1 ∂ρ ; λ o = Δρ o ∂z λ density change over λ 2 Δρ o ~10−3 over total depth: ωint << ωsurface . The frequency of internal waves is much less than the frequency of surface gravity waves. The restoring force for surface gravity waves is g; the restoring force for internal waves is Δρ o g, reduced gravity. ρo Internal waves in an unbounded fluid Consider an incompressible, stratified non-rotating fluid characterized by a basic state of rest and hydrostatic equilibrium: u ≡ o, ρ = ρ o (z), p = p o (z) and dp o = −gρ o dz The fluid experiences small amplitude perturbations around the basic state, so we can use the linearized equations of motion, assuming also that the motion is frictionless and adiabatic: (1) ρ o ∂u ∂p =− ∂t ∂x ρtotal = ρo+ρ; ρ<<ρo (2) ρ o ∂v ∂p =− ∂y ∂t ptotal = po+ρ; p< valid also in the atmosphere. So we can ignore the first term and we simplify to: ⎛ ∂2 ∂2 ∂2 ⎤ ∂2 ⎞ ∂2 ⎡ ∂2 ⎟⎟w = 0 ⎢ ⎥w + N 2 ⎜⎜ + + + 2 ∂t 2 ⎣⎢∂x 2 ∂y 2 ∂z 2 ⎦⎥ ∂y 2 ⎠ ⎝ ∂x total Laplacian horizontal Laplacian ∂2 ∂t 2 ∇ 2w + N 2∇ 2Hw = 0 internal wave equation. Notice that if N = 0, no stratification, ∇ 2ω = 0 the motion is irrotational -> surface gravity waves. Consider now a plane wave solution in three-dimensions w = wocos(kx+ly+mz-ωt) (k,l,m) wave number Substituting into the internal wave equation, we obtain the dispersion relationship ω2 = N 2 (k 2 + l2 ) (k 2 + l2 + m2 ) 5 or ω 2 = N 2k 2H K2 k ω = ±N H K (m,z) K m q (l,y) j (k,x) KH Figure 2. Figure by MIT OpenCourseWare. ω = ±N cos θ And the wave numbers are k = K cosθcoφ, l = K cosθsin φ; m = K sinθ The dispersion relation for internal waves is of a quite different character from the dispersion relation for surface waves: ω of surface waves depends only on the magnitude of K and not on its direction ω of internal waves is independent of the magnitude of K and depends only on the orientation of the wave vector, i.e. on the angle θ of the wavenumber K with the horizontal. 6 Consider the displacement ζ along a line of constant phase by definition perpendicular to the phase line z K θ x θ Fz dz θ θ Figure by MIT OpenCourseWare. Figure 3. Thus particle motion is along the wave crests i.e., along the lines of constant phase d2ζ dt 2 + N 2ζ = 0 We can see this also considering (u,v,w) = (u o ,v o ,w o )e i(kx + ly+ mz−ωt) Continuity equation gives kuo+lvo+mwo = 0 => K • u = 0 Fluid velocity is perpendicular to the wave vector, i.e. is along the crests of the waves => wave motion is transverse 7 K u q3 u high u q2 low q1 high Figure 4. phase propagation Figure by MIT OpenCourseWare. When the wave vector is horizontal, m = o, the particle motion is purely vertical and ωmax = N A displacement ζ along the phase line gives a vertical displacement dz = ζcosθ The buoyancy force in the vertical corresponding to the displacement dz is Fz = -N2dz = -N2ζcosθ The component of this force along the phase line is Fζ = -N2ζcos2θ and the motion of the particle along the phase line is governed by: d2ζ dt 2 = Fζ → d2ζ dt 2 + (N 2 cos 2 θ)ζ = 0 Thus ±Ncosθ is the frequency of oscillation of a particle along the phase line. If θ = 0, we have vertical oscillations with frequency N. 8 Dispersion effects For internal waves, the surfaces of constant frequency in wavenumber space are the cones θ = constant, i.e. ω = constant The phase velocity | c |= on the cone. ω N = cosθ is directed along the wave vector and therefore lies K K The group velocity c g = i ∂ω ˆ ∂ω ˆ ∂ω is the gradient of ω in +j +k ∂k ∂l ∂m wavenumber space and therefore by definition is perpendicular to the surfaces ω = constant. It follows that c g is at right angles with (K,c) . When the group velocity has an upward component the phase speed has a downward component. Let us explicitly evaluate the group velocity k 2 + l2 N 2k 2H Write ω 2 = N 2 2 2 = k + l + m2 K2 ∂ω N m2 k N = = sin θ(sin θ cos φ) 2 ∂k K K k H K ∂ω N m2 l N = = sin θ(sin θ sin φ) 2 ∂k K K k H K k m N ∂ω = −N H 3 = − sinθ(cosθ) K ∂m K Note ω ∂ω N2 = − 2 cos2 θ < 0 m ∂m K 9 The vertical phase velocity is always opposite to the vertical group velocity. Waves propagating their phase upwards will be propagating their energy downwards and viceversa, or cg = N sinθ(sinθcos φ,sinθsin φ,−cosθ) . K Explanation of the Figure For internal waves, wave crest AA’ has moved to 4 wavelengths downward to the left, the wave group has moved upward parallel to the crests, at right angle to the phase propagation. 1 For surface gravity waves in deep water, c g = c 2 wavecrest AA’ has again moved 4 wavelengths downward to the left; the wave group has moved in the same direction but at half the speed, that is two wavelengths: AA’, with respect to the group, has moved 2 wavelengths. m 0 0.2 0.4 0.6 0.8 K cg 1.0 Figure 5. Figure by MIT OpenCourseWare. 10 z ( K, c ) cg u q x q cg u (K, c ) Figure 6. Figures by MIT OpenCourseWare. A A' 60o Figure 7a. z 11 A A' 60o z Figure 7b. Figures by MIT OpenCourseWare. A A' 60o z Figure 7c. 12

Internal Waves
