Class on Computer Systems Security, Lecture 2

6.858 Lecture 2 REVIEW OF BUFFER  OVERFLOW ATTACKS Last lecture, we looked at the basics of performing a buffer overflow  attack.  That   attack leveraged several observations: • Systems software is  often  written  in C (operating systems, file systems, databases, compilers, network servers, command shells and console utilities) • C is essentially  high-­‐level assembly, so . . . o Exposes raw pointers to memory o Does not perform  bounds-­‐checking  on arrays (b/c  the  hardware   doesn't do this, and C wants to get  you  as close to the hardware as possible) • Attack also leveraged architectural knowledge about how x86  code works: o The direction  that the  stack grows o Layout of stack variables  (esp. arrays  and return addresses  for functions) void read_req() { char buf[128]; int i; gets(buf); //. . . do stuff w/buf . . . } What does the compiler generate in terms of memory layout? x86 stack  looks like this: • %esp points  to  the  last (bottom-­‐most) valid thing on the stack. • %ebp points  to  the  caller's  %esp value. +------------------+ entry %ebp ----> | .. prev frame .. | | | | | +------------------+ entry %esp ----> | return address | +------------------+ new %ebp ------> | saved %ebp | +------------------+ | buf[127] | | ... | | buf[0] | +------------------+ new %esp ------> | i | +------------------+ 1 | | stack grows down | v How does the  adversary  take  advantage  of this  code? • Supply long input, overwrite  data on stack past buffer. • Key observation  1: attacker can  overwrite the return address, make the program  jump to a place of the attacker's choosing! • Key observation  2: attacker can  set  return  address to the buffer itself,  include some x86 code in there! What  can  the attackers do once  they are  executing code? • Use any privileges  of the  process! If the  process is running as  root or Administrator, it can do whatever it wants on the system. Even if the process is not running as root, it can send spam, read files, and interestingly,  attack or subvert other machines behind the firewall. • Hmmm, but why didn't the OS notice that the buffer has been  overrun? o As far as the OS is aware, nothing strange has happened! Remember that, to a first approximation, the OS only gets invoked by the web   server  when the server does IO or IPC.  Other than  that,  the OS basically sits back and lets the program  execute, relying on hardware   page tables to prevent  processes from  tampering with each other's memory. However, page table protections don't  prevent  buffer overruns launched by a process "against  itself,"  since the overflowed   buffer and the return  address and all of that  stuff are inside the process's valid address space. o Later  in this  lecture, we'll talk about things that  the OS *can*  do to make buffer overflows more difficult. FIXING  BUFFER OVERFLOWS Approach  #1: Avoid bugs in C code. Programmer should carefully check sizes of buffers, strings, arrays, etc. In particular, the programmer should  use  standard  library  functions  that take buffer sizes into  account (strncpy() instead  of strcpy(), fgets() instead  of gets(), etc.). Modern  versions of gcc and Visual  Studio warn  you  when a program  uses unsafe functions  like  gets().  In  general,  YOU  SHOULD  NOT  IGNORE COMPILER WARNINGS. Treat warnings like errors! Good: Avoid problems in the first place! Bad: It's hard to ensure that  code is bug-­‐free,  particularly if the  code base  is large.   Also, the application itself may define buffer manipulation functions which do not use  fgets() or strcpy() as primitives. Approach  #2: Build tools to help programmers find bugs. 2 For example, we can use static analysis to find problems in source  code before  it's   compiled. Imagine that you had a function  like  this: void foo(int *p){ int offset; int *z = p + offset; if(offset > 7){ bar(offset); } } By statically  analyzing  the control  flow,  we can tell that  offset  is used without  being   initialized. The if-­‐statement  also puts bounds on offset that we may be able to propogate  to bar. We'll talk about static analysis more in later lectures. “Fuzzers” that supply random inputs can be effective for finding bugs.  