Tutorial 7: Data Structures and Input Assertion

MATLAB Tutorial Chapter 7. Data structures and input assertion 7.1. User-defined data structures Vectors and matrices are not the only means that MATLAB offers for grouping data into a single entity. User defined data structures are also available that enable the programmer to create variable types that mix numbers, strings, and arrays. As an example, let us create a data structure that contains the information for a single student. We will store the name, status (year and department), the homework and exam grades, and the final class grade. First, we can define a NameData structure to contain the name. Here, the "." operator, used in the case of Structure.Field tells MATLAB to access the field named "Field" in the structure "Structure". NameData.First = 'John'; NameData.MI = 'J'; NameData.Last = 'Doe'; We now create a StudentData structure with a name field. StudentData.Name = NameData; We now initialize the rest of the structure. StudentData.Status = 'ChE grad 1'; StudentData.HW = 10; StudentData.Exam = linspace(100,100,3); We can now view the contents of the structure StudentData StudentData.Name StudentData.Exam We can operate on the elements of a structure. StudentData.Exam(3) = 0; StudentData.Exam StudentData.Name.First = 'Jane'; StudentData.Name We can also create arrays of structures num_students = 5; for i=1:num_students ClassData(i) = StudentData; end ClassData ClassData(2) Structures can be passed as arguments to functions in the same manner as scalars, vectors, and matrices. In this case, we use the function pass_or_fail listed below. message = pass_or_fail(ClassData(2)); message File pass_or_fail.m function message = pass_or_fail(StudentData) Exam_avg = mean(StudentData.Exam); if(Exam_avg >= 70) message = 'You pass!'; else message = 'You fail!'; end return; 7.2. Input assertion routines Good programming style dictates the practice of defensive programming, that is, anticipating and detecting possible errors before they cause a run-time error that results in a halt to the program execution or a crash. This allows one to save the current data to the disk or take corrective action to avoid a catastrophic failure. One common source of errors can be avoided by having each subroutine make sure that the data that it has been fed through its argument list is of the approriate type, e.g. argument 1 should be a real, positive, scalar integer and argument 2 should be a real, non-negative column vector of length N. The following m-files are useful for automating this checking process, and a scalar input function is provided to allow the robust entry of data from the keyboard. assert_scalar.m function [iflag_assert,message] = assert_scalar( ... i_error,value,name,func_name, ... check_real,check_sign,check_int,i_error); This m-file contains logical checks to assert than an input value is a type of scalar number. This function is passed the value and name of the variable, the name of the function making the assertion, and four integer flags that have the following usage : i_error : controls what to do if test fails if i_error is non-zero, then use error() MATLAB command to stop execution, otherwise just return the appropriate negative number. if i_error > 1, then dump current state to dump_error.mat before calling error(). check_real : check to examine whether input number is real or not. See table after function header for set values of these case flags check_real = i_real (make sure that input is real) check_real = i_imag (make sure that input is purely imaginary) any other value of check_real (esp. 0) results in no check check_real i_real = 1; i_imag = -1; check_sign : check to examine sign of input value see table after function header for set values of these case flags check_sign = i_pos (make sure input is positive) check_sign = i_nonneg (make sure input is non-negative) check_sign = i_neg (make sure input is negative) check_sign = i_nonpos (make sure input is non-positive) check_sign = i_nonzero (make sure input is non-zero) check_sign = i_zero (make sure input is zero) any other value of check_sign (esp. 0) results in no check check_sign i_pos = 1; i_nonneg = 2; i_neg = -1; i_nonpos = -2; i_nonzero = 3; i_zero = -3; check_int : check to see if input is an integer