18.212: Algebraic Combinatorics April 29, 2019 Today we’re going to talk about Eulerian cycles! Deﬁnition 1 An Eulerian cycle or circuit / tour / walk in a digraph G is a closed directed walk on G such that we return to the same point where we start, and every edge is visited exactly once. We have the following famous result: Theorem 2 (Euler, 1736) A digraph G contains an Eulerian cycle if G is connected as an undirected graph and all vertices have equal indegree and outdegree. We can also say something similar for undirected graphs: Corollary 3 An undirected graph G contains an (undirected) Eulerian cycle if and only if G is connected and all vertices have even degree. The story behind these is the bridges of Konigsberg: Euler wanted to use each bridge excatly once. This is pretty easy to prove: Proof of directed version. It is clear that the conditions are necessary: the graph must be connected, and each edge is entered and exited an equal number of times. To show that this is suÿcient, pick some arbitrary edge and keep going until we get stuck at some point (because there are ﬁnitely many edges). We can then only get stuck at our initial vertex, because the outdegree is equal to the indegree: for any other vertex, if we enter a times, we should be able to exit a times. So if we end up at our starting vertex, we are either done, or there are some edges we haven’t used. Find a vertex for which an edge hasn’t been used: just keep going and repeatedly add edges until everything is used. What we’re discussing, then, is the next question: how many Eulerian cycles exist? To avoid overcounting, we’ll ﬁx our starting edge: basically, we are given a root r and edge e as reference, and we want to see how many Eulerian cycles are distinct up to that. (Since each edge is used exactly once in each Eulerian cycle, it doesn’t actually matter which one we use.) 1 Theorem 4 (B.E.S.T Theorem, 1951) Let G be a connected digraph, where the indegree of each vertex is equal to its outdegree, and ﬁx a root r . Then the number of Eulerian cycles in G is equal to Y # of Eulerian cycles in G = Inr (G) · (outdegree(v ) − 1)!, v vertex where Inr (G) is the number of in-trees rooted at r . B.E.S.T actually stands for de Bruijn, von Aardenne-Ehrenfest, Smith, and Tutte. Note that we know the value of Inr (G) from the directed matrix tree theorem! Fact 5 Since our graph is Eulerian (it satisﬁes the two requirements), the two Laplacian matrices Lin = Lout , and all row and column sums of our Laplacian matrix are zero: this implies that all cofactors of L are the same! Therefore, the number of in-trees rooted at r is the same as the number of out-trees rooted at r , and this is the same for all r . Example 6 Consider a 4-cycle, where there are a pair of oppositely-directed edges between two opposite vertices in the cycle. We have two in-trees, and the outdegrees are 2, 1, 2, 1, so we should have 2 · 1!0!1!0! = 2 Eulerian cycles. Proof. Fix our starting root r and starting edge e. Given any Eulerian cycle C, list them in the order they appear in our cycle starting from e: this will order all edges in some manner e1 e2 · · · eN . This is a total ordering, and it will be denoted by f 00 : then we shouldn’t have included f 00 in T in the ﬁrst place by maximality of construction of T !. So this is a contradiction, and no such cycle can exist. 2 This means that we have a graph with outdegree 1 everywhere except at the root, which is enough to make it an in-tree! So how do we ﬁnish the proof? For any vertex v , let wv be the ordering of all edges outgoing from v except for e and the tree T , given by our order

18.212 Algebraic Combinatorics, Lecture 32: Eulerian Cycles in Digraphs and B.E.S.T. Theorem