Note  that fuzzing can be combined with static analysis to maximize code coverage! Bad: Difficult to prove the complete absence of bugs, esp. for unsafe  code like  C. Good:  Even partial analysis is useful, since programs should become strictly less buggy. For example, baggy bounds checking cannot catch all memory errors, but it can detect many important kinds. Approach  #3: Use a memory-­‐safe  language  (JavaScript,  C#, Python). Good: Prevents memory corruption errors by not exposing raw memory addresses to the programmer, and by automatically handling  garbage  collection. Bad: Low-­‐level  runtime code DOES use raw memory addresses. So, that runtime core still needs to  be  correct.  For example, heap spray attacks: • • https://www.usenix.org/legacy/event/sec09/tech/full_papers/ratanaworab han.pdf https://www.corelan.be/index.php/2011/12/31/exploit-writing-tutorialpart-11-heap-spraying-demystified/ Bad: Still  have a lot  of legacy  code in unsafe languages (FORTRAN and COBOL  oh noes). Bad: Maybe you  need access to low-­‐level  hardware features b/c,  e.g.,  you're writing   a device driver. Bad: Perf is worse than  a fine-­‐tuned C application? 3 • • • Used to be a bigger problem, but hardware and high-­‐level  languages are getting better. o JIT compilation FTW! o asm.js is within 2x of native C++ perf! [http://asmjs.org/faq.html] Use careful coding to  avoid garbage  collection jitter in critical  path. Maybe you're a bad person/language chauvinist who doesn't know how to pick the right  tool for the  job.  If  your  task is I/O-­‐bound,  raw compute speed is much less important. Also, don't be the chump who writes text manipulation programs in C. All 3 above approaches are  effective  and  widely  used, but buffer overflows  are  still a problem in practice. • Large/complicated legacy code written in C is very prevalent. • Even  newly written code in C/C++  can have memory errors. How  can we mitigate buffer overflows despite buggy code? • Two  things  going on in a "traditional"  buffer overflow: o Adversary gains control over execution (program counter). o Adversary executes some malicious code. • What  are the difficulties to these two steps? o Requires  overwriting  a code pointer (which is later invoked). Common  target is a return address  using a buffer  on the  stack. Any memory error could potentially work, in practice. Function pointers, C++ vtables, exception handlers, etc. o Requires some interesting code in process's memory. This is often easier  than  #1, because: § it's  easy  to  put code  in a buffer,  and § the process already contains a lot  of code that might be exploitable. o However, the  attacker  needs  to  put this  code in a predictable  location, so that the  attacker  can  set the code pointer  to  point to  the  evil code! Mitigation approach 1: canaries (e.g., StackGuard,  gcc's SSP) Idea: OK to overwrite  code  ptr,  as long as we catch it before invocation. One of the earlier systems: StackGuard • Place  a canary on the  stack upon entry,  check canary value before return. • Usually  requires source code; compiler inserts canary checks. • Q: Where is the canary on the stack diagram? o A: Canary  must go "in front of" return address on the stack,  so that any overflow  which rewrites return address will  also rewrite canary. 4 | | +------------------+ entry %esp ----> | return address | +------------------+ new %ebp ------> | saved %ebp | +------------------+ | CANARY | +------------------+ | buf[127] | | ... | | buf[0] | +------------------+ | | ^ | | | | Overflow goes | this way. | | | Q: Suppose that the compiler always made the canary 4 bytes  of the  'a'  character.   