if = 1, then check to make sure input is an integer any other value, perform no check Kenneth Beers Massachusetts Institute of Technology Department of Chemical Engineering 7/2/2001 Version as of 7/21/2001 function [iflag_assert,message] = assert_scalar( ... i_error,value,name,func_name, ... check_real,check_sign,check_int); iflag_assert = 0; message = 'false'; First, set case values of check integer flags. check_real i_real = 1; i_imag = -1; check_sign i_pos = 1; i_nonneg = 2; i_neg = -1; i_nonpos = -2; i_nonzero = 3; i_zero = -3; Check to make sure input is numerical and not a string. if(~isnumeric(value)) message = [ func_name, ': ', ... name, ' is not numeric']; iflag_assert = -1; if(i_error ~= 0) if(i_error > 1) save dump_error.mat; end error(message); else return; end end Check to see if it is a scalar. if(max(size(value)) ~= 1) message = [ func_name, ': ', ... name, ' is not scalar']; iflag_assert = -2; if(i_error ~= 0) if(i_error > 1) save dump_error.mat; end error(message); else return; end end Then, check to see if it is real. switch check_real; case {i_real} if(~isreal(value)) message = [ func_name, ': ', ... name, ' is not real']; iflag_assert = -3; if(i_error ~= 0) if(i_error > 1) save dump_error.mat; end error(message); else return; end end case {i_imag} if(real(value)) message = [ func_name, ': ', ... name, ' is not imaginary']; iflag_assert = -3; if(i_error ~= 0) if(i_error > 1) save dump_error.mat; end error(message); else return; end end end Next, check sign. switch check_sign; case {i_pos} if(value <= 0) message = [ func_name, ': ', ... name, ' is not positive']; iflag_assert = -4; if(i_error ~= 0) if(i_error > 1) save dump_error.mat; end error(message); else return; end end case {i_nonneg} if(value < 0) message = [ func_name, ': ', ... name, ' is not non-negative']; iflag_assert = -4; if(i_error ~= 0) if(i_error > 1) save dump_error.mat; end error(message); else return; end end case {i_neg} if(value >= 0) message = [ func_name, ': ', ... name, ' is not negative']; iflag_assert = -4; if(i_error ~= 0) if(i_error > 1) save dump_error.mat; end error(message); else return; end end case {i_nonpos} if(value > 0) message = [ func_name, ': ', ... name, ' is not non-positive']; iflag_assert = -4; if(i_error ~= 0) if(i_error > 1) save dump_error.mat; end error(message); else return; end end case {i_nonzero} if(value == 0) message = [ func_name, ': ', ... name, ' is not non-zero']; iflag_assert = -4; if(i_error ~= 0) if(i_error > 1) save dump_error.mat; end error(message); else return; end end case {i_zero} if(value ~= 0) message = [ func_name, ': ', ... name, ' is not zero']; iflag_assert = -4; if(i_error ~= 0) if(i_error > 1) save dump_error.mat; end error(message); else return; end end end Finally, check to make sure it is an integer. if(check_int == 1) if(round(value) ~= value) message = [ func_name, ': ', ... name, ' is not an integer']; iflag_assert = -5; if(i_error ~= 0) if(i_error > 1) save dump_error.mat; end error(message); else return; end end end set flag for succesful passing of all checks iflag_assert = 1; message = 'true'; return; assert_vector.m function [iflag_assert, message] = ... assert_vector( ... i_error,value,name,func_name,num_dim, ... check_real,check_sign,check_int,check_column); This m-file contains logical checks to assert than an input value is a vector of a given type. This function is passed the value and name of the variable, the name of the function making the assertion, the dimension that the vector is supposed to be, and five integer flags that have the following usage : i_error : controls what to do if test fails if i_error is non-zero, then use error() MATLAB command to stop execution, otherwise just return the appropriate negative number. if i_error > 1, create file dump_error.mat before calling error() check_real : check to examine whether input is real see table after function header for set values of these case flags check_real = i_real (make sure that input is real) check_real = i_imag (make sure that input is purely imaginary) any other value of check_real (esp. 0) results in no check check_real i_real = 1; i_imag = -1; check_sign : check to examine sign of input see table after function header for set values of these case flags check_sign = i_pos (make sure input