Computer Organization and Design Chapter 1 Solution

1 Solutions Solution 1.1 1.1.1 Computer used to run large problems and usually accessed via a network: (3) servers 1.1.2 1015 or 250 bytes: (7) petabyte 1.1.3 A class of computers composed of hundred to thousand processors and terabytes of memory and having the highest performance and cost: (5) supercomputers 1.1.4 Today’s science f iction application that probably will be available in near future: (1) virtual worlds 1.1.5 A kind of memory called random access memory: (12) RAM 1.1.6 Part of a computer called central processor unit: (13) CPU 1.1.7 Thousands of processors forming a large cluster: (8) data centers 1.1.8 Microprocessors containing several processors in the same chip: (10) multicore processors 1.1.9 Desktop computer without a screen or keyboard usually accessed via a network: (4) low-end servers 1.1.10 A computer used to running one predetermined application or collection of software: (9) embedded computers 1.1.11 Special language used to describe hardware components: (11) VHDL 1.1.12 Personal computer delivering good performance to single users at low cost: (2) desktop computers 1.1.13 Program that translates statements in high-level language to assembly language: (15) compiler S2 Chapter 1 Solutions 1.1.14 Program that translates symbolic instructions to binary instructions: (21) assembler 1.1.15 High-level language for business data processing: (25) Cobol 1.1.16 Binary language that the processor can understand: (19) machine language 1.1.17 Commands that the processors understand: (17) instruction 1.1.18 High-level language for scientific computation: (26) Fortran 1.1.19 Symbolic representation of machine instructions: (18) assembly language 1.1.20 Interface between user’s program and hardware providing a variety of services and supervision functions: (14) operating system 1.1.21 Software/programs developed by the users: (24) application software 1.1.22 Binary digit (value 0 or 1): (16) bit 1.1.23 Software layer between the application software and the hardware that includes the operating system and the compilers: (23) system software 1.1.24 High-level language used to write application and system software: (20) C 1.1.25 Portable language composed of words and algebraic expressions that must be translated into assembly language before run in a computer: (22) high-level language 1.1.26 1012 or 240 bytes: (6) terabyte Solution 1.2 1.2.1 8 bits × 3 colors = 24 bits/pixel = 3 bytes/pixel. AQ 1 a. Configuration 1: 640 × 480 pixels = 179,200 pixels => 179,200 × 3 = 537,600 bytes/frame Configuration 2: 1280 × 1024 pixels = 1,310,720 pixels => 1,310,720 × 3 = 3,932,160 bytes/frame b. Configuration 1: 1024 × 768 pixels = 786,432 pixels => 786,432 × 3 = 2,359,296 bytes/frame Configuration 2: 2560 × 1600 pixels = 4,096,000 pixels => 4,096,000 × 3 = 12,288,000 bytes/frame Chapter 1 Solutions S3 1.2.2 No. frames = integer part of (Capacity of main memory/bytes per