What's wrong  with this? • A: Adversary can include the appropriate canary value in the  buffer  overflow! So, the canary must be either hard to guess,  or it can be  easy to  guess but still resilient against buffer overflows. Here are examples of these approaches. • “Terminator canary”:  four  bytes  (0, CR, LF, -­‐1) o Idea: Many C functions treat  these  characters as terminators(e.g., gets(), sprintf()). As a result, if the canary matches one of these terminators, then further writes won't happen. • Random  canary generated at program  init time: Much more common today (but,  you need good randomness!). What  kinds of vulnerabilities will  a stack  canary not  catch? • Overwrites  of function  pointer  variables  before  the  canary. • Attacker can overwrite a data pointer, then leverage it to do arbitrary mem   writes. int *ptr = ...; char buf[128]; gets(buf); //Buffer is overflowed, and overwrites ptr. *ptr = 5; //Writes to an attacker-controlled address! //Canaries can't stop this kind of thing. • • Heap object overflows  (function pointers, C++ vtables). malloc/free overflows int main(int argc, char **argv) { char *p, *q; p = malloc(1024); q = malloc(1024); 5 } if(argc >= 2) strcpy(p, argv[1]); free(q); free(p); return 0; Assume that the two blocks of memory belonging to p and q are adjacent/nearby  in   memory. Assume that malloc and free represent memory blocks like this: +----------------+ | | | App data | | | +----------------+ | size | +----------------+ +----------------+ | size | +----------------+ | | ...empty... +----------------+ | bkwd ptr | +----------------+ | fwd ptr | +----------------+ | size | +----------------+ Allocated memory block Free memory block So, the buffer overrun  in p will overwrite  the size value in q's memory  block!  Why is this a problem? When free() merges two adjacent free blocks, it needs to manipulate bkwd and fwd pointers, and the pointer calculation  uses size to determine where the free memory block  structure lives! p = get_free_block_struct(size); bck = p->bk; fwd = p->fd; fwd->bk = bck; //Writes memory! bck->fd = fwd; //Writes memory! The free memory block is represented as a C struct;  by  corrupting  the  size value,  the attacker can force free() to operate on  a fake  struct that resides in attacker-­‐ 6 controlled memory and has attacker-­‐controlled  values for the  forward  and   backwards pointers. If the attacker knows how free()  updates the pointers,  he can  use that  update code to write an arbitrary value to an arbitrary place. For example, the attacker can overwrite a return  address. Actual details are a bit more complicated; if you're interested  in gory details, go here: http://www.win.tue.nl/~aeb/linux/hh/hh-11.html The high-­‐level  point  is that  stack  canaries won't prevent  this attack, because  the attacker is "skipping over" the canary and writing  directly  to  the  return address! So, stack canaries  are  one  approach for mitigating buffer overflows  in buggy  code. Mitigation approach 2: bounds checking. Overall goal: prevent pointer misuse by checking if pointers are in  range. Challenge:  In C, it can be  hard  to  differentiate  between  a valid pointer and an invalid pointer. For example, suppose that a program allocates an array of characters … char x[1024]; … as  well as a pointer to some place in that array, e.g., char *y = &x[107]; Is it OK to increment y to access subsequent elements? • If x represents a string buffer, maybe yes. • If x represents a network message, maybe no. Life is even more complicated if the program uses unions. union u{ int i; struct s{ int j; int k; }; }; int *ptr = &(u.s.k); //Does this point to valid data? The problem is that, in C,  a pointer does not encode information about the intended usage semantics for that pointer. So, a lot of tools don't  try to guess those semantics. Instead, the tools have a less lofty goal than "totally correct" pointer semantics: the 7 tools just  enforce the memory bounds on heap objects and stack objects. At a high level,  here's the goal: For a pointer  p'  that's derived from  p, p' should only be dereferenced to access the valid memory region that belongs to p. Enforcing memory bounds is a weaker goal than enforcing "totally correct"  pointer semantics. Programs can still shoot themselves in the foot by trampling on their memory in nasty ways (e.g.,  in the union example, the application may write to ptr even though  it's  not defined). However, bounds  checking is still