is positive) check_sign = i_nonneg (make sure input is non-negative) check_sign = i_neg (make sure input is negative) check_sign = i_nonpos (make sure input is non-positive) check_sign = i_nonzero (make sure input is non-zero) check_sign = i_zero (make sure input is zero) any other value of check_sign (esp. 0) results in no check check_sign i_pos = 1; i_nonneg = 2; i_neg = -1; i_nonpos = -2; i_nonzero = 3; i_zero = -3; check_int : check to see if input is an integer if = 1, then check to make sure input is an integer any other value, perform no check check_column : check to see if input is a column or row vector check_column = i_column (make sure input is column vector) check_column = i_row (make sure input is row vector) any other value, perform no check check_column i_column = 1; i_row = -1; if the dimension num_dim is set to zero, no check as to the dimension of the vector is made. Kenneth Beers Massachusetts Institute of Technology Department of Chemical Engineering 7/2/2001 Version as of 7/21/2001 function [iflag_assert,message] = ... assert_vector( ... i_error,value,name,func_name,num_dim, ... check_real,check_sign,check_int,check_column); First, set case values of check integer flags. check_real i_real = 1; i_imag = -1; check_sign i_pos = 1; i_nonneg = 2; i_neg = -1; i_nonpos = -2; i_nonzero = 3; i_zero = -3; check_column i_column = 1; i_row = -1; iflag_assert = 0; message = 'false'; Check to make sure input is numerical and not a string. if(~isnumeric(value)) message = [ func_name, ': ', ... name, 'is not numeric']; iflag_assert = -1; if(i_error ~= 0) if(i_error > 1) save dump_error.mat; end error(message); else return; end end Check to see if it is a vector of the proper length. num_rows = size(value,1); num_columns = size(value,2); if it is a multidimensional array if(length(size(value)) > 2) message = [ func_name, ': ', ... name, 'has too many subscripts']; iflag_assert = -2; if(i_error ~= 0) if(i_error > 1) save dump_error.mat; end error(message); else return; end end if both the number of rows and number of columns are not equal to 1, then value is a matrix instead of a vector. if(and((num_rows ~= 1),(num_columns ~= 1))) message = [ func_name, ': ', ... name, 'is not a vector']; iflag_assert = -2; if(i_error ~= 0) if(i_error > 1) save dump_error.mat; end error(message); else return; end end if the dimension of the vector is incorrect if(num_dim ~= 0) if(length(value) ~= num_dim) message = [ func_name, ': ', ... name, 'is not of the proper length']; iflag_assert = -2; if(i_error ~= 0) if(i_error > 1) save dump_error.mat; end error(message); else return; end end end check to make sure that the vector is of the correct type (e.g. column) switch check_column; case {i_column} check to make sure that it is a column vector if(num_columns > 1) message = [ func_name, ': ', ... name, 'is not a column vector']; iflag_assert = -2; if(i_error ~= 0) if(i_error > 1) save dump_error.mat; end error(message); else return; end end case {i_row} if(num_rows > 1) message = [ func_name, ': ', ... name, 'is not a row vector']; iflag_assert = -2; if(i_error ~= 0) if(i_error > 1) save dump_error.mat; end error(message); else return; end end end Then, check to see if all elements are of the proper complex type. switch check_real; case {i_real} if any element of value is not real if(any(~isreal(value))) message = [ func_name, ': ', ... name, ' is not real']; iflag_assert = -3; if(i_error ~= 0) if(i_error > 1) save dump_error.mat; end error(message); else return; end end case {i_imag} if any element of value is not purely imaginary if(any(real(value))) message = [ func_name, ': ', ... name, ' is not imaginary']; iflag_assert = -3; if(i_error ~= 0) if(i_error > 1) save dump_error.mat; end error(message); else return; end end end Next, check sign. switch check_sign; case {i_pos} if any element of value is not positive if(any(value <= 0)) message = [ func_name, ': ', ... name, ' is not positive']; iflag_assert = -4; if(i_error ~= 0) if(i_error > 1) save dump_error.mat; end error(message); else return; end end case {i_nonneg} if any element of value is negative if(any(value < 0)) message = [ func_name, ': ', ... name, ' is not non-negative']; iflag_assert = -4; if(i_error ~= 0) if(i_error > 1) save dump_error.mat; end error(message); else