frame) a. Configuration 1: Main memory: 2 GB = 2000 Mbytes. Frame: 537.600 Mbytes => No. frames = 3 Configuration 2: Main memory: 4 GB = 4000 Mbytes. Frame: 3,932.160 Mbytes => No. frames = 1 b. Configuration 1: Main memory: 2 GB = 2000 Mbytes. Frame: 2,359.296 Mbytes => No. frames = 0 Configuration 2: Main memory: 4 GB = 4000 Mbytes. Frame: 12,288 Mbytes => No. frames = 0 1.2.3 File size: 256 Kbytes = 0.256 Mbytes. Same solution for a) and b) Configuration 1: Network speed: 100 Mbit/sec = 12.5 Mbytes/sec. Time = 0.256/12.5 = 20.48 ms Configuration 2: Network speed: 1 Gbit/sec = 125 Mbytes/sec. Time = 0.256/125 = 2.048 ms 1.2.4 a. 2 microseconds from cache ⇒ 20 microseconds from DRAM. b. 2 microseconds from cache ⇒ 20 microseconds from DRAM. 1.2.5 a. 2 microseconds from cache ⇒ 2 ms from Flash memory. b. 2 microseconds from cache ⇒ 4.28 ms from Flash memory. 1.2.5 a. 2 microseconds from cache ⇒ 2 s from magnetic disk. b. 2 microseconds from cache ⇒ 5.7 s from magnetic disk. Solution 1.3 1.3.1 P2 has the highest performance. Instr/sec = f/CPI a. performance of P1 (instructions/sec) = 3 × 109/1.5 = 2 × 109 performance of P2 (instructions/sec) = 2.5 × 109/1.0 = 2.5 × 109 performance of P3 (instructions/sec) = 4 × 109/2.2 = 1.8 × 109 b. performance of P1 (instructions/sec) = 2 × 109/1.2 = 1.66 × 109 performance of P2 (instructions/sec) = 3 × 109/0.8 = 3.75 × 109 performance of P3 (instructions/sec) = 4 × 109/2 = 2 × 109 AQ 2 S4 Chapter 1 Solutions 1.3.2 No. cycles = time × clock rate time = (No. Instr × CPI)/clock rate, then No. instructions = No. cycles/CPI a. cycles(P1) = 10 × 3 × 109 = 30 × 109 s cycles(P2) = 10 × 2.5 × 109 = 25 × 109 s cycles(P3) = 10 × 4 × 109 = 40 × 109 s No. instructions(P1) = 30 × 109/1.5 = 20 × 109 No. instructions(P2) = 25 × 109/1 = 25 × 109 No. instructions(P3) = 40 × 109/2.2 = 18.18 × 109 b. cycles(P1) = 10 × 2 × 109 = 20 × 109 s cycles(P2) = 10 × 3 × 109 = 30 × 109 s cycles(P3) = 10 × 4 × 109 = 40 × 109 s No. instructions(P1) = 20 × 109/1.2 = 16.66 × 109 No. instructions(P2) = 30 × 109/0.8 = 37.5 × 109 No. instructions(P3) = 40 × 109/2 = 20 × 109 1.3.3 time a. new = timeold × 0.7 = 7 s CPInew = CPIold × 1.2, then CPI(P1) = 1.8, CPI(P2) = 1.2, CPI(P3) = 2.6 f = No. Instr × CPI/time, then AQ 3 f(P1) = 20 × 109 × 1.8 / 7 = 5.14 GHz f(P2) = 25 × 109 × 1.2 / 7 = 4.28 GHz f(P1) = 18.18 × 109 × 2.6 / 7 = 6.75 GHz b. CPInew = CPIold × 1.2, then CPI(P1) = 1.44, CPI(P2) = 0.96, CPI(P3) = 2.4 f = No. Instr × CPI/time, then f(P1) = 16.66 × 109 × 1.44/7 = 3.42 GHz f(P2) = 37.5 × 109 × 0.96/7 = 5.14 GHz f(P1) = 20 × 109 × 2.4/7 = 6.85 GHz 1.3.4 IPC = 1/CPI = No. instr/(time × clock rate) a. IPC(P1) = 0.95 IPC(P2) = 1.2 IPC(P3) = 2.5 b. IPC(P1) = 2 IPC(P2) = 1.25 IPC(P3) = 0.89 1.3.5 a. Timenew/Timeold = 7/10 = 0.7. So fnew = fold/0.7 = 2.5 GHz/0.7 = 3.57 GHz. b. Timenew/Timeold = 5/8 = 0.625. So fnew = fold/0.625 = 4.8 GHz. Chapter 1 Solutions 1.3.6 a. Timenew/Timeold = 9/10 = 0.9. Then Instructionsnew = Instructionsold × 