useful because  it prevents *arbitrary* memory overwrites. The program  can only trample its memory if that memory is actually allocated! THIS IS CONSIDERED  PROGRESS IN  THE WORLD  OF  C. A drawback of bounds checking is that it typically requires changes to the compiler, and programs must be recompiled with the new compiler. This is a problem  if you only  have  access to binaries. What  are some approaches for implementing bounds checking? Bounds  checking  approach #1: Electric  fences • This is an old approach that had the virtue of being simple. • Idea: Align each heap object with a guard page, and use page tables to ensure that  accesses to the guard  page cause a fault. +---------+ | | Guard | | +---------+ | Heap | | obj | +---------+ • • • • ^ | Overflows cause a page exception | | This is a convenient debugging  technique, since  a heap  overflow will immediately cause a crash, as opposed to silently corrupting the heap and causing a failure at some indeterminate time in the future. Big  advantage: Works without source code-­‐-­‐-­‐don't need to  change compilers or recompile programs! [You *do* need to relink them  so that they use a new version of malloc which implements electric fences.] Big  disadvantage: Huge overhead!  There's only  one object per page, and you have the overhead of a dummy page which isn't used for "real"  data. Summary:  Electric  fences can be useful  as debugging  technique, and they  can prevent some buffer overflows for heap objects. However, electric  fences can't protect the  stack,  and the memory overhead is too high to use in production systems. Bounds  checking  approach #2: Fat pointer 8 Idea: Modify  the pointer representation  to  include  bounds information. Now, a pointer includes a memory address and bounds information about an object that lives in that memory region. Ex: Regular 32-bit pointer +-----------------+ | 4-byte address | +-----------------+ Fat pointer (96 bits) +-----------------+----------------+---------------------+ | 4-byte obj_base | 4-byte obj_end | 4-byte curr_address | +-----------------+----------------+---------------------+ You need to modify the compiler and recompile the programs to use the fat pointers. The compiler generates code to abort the program  if it dereferences a pointer whose address is outside of its own base...end range. int *ptr = malloc(sizeof(int) * 2); while(1){ *ptr = 42; <----------| ptr++; | } | __________________________| | This line  checks  the  current address  of the  pointer  and ensures that it's  in-­‐bounds.   Thus, this  line  will fail during the  third  iteration  of the  loop. Problem  #1: It can be expensive to check all pointer dereferences. The C community hates  things  that are expensive,  because  C is all about SPEED SPEED SPEED. Problem  #2: Fat pointers are incompatible with a lot of existing  software. • You can't pass a fat pointer to an unmodified library. • You  can't  use fat  pointers in  fixed-­‐size  data structures.  For example, sizeof(that_struct) will  change! • Updates  to  fat pointers  are not atomic, because they span multiple words. Some programs assume that pointer writes are atomic. Bounds  checking  approach #3: Use shadow data structures  to  keep track  of bounds information (Jones and Kelly, Baggy). Basic  idea: For each allocated object,  store  how big  the object is. For example: Record the value passed to malloc: char *p = malloc(mem_size); For static  variables, the values are determined by the compiler: 9 char p[256]; For each  pointer, we  need  to  interpose  on two  operations: • pointer arithmetic:  char *q = p + 256; • pointer dereferencing: char ch = *q; Q: Why  do we need to interpose on  dereference?  Can't  we do just arithmetic? • A: An invalid pointer isn't always a bug! For example, a pointer to one element past the last item  of an array might be used as a stopping  test  in a loop. Applications can also do goofy stuff like: o Simulating 1-­‐indexed  arrays o Computing p+(a-­‐b) as (p+a)-­‐b o Generating  OOB pointers that  are later checked for validity So, the mere creation of invalid  pointer  shouldn't cause  program  to fail. Q: Why do we need to interpose on arithmetic? Can't we do just dereference? • A: Interposing on arithmetic is what allows us to track the provenance of pointers and set  the OOB bit. Without the OOB, we won't  be able to tell  when   a derived pointer goes outside of the bounds of its base object. Challenge 1: How do we find the bounds information for a regular  pointer, i.e., a pointer that's in-­‐bounds? Naive: Use a hash table or interval tree to map addresses to bounds. Good: Space  efficient (only  store  info for in-­‐use  pointers,  not all possible addresses). Bad: Slow lookup (multiple memory accesses per look-­‐up). Naive: Use an array to store bounds info for *every* memory address. Good: Fast! Bad: Really high memory overhead. Challenge 2: How do we  force out-­‐of-­‐bounds pointer dereferences to fail? Naive: Instrument every pointer dereference. Good: Uh, it works. Bad: Expensive-­‐-­‐-­‐we have  to  execute  extra code for every dereference! The baggy  bounds  approach:  5 tricks • Round up each allocation to a power of 2,  and align  the start of the  allocation   to that  power of 2. • Express each range limit as log_2(alloc_size).  For 32-­‐bit  pointers,  only need 5 bits to express the possible ranges. • Store limit info in a linear array: fast  lookup  with one byte  per entry. Also, we can use virtual memory to allocate the array  on-­‐demand! • Allocate memory at slot granularity  (e.g., 16 bytes): fewer  array  entries. 10 Ex: slot_size = 16 p = malloc(16); p = malloc(32); table[p/slot_size] = 4; table[p/slot_size] = 5; table[(p/slot_size) + 1] = 5; Now,  given a known  good pointer p, and a derived  pointer p', we can test whether p' is valid  by checking whether both pointers have the same prefix  in their address   bits,  and they only differ in their  e least significant bits,  where  e is equal to the logarithm  of the allocation size. C code -­‐-­‐-­‐-­‐-­‐-­‐ p' = p + i; Bounds check -­‐-­‐-­‐-­‐-­‐-­‐-­‐-­‐-­‐-­‐-­‐-­‐ size = 1 << table[p >> log_of_slot_size]; base = p & ~(size - 1); (p' >= base) && ((p' - base) < size) Optimized bounds check -­‐-­‐-­‐-­‐-­‐-­‐-­‐-­‐-­‐-­‐-­‐-­‐-­‐-­‐-­‐-­‐-­‐-­‐-­‐-­‐-­‐-­‐ (p^p') >> table[p >> log_of_slot_size] == 0 • Use virtual memory system  to prevent out-­‐of-­‐bound derefs: set most significant bit  in  an OOB pointer, and then mark pages in the upper half of the address space as inaccessible. So, we don't have to instrument pointer dereferences to prevent bad memory accesses! Example code (assume that slot_size=16): char *p = malloc(44); //Note that the nearest power of 2 (i.e., //64 bytes) are allocated. So, there are //64/(slot_size) = 4 bounds table entries //that are set to log_2(64) = 6. char *q = p + 60; //This access is ok: It's past p's object //size of 44, but still within the baggy //bounds of 64. char *r = q + 16; //r is now at an offset of 60+16=76 from 11 //p. This means that r is (76-64)=12 bytes //beyond the end of p. This is more than //half a slot away, so baggy bounds will //raise an error. char *s = q + 8; //s is now at an offset of 60+8=68 from p. //So, s is only 4 bytes beyond the baggy //bounds, which is les than half a slot //away. No error is raised, but the OOB //high-order bit is set in s, so that s //cannot be dereferenced. char *t = s - 32; //t is now back inside the bounds, so //the OOB bit is cleared. For OOB pointers, the  high  bit is set (if OOB within half  a slot). • Typically,  OS  kernel lives  in upper half,  protects  itself via paging hardware. • Q: Why  half a slot  for out-­‐of-­‐bounds? So what's the answer to the homework problem? char *p = malloc(256); char *q = p + 256; char ch = *q; //Does this raise an exception? //Hint: How big is the baggy bound for p? ADDITIONAL/SUPPLEMENTAL INFO =============================== Some bugs in the baggy bounds  paper: Figure  3, explicit bounds  check should  generate  the size like this: size = 1 << table[p >> log_of_slot_size] Figure 3, optimized bounds check should be (p^p') >> table[p >> log_of_slot_size] == 0 Figures  5 and  18, pointer arithmetic code should be char *p = &buf[i]; or char *p = buf + i; 12