return; end end case {i_neg} if any element of value is not negative if(any(value >= 0)) message = [ func_name, ': ', ... name, ' is not negative']; iflag_assert = -4; if(i_error ~= 0) if(i_error > 1) save dump_error.mat; end error(message); else return; end end case {i_nonpos} if any element of value is positive if(any(value > 0)) message = [ func_name, ': ', ... name, ' is not non-positive']; iflag_assert = -4; if(i_error ~= 0) if(i_error > 1) save dump_error.mat; end error(message); else return; end end case {i_nonzero} if any element of value is zero if(any(value == 0)) message = [ func_name, ': ', ... name, 'is not non-zero']; iflag_assert = -4; if(i_error ~= 0) if(i_error > 1) save dump_error.mat; end error(message); else return; end end case {i_zero} if any element of value is non-zero if(any(value ~= 0)) message = [ func_name, ': ', ... name, ' is not zero']; iflag_assert = -4; if(i_error ~= 0) if(i_error > 1) save dump_error.mat; end error(message); else return; end end end Finally, check to make sure it is an integer. if(check_int == 1) if(any(round(value) ~= value)) message = [ func_name, ': ', ... name, ' is not an integer']; iflag_assert = -5; if(i_error ~= 0) if(i_error > 1) save dump_error.mat; end error(message); else return; end end end set flag for succesful passing of all checks iflag_assert = 1; message = 'true'; return; assert_matrix.m function [iflag_assert,message] = assert_matrix( ... i_error,value,name,func_name, ... num_rows,num_columns, ... check_real,check_sign,check_int); This m-file contains logical checks to assert than an input value is a matrix of a given type. This function is passed the value and name of the variable, the name of the function making the assertion, the dimension that the matrix is supposed to be, and four integer flags that have the following usage : i_error : controls what to do if test fails if i_error is non-zero, then use error() MATLAB command to stop execution, otherwise just return the appropriate negative number. if i_error > 1, create file dump_error.mat before calling error() check_real : check to examine whether input is real see table after function header for set values of these case flags check_real = i_real (make sure that input is real) check_real = i_imag (make sure that input is purely imaginary) any other value of check_real (esp. 0) results in no check check_real i_real = 1; i_imag = -1; check_sign : check to examine sign of input see table after function header for set values of these case flags check_sign = i_pos (make sure input is positive) check_sign = i_nonneg (make sure input is non-negative) check_sign = i_neg (make sure input is negative) check_sign = i_nonpos (make sure input is non-positive) check_sign = i_nonzero (make sure input is non-zero) check_sign = i_zero (make sure input is zero) any other value of check_sign (esp. 0) results in no check check_sign i_pos = 1; i_nonneg = 2; i_neg = -1; i_nonpos = -2; i_nonzero = 3; i_zero = -3; check_int : check to see if input value is an integer if = 1, then check to make sure input is an integer any other value, perform no check if the dimensions num_rows or num_columns are set to zero, no check as to that dimension of the matrix is made. Kenneth Beers Massachusetts Institute of Technology Department of Chemical Engineering 7/2/2001 Version as of 7/21/2001 function [iflag_assert,message] = assert_matrix( ... i_error,value,name,func_name, ... num_rows,num_columns, ... check_real,check_sign,check_int); First, set case values of check integer flags. check_real i_real = 1; i_imag = -1; check_sign i_pos = 1; i_nonneg = 2; i_neg = -1; i_nonpos = -2; i_nonzero = 3; i_zero = -3; iflag_assert = 0; message = 'false'; Check to make sure input is numerical and not a string. if(~isnumeric(value)) message = [ func_name, ': ', ... name, ' is not numeric']; iflag_assert = -1; if(i_error ~= 0) if(i_error > 1) save dump_error.mat; end error(message); else return; end end Check to see if it is a matrix of the proper length. if it is a multidimensional array if(length(size(value)) > 2) message = [ func_name, ': ', ... name, ' has too many subscripts']; iflag_assert = -2; if(i_error ~= 0) if(i_error > 1) save dump_error.mat; end error(message); else return; end end check that value has the proper number of rows