0.9 = 30 × 109 × 0.9 = 27 × 109. b. Timenew/Timeold = 7/8 = 0.875. Then Instructionsnew = Instructionsold × 0.875 = 26.25 × 109. Solution 1.4 1.4.1 Class A: 105 instr. Class B: 2 × 105 instr. Class C: 5 × 105 instr. Class D: 2 × 105 instr. Time = No. instr × CPI/clock rate a. Total time P1 = (105 + 2 × 105 × 2 + 5 × 105 × 3 + 2 × 105 × 3)/(2.5 × 109) = 10.4 × 10−4 s Total time P2 = (105 × 2 + 2 × 105 × 2 + 5 × 105 × 2 + 2 × 105 × 2)/(3 × 109) = 6.66 × 10−4 s b. Total time P1 = (105 × 2 + 2 × 105 × 1.5 + 5 × 105 × 2 + 2 × 105)/(2.5 × 109) = 6.8 × 10−4 s Total time P2 = (105 + 2 × 105 × 2 + 5 × 105 + 2 × 105)/(3 × 109) = 4 × 10−4 s 1.4.2 CPI = time × clock rate/No. instr a. CPI (P1) = 10.4 × 10−4 × 2.5 × 109/106 = 2.6 CPI (P2) = 6.66 × 10−4 × 3 × 109/106 = 2.0 b. CPI (P1) = 6.8 × 10−4 × 2.5 × 109/106 = 1.7 CPI (P2) = 4 × 10−4 × 3 × 109/106 = 1.2 1.4.3 a. clock cycles (P1) = 105 × 1 + 2 × 105 × 2 + 5 × 105 × 3 + 2 × 105 × 3 = 26 × 105 clock cycles (P2) = 105 × 2 + 2 × 105 × 2 + 5 × 105 × 2 + 2 × 105 × 2 = 20 × 105 b. clock cycles (P1) = 17 × 105 clock cycles (P2) = 12 × 105 1.4.4 a. (650 × 1 + 100 × 5 + 600 × 5 + 50 × 2) × 0.5 × 10–9 = 2,125 ns b. (750 × 1 + 250 × 5 + 500 × 5 + 500 × 2) × 0.5 × 10–9 = 2,750 ns 1.4.5 CPI = time × clock rate/No. instr a. CPI = 2,125 × 10–9 × 2 × 109/1,400 = 3.03 b. CPI = 2,750 × 10–9 × 2 × 109/2,000 = 2.75 S5 S6 Chapter 1 Solutions 1.4.6 a. Time = (650 × 1 + 100 × 5 + 300 × 5 + 50 × 2) × 0.5 × 10–9 = 1,375 ns Speedup = 2,125 ns/1,375 ns = 1.54 CPI = 1,375 × 10–9 × 2 × 109/1,100 = 2.5 b. Time = (750 × 1 + 250 × 5 + 250 × 5 + 500 × 2) × 0.5 × 10–9 = 2,125 ns Speedup = 2,750 ns/2,125 ns = 1.29 CPI = 2,125 × 10–9 × 2 × 109/1,750 = 2.43 Solution 1.5 1.5.1 a. P1: 2 × 109 inst/sec, P2: 2 × 109 inst/sec b. P1: 2 × 109 inst/sec, P2: 3 × 109 inst/sec 1.5.2 a. T(P2)/T(P1) = 4/7; b. T(P2)/T(P1 )= 4.66/5; P2 is 1.07 times faster than P1 P2 is 1.75 times faster than P1 1.5.3 a. T(P2)/T(P1) = 4.5/8; b. T(P2)/T(P1) = 5.33/5.5; P2 is 1.03 times faster than P1 P2 is 1.77 times faster than P1 1.5.4 a. 2.91 µs b. 2.50 µs 1.5.5 a. 0.78 µs b. 0.90 µs 1.5.6 a. T = 0.68µs => 1.14 times faster b. T = 0.75µs => 1.20 times faster Chapter 1 Solutions Solution 1.6 1.6.1 CPI = Texec × f/No. Instr Compiler A CPI Compiler B CPI a. 1.8 1.5 b. 1.1 1.25 1.6.2 f A/fB = (No. Instr(A) ´ CPI(A))/(No. Instr(B) ´ CPI(B)) a. fA/fB = 1 b. fA/fB = 0.73 1.6.3 Speedup vs. Compiler A Speedup vs. Compiler B a. Tnew/TA = 0.36 Tnew/TB = 0.36 b. Tnew/TA = 0.6 Tnew/TB = 0.44 1.6.4 P1 Peak P2 Peak a. 4 × 109 Inst/s 2 × 109 Inst/s b. 4 × 109 Inst/s 3 × 109 Inst/s 1.6.5 Speedup, P1 versus P2: a. T1/T2 = 1.9 b. T1/T2 = 1.5 1.6.6 a. 4.37 GHz b. 6 GHz Solution 1.7 1.7.1 Geometric mean clock rate ratio = (1.28 × 1.56 × 2.64 × 3.03 × 10.00 × 1.80 × 0.74)1/7 = 2.15 Geometric mean power ratio = (1.24 × 1.20 × 2.06 × 2.88 × 2.59 × 1.37 × 0.92)1/7 = 1.62 S7 S8 Chapter 1 Solutions 1.7.2 Largest clock rate ratio = 2000 MHz/200 MHz = 10 (Pentium Pro to Pentium 4 