Introduction to Thermo; 0th Law; Temperature; Work; Heat

20.110/5.60 Lecture #1 page 1 Introduction to Thermodynamics Thermodynamics: → Describes macroscopic properties of equilibrium systems → Entirely Empirical → Built on 4 Laws and “simple” mathematics 0th Law ⇒ Defines Temperature (T) 1st Law ⇒ Defines Energy (U) 2nd Law ⇒ Defines Entropy (S) 3rd Law ⇒ Gives Numerical Value to Entropy These laws are UNIVERSALLY VALID, they cannot be circumvented. 20.110/5.60 Lecture #1 page 2 Definitions: • System: The part of the Universe that we choose to study • Surroundings: The rest of the Universe • Boundary: The surface dividing the System from the Surroundings Systems can be: • Open: Mass and Energy can transfer between the System and the Surroundings • Closed: Energy can transfer between the System and the Surroundings, but NOT mass • Isolated: Neither Mass nor Energy can transfer between the System and the Surroundings Describing systems requires: • A few macroscopic properties: p, T, V, n, m, … • Knowledge if System is Homogeneous or Heterogeneous • Knowledge if System is in Equilibrium State • Knowledge of the number of components 20.110/5.60 Lecture #1 page 3 Two classes of Properties: • Extensive: Depend on the size of the system (n,m,V,…) • Intensive: Independent of the size of the system V (T,p, V = ,…) n The State of a System at Equilibrium: • Defined by the collection of all macroscopic properties that are described by State variables (p,n,T,V,…) [INDEPENDENT of the HISTORY of the SYSTEM] • For a one-component System, all that is required is “n” and 2 variables. All other properties then follow. V = f (n , p, T) or p = g ( n , V, T ) These are Equations of States E.g. The Ideal gas law: pV = nRT The Virial expansion: B (T ) C (T ) pV =1+ + +" RT V V 2 The van der Waals equation of state: ⎛ p + a ⎞ V − b = RT ⎜ ⎟ V 2⎠ ⎝ ( ) 20.110/5.60 Lecture #1 • Notation: 3 H2 (g, 1 bar, 100 °C) 3 moles (n=3) gas p=1 bar 2 Cl2 (g, 5 L, 50 °C) Change of State: , T=100 °C 5 Ar (s, 5 bar, 50 K) (Transformations) • Notation: 3 H2 (g, 5 bar, 100 °C) = 3 H2 (g, 1 bar, 50 °C) initial state final state 2 H2O (ℓ, 1 bar, 50 °C) = 3 H2O (g, 1 bar, 150 °C) initial state final state page 4 20.110/5.60 Lecture #1 page 5 • Path: Sequence of intermediate states 5 p (bar) 1 50 100 T (K) • Process: Describes the Path - Reversible (always in Equilibrium) - Irreversible (defines direction of time) - Adiabatic (no heat transfer between sys. and surr.) - Isobaric (constant pressure) - Isothermal (constant temperature) - Constant Volume -… 20.110/5.60 Lecture #1 page 6 Thermal Equilibrium (Heat stops flowing) A B A B A When a hot object is placed in thermal contact with a cold object, heat flows from the warmer to the cooler object. This continues until they are in thermal equilibrium (the heat flow stops). At this point, both bodies are said to have the same “temperature”. This intuitively straightforward idea is formalized in the 0th Law of thermodynamics and is made practical through the development of thermometers and temperature scales. ≡≡≡≡≡ ZERO’th LAW of Thermodynamics ≡≡≡≡≡ If then A and B are in thermal equilibrium and B and C are in thermal equilibrium, A and C are in thermal equilibrium. Consequence of the zero’th law: B acts like a thermometer, and at the same “temperature”. A , B , and C are all B 20.110/5.60 Lecture #1 Operational definition of temperature (t) Need : (1) (2) (3) (4) substance property that depends on t reference points interpolation scheme between ref. pts. Example: Ideal Gas Thermometer with the Celsius scale. Based on Boyle’s Law ( lim pV p →0 ) t = constant = f (t ) for fixed t depends on t • the substance is a gas • f (t ) is the property • the boiling point (tb = 100°C ) and freezing point (tf = 0°C ) of water are the reference points • the interpolation is linear p 0 f(t)=f(0 C)(1+At) Experimental result: A = 0.0036609 = 1/273.15 -273.15 Note: 0 100 C (t = −273.15 °C ) is special t = −273.15 °C is called the absolute zero, page 7 20.110/5.60 Lecture #1 page 8 This suggests defining a new temperature scale (Kelvin) T (K ) = t ( °C ) + 273.15 T = 0K corresponds to absolute zero (t = −273.15 °C ) Better reference points used for the Kelvin scale today are T = 0K (absolute zero) and Ttp = 273.16K (triple point of H2O) Ideal Gases Boyle’s Law and the Kelvin scale ( lim pV p →0 ) T ( ) ⎡ lim pV ⎤ tp ⎥ p →0 ⎢ = T ≡ RT ⎢ 273.16 ⎥ ⎣⎢ ⎦⎥ valid for all gases for p → 0 define the “gas constant” An ideal gas obeys the expression pV = RT at all pressures (⇒ the gas molecules do not interact) ⎡ lim ( pV ) ⎤ tp p →0 ⎥ = 8.31451 J R=⎢ ⎢ 273.16 ⎥ K − mol ⎣ ⎦ (gas constant) 20.110/5.60 Lecture #1 • Work: page 9 “w” w = F ⋅A applied force Expansion work distance A pext pext F = pext A w = − ( pext A ) A = − pext ∆V convention: • Heat: Having a “-“ sign here implies w > 0 if ∆V < 0 , that is, positive work means that the surroundings do work to the system. If the system does work on the surroundings ( ∆V > 0 ) then w < 0 . “q” That quantity flowing between the system and the surroundings that can be used to change the temperature of the system and/or the surroundings. Sign convention: If heat enters the system, then it is positive.