if(num_rows ~= 0) if(size(value,1) ~= num_rows) message = [ func_name, ': ', ... name, ' has the wrong number of rows']; iflag_assert = -2; if(i_error ~= 0) if(i_error > 1) save dump_error.mat; end error(message); else return; end end end check that value has the proper number of columns if(num_columns ~= 0) if(size(value,2) ~= num_columns) message = [ func_name, ': ', ... name, ' has the wrong number of columns']; iflag_assert = -2; if(i_error ~= 0) if(i_error > 1) save dump_error.mat; end error(message); else return; end end end Then, check to see if all elements are of the proper complex type. switch check_real; case {i_real} if any element of value is not real if(any(~isreal(value))) message = [ func_name, ': ', ... name, ' is not real']; iflag_assert = -3; if(i_error ~= 0) if(i_error > 1) save dump_error.mat; end error(message); else return; end end case {i_imag} if any element of value is not purely imaginary if(any(real(value))) message = [ func_name, ': ', ... name, ' is not imaginary']; iflag_assert = -3; if(i_error ~= 0) if(i_error > 1) save dump_error.mat; end error(message); else return; end end end Next, check sign. switch check_sign; case {i_pos} if any element of value is not positive if(any(value <= 0)) message = [ func_name, ': ', ... name, ' is not positive']; iflag_assert = -4; if(i_error ~= 0) if(i_error > 1) save dump_error.mat; end error(message); else return; end end case {i_nonneg} if any element of value is negative if(any(value < 0)) message = [ func_name, ': ', ... name, ' is not non-negative']; iflag_assert = -4; if(i_error ~= 0) if(i_error > 1) save dump_error.mat; end error(message); else return; end end case {i_neg} if any element of value is not negative if(any(value >= 0)) message = [ func_name, ': ', ... name, ' is not negative']; iflag_assert = -4; if(i_error ~= 0) if(i_error > 1) save dump_error.mat; end error(message); else return; end end case {i_nonpos} if any element of value is positive if(any(value > 0)) message = [ func_name, ': ', ... name, ' is not non-positive']; iflag_assert = -4; if(i_error ~= 0) if(i_error > 1) save dump_error.mat; end error(message); else return; end end case {i_nonzero} if any element of value is zero if(any(value == 0)) message = [ func_name, ': ', ... name, 'is not non-zero']; iflag_assert = -4; if(i_error ~= 0) if(i_error > 1) save dump_error.mat; end error(message); else return; end end case {i_zero} if any element of value is non-zero if(any(value ~= 0)) message = [ func_name, ': ', ... name, ' is not zero']; iflag_assert = -4; if(i_error ~= 0) if(i_error > 1) save dump_error.mat; end error(message); else return; end end end Finally, check to make sure it is an integer. if(check_int == 1) if(any(round(value) ~= value)) message = [ func_name, ': ', ... name, ' is not an integer']; iflag_assert = -5; if(i_error ~= 0) if(i_error > 1) save dump_error.mat; end error(message); else return; end end end set flag for succesful passing of all checks iflag_assert = 1; message = 'true'; return; assert_structure.m function [iflag_assert,message] = assert_structure(... i_error,Struct,struct_name,func_name,StructType); This MATLAB m-file performs assertions on a data structure. It makes use of assert_scalar, assert_vector, and assert_matrix for the fields. INPUT : ======= i_error controls what to do if test fails if i_error is non-zero, then use error() MATLAB command to stop execution, otherwise just return the appropriate negative number. if i_error > 1, then dump current state to dump_error.mat before calling error(). Struct This is the structure to be checked struct_name the name of the structure func_name the name of the function making the assertion StructType this is a structure that contains the typing data for each field. .num_fields is the total number of fields Then, for i = 1,2, ..., StructType.num_fields, we have : .field(i).name the name of the field .field(i).is_numeric if non-zero, then field is numeric .field(i).num_rows # of rows in field .field(i).num_columns # of columns in field .field(i).check_real value of check_real passed to assertion .field(i).check_sign value of check_sign passed to assertion .field(i).check_int value of check_int passed to assertion OUTPUT : ======= iflag_assert an integer flag telling of outcome message a message passed that describes the result of making the assertion Kenneth Beers Massachusetts Institute of Technology Department of Chemical Engineering 7/2/2001 Version as of 7/25/2001 function [iflag_assert,message] = assert_structure(... i_error,Struct,struct_name,func_name,StructType); iflag_assert = 0; message = 'false'; first, check to make sure Struct is a structure if(~isstruct(Struct)) iflag_assert = -1; message = [func_name, ': ', struct_name, ... ' is not a structure']; if(i_error ~= 0) if(i_error > 1); save dump_error.mat; end error(message); else return; end end Now, for each field, perform the required assertion. for ifield = 1:StructType.num_fields set shortcut to current field type FieldType = StructType.field(ifield); check if it exists in Struct if(~isfield(Struct,FieldType.name)) iflag_assert = -2; message = [func_name, ': ', struct_name, ... ' does not contain ', FieldType.name]; if(i_error ~= 0) if(i_error > 1) save dump_error.mat; end error(message); else return; end end extract value of field value = getfield(Struct,FieldType.name); if the field is supposed to be numeric if(FieldType.is_numeric ~= 0) check to make sure field is numeric if(~isnumeric(value)) iflag_assert = -3; message = [func_name, ': ', ... struct_name, '.', FieldType.name, ... ' is not numeric']; if(i_error ~= 0) if(i_error > 1) save dump_error.mat; end error(message); else return; end end decide which assertion statement to use based on array dimension of field value If both num_rows and num_columns are set equal to zero, then no check of the dimension of this field is made. if(and((FieldType.num_rows == 0), ... (FieldType.num_columns == 0))) message = [func_name, ': ', ... struct_name,'.',FieldType.name, ... ' is not checked for dimension']; if(i_error ~= 0) disp(message); end else, peform check of dimension to make sure it is a scalar, vector, or matrix (i.e. a two dimensional array). else check that is is not a multidimensional array if(length(size(value)) > 2) iflag_assert = -4; message = [func_name, ': ', ... struct_name,'.',FieldType.name, ... ' is multidimensional array']; if(i_error ~= 0) if(i_error > 1) save dump_error.mat; end error(message); else return; end else if scalar elseif(and((FieldType.num_rows == 1), ... (FieldType.num_columns == 1))) assert_scalar(i_error,value, ... [struct_name,'.',FieldType.name], ... func_name,FieldType.check_real, ... FieldType.check_sign,FieldType.check_int); else if a column vector elseif (and((FieldType.num_rows > 1), ... (FieldType.num_columns == 1))) dim = FieldType.num_rows; check_column = 1; assert_vector(i_error,value, ... [struct_name,'.',FieldType.name], ... func_name,dim,FieldType.check_real, ... FieldType.check_sign,FieldType.check_int, ... check_column); else if a row vector elseif (and((FieldType.num_rows == 1), ... (FieldType.num_columns > 1))) dim = FieldType.num_columns; check_column = -1; assert_vector(i_error,value, ... [struct_name,'.',FieldType.name], ... func_name,dim,FieldType.check_real, ... FieldType.check_sign,FieldType.check_int, ... check_column); otherwise, a matrix else assert_matrix(i_error,value, ... [struct_name,'.',FieldType.name], ... func_name, ... FieldType.num_rows,FieldType.num_columns, ... FieldType.check_real,FieldType.check_sign, ... FieldType.check_int); end end end end selection of assertion routine if perform check of dimension if (FieldType.is_numeric ~= 0) for loop over fields set return results for succesful assertion iflag_assert = 1; message = 'true'; return; get_input_scalar.m function value = get_input_scalar(prompt, ... check_real,check_sign,check_int); This MATLAB m-file gets from the user an input scalar value of the appropriate type. It asks for input over and over again until a correctly typed input value is entered. Kenneth Beers Massachusetts Institute of Technology Department of Chemical Engineering 7/2/2001 Version as of 7/25/2001 function value = get_input_scalar(prompt, ... check_real,check_sign,check_int); func_name = 'get_input_scalar'; name = 'trial_value'; input_OK = 0; while (input_OK ~= 1) trial_value = input(prompt); [iflag_assert,message] = ... assert_scalar(0,trial_value, ... name,func_name, ... check_real,check_sign,check_int); if(iflag_assert == 1) input_OK = 1; value = trial_value; else disp(message); end end return;