Willamette) Largest power ratio = 29.1 W/10.1 W = 2.88 (Pentium to Pentium Pro) 1.7.3 Clock rate: 2.667 × 109/12.5 × 106 = 213.36 Power: 95 W/3.3 W = 28.78 1.7.4 C = P/V2 × clock rate 80286: C = 0.0105 × 10−6 80386: C = 0.01025 × 10−6 80486: C = 0.00784 × 10−6 Pentium: C = 0.00612 × 10−6 Pentium Pro: C = 0.0133 × 10−6 Pentium 4 Willamette: C = 0.0122 ×10−6 Pentium 4 Prescott: C = 0.00183 × 10−6 Core 2: C = 0.0294 ×10−6 1.7.5 3.3/1.75 = 1.78 (Pentium Pro to Pentium 4 Willamette) 1.7.6 Pentium to Pentium Pro: 3.3/5 = 0.66 Pentium Pro to Pentium 4 Willamette: 1.75/3.3 = 0.53 Pentium 4 Willamette to Pentium 4 Prescott: 1.25/1.75 = 0.71 Pentium 4 Prescott to Core 2: 1.1/1.25 = 0.88 Geometric mean = 0.68 Solution 1.8 1.8.1 Power = V2 × clock rate × C. Power2 = 0.9 Power1 a. C2/C1 = 0.9 × 1.752 × 1.5 × 109/(1.22 × 2 × 109) = 1.43 b. C2/C1 = 0.9 × 1.12 × 3 × 109/(0.82 × 4 × 109) = 1.27 1.8.2 Power 2/Power1 = V22 × clock rate2/(V21 × clock rate1) a. Power2/Power1 = 0.62 => Reduction of 38% b. Power2/Power1 = 0.7 => Reduction of 30% Chapter 1 Solutions 1.8.3 Power2 = V2 2 × 2 × 109 × 0.8 × C1 = 0.6 × Power1 Power1 = 1.752 × 1.5 × 109 × C1 a. V22 × 2 × 109 × 0.8 × C1 = 0.6 × 1.752 × 1.5 × 109 × C1 V2 =((0.6 × 1.752 × 1.5)/(2 × 0.8))1/2 = 1.31 V Power2 = V2 2 × 4 × 109 × 0.8 × C1 = 0.6 × Power1 Power1 = 1.12 × 3 × 109 × C1 b. V22 × 4 × 109 × 0.8 × C1 = 0.6 × 1.12 × 3 × 109 × C1 V2 = ((0.6 × 1.12 × 3)/(4 × 0.8))1/2 = 0.825 V 1.8.4 a. Power new = 1 × Cold × V2 old /(21/2)2 × clock rate × 1.15. Thus, Powernew = 0.575 Powerold b. Power new = 1 × Cold × V2 old /(21/4)2 × clock rate × 1.2. Thus, Powernew = 0.848 Powerold 1.8.5 a. 1/21/2 = 0.7 b. 1/21/4 = 0.8 1.8.6 a. Voltage = 1.1 × 1/21/2 = 0.77 V. Clock rate = 2.667 × 1.15 = 3.067 GHz. b. Voltage = 1.1 × 1/21/4 = 0.92 V. Clock rate = 2.667 × 1.2 = 3.2 GHz. Solution 1.9 1.9.1 a. 10/60 × 100 = 16.6% b. 60/150 × 100 = 40% 1.9.2 Ptotal_new = 0.9 Ptotal_old Pstatic_new/Pstatic_old = Vnew/Vold a. 1.08 V b. 0.81 V S9 S10 Chapter 1 Solutions 1.9.3 a. Power st/Powerdyn = 10/50 = 0.2 b. Power st/Powerdyn = 60/90 = 0.66 1.9.4 Power st/Powerdyn = 0.6 => Powerst = 0.6 × Powerdyn a. Power st = 0.6 × 35 W = 21 W b. Power st = 0.6 × 30 W = 18 W 1.9.5 1.2 V 1.0 V 0.8 V a. Pst = 12.5 W Pdyn = 62.5 W Pst = 10 W Pdyn = 50 W Pst = 5.8 W Pdyn = 29.2 W b. Pst = 24.8 W Pdyn = 37.2 W Pst = 20 W Pdyn = 30 W Pst = 12 W Pdyn = 18 W 1.9.6 a. 29.15 b. 23.32 Solution 1.10 1.10.1 a. b. Processors Instructions per Processor Total Instructions 1 4096 4096 2 2048 4096 4 1024 4096 8 512 4096 Processors Instructions per Processor Total Instructions 1 4096 4096 2 2048 4096 4 1024 4096 8 512 4096 Chapter 1 Solutions 1.10.2 a. Processors 4.096 2 2.368 4 1.504 8 b. Execution Time (µs) 1 Processors 1.152 Execution Time (µs) 1 4.096 2 2.688 4 1.664 8 0.992 1.10.3 a. Processors 1 5.376 2 3.008 4 1.824 8 b. Execution Time (µs) Processors 1.312 Execution Time (µs) 1 5.376 2 3.328 4 1.984 8 1.152 1.10.4 a. Cores 1 4.00 2 2.33 4 1.50 8 b. Execution Time (s) @ 3 GHz Cores 1.08 Execution Time (s) @ 3 GHz 1 3.33 2 2.00 4 1.16 8 0.71 S11 S12 Chapter 1 Solutions 1.10.5 a. Cores Power (W) per Core @ 3 GHz Power (W) per Core @ 500 MHz Power (W) @ 3 GHz 1 15 0.625 15 0.625 2 15 0.625 30 1.25 4 15 0.625 60 2.5 8 15 0.625 120 b. Cores Power (W) per Core @ 3 GHz Power (W) per Core @ 500 MHz 5 Power (W) @ 3 GHz Power (W) @ 500 MHz 1 15 0.625 15 0.625 2 15 0.625 30 1.25 4 15 0.625 60 2.5 8 15 0.625 120 5 1.10.6 a. Processors 1 b. CPI for 1 Core 1.2 2 0.7 4 0.45 8 AQ 4 Power (W) @ 500 MHz Processors 0.32 CPI for 1 Core 1 1 2 0.6 4 0.35 8 0.21 Solution 1.11 1.11.1 Wafer area = p × (d/2)2 a. wafer area = π × 7.52 = 176.7 cm2 b. wafer area = π × 102 = 314.2 cm2 Die area = wafer area/dies per wafer a. Die area = 176.7/84 = 2.10 cm2 b. Die area = 314.2/100 = 3.14 cm2 Chapter 1 Solutions Yield = 1/(1 + (defect per area × die area)/2)2 a. Yield = 0.96 b. Yield = 0.91 1.11.2 Cost per die = cost per wafer/(dies per wafer × yield) a. Cost per die = 0.15 b. Cost per die = 0.16 1.11.3 a. Dies per wafer = 1.1 × 84 = 92 Defects per area = 1.15 × 0.02 = 0.023 defects/cm2 Die area = wafer area/Dies per wafer = 176.7/92 = 1.92 cm2 Yield = 0.96 b. Dies per wafer = 1.1 × 100 = 110 Defects per area = 1.15 × 0.031 = 0.036 defects/cm2 Die area = wafer area/Dies per wafer = 314.2/110 = 2.86 cm2 Yield = 0.90 1.11.4 Yield = 1/(1 + (defect per area × die area)/2)2 Then defect per area = (2/die area)(y−1/2 − 1) Replacing values for T1 and T2 we get: T1: defects per area = 0.00085 defects/mm2 = 0.085 defects/cm2 T2: defects per area = 0.00060 defects/mm2 = 0.060 defects/cm2 T3: defects per area = 0.00043 defects/mm2 = 0.043 defects/cm2 T4: defects per area = 0.00026 defects/mm2 = 0.026 defects/cm2 1.11.5 no solution provided Solution 1.12 1.12.1 CPI = clock rate × CPU time/instr count clock rate = 1/cycle time = 3 GHz a. CPI(bzip2) = 3 × 109 × 750/(2,389 × 109) = 0.94 b. CPI(go) = 3 × 109 × 700/(1,658 × 109) = 1.26 1.12.2 SPECratio = ref. time/execution time a. SPECratio(bzip2) = 9,650/750 = 12.86 b. SPECratio(go) = 10,490/700 = 14.98 S13 S14 Chapter 1 Solutions 1.12.3 (12.86 × 14.98)1/2 = 13.88 1.12.4 CPU time = No. instr × CPI/clock rate If CPI and clock rate do not change, the CPU time increase is equal to the increase in the of number of instructions, that is, 10%. 1.12.5 CPU time(before) = No. instr × CPI/clock rate CPU time(after) = 1.1 × No. instr × 1.05 × CPI/clock rate CPU times(after)/CPU time(before) = 1.1 × 1.05 = 1.155 Thus, CPU time is increased by 15.5%. 1.12.6 SPECratio = reference time/CPU time SPECratio(after)/SPECratio(before) = CPU time(before)/CPU time(after) = 1/1.1555 = 0.86. Thus, the SPECratio is decreased by 14%. Solution 1.13 1.13.1 CPI = (CPU time × clock rate)/No. instr a. CPI = 700 × 4 × 109/(0.85 × 2,389 × 109) = 1.37 b. CPI = 620 × 4 × 109/(0.85 × 1,658 × 109) = 1.75 1.13.2 Clock rate ratio = 4 GHz/3 GHz = 1.33 a. CPI @ 4 GHz = 1.37, CPI @ 3 GHz = 0.94, ratio = 1.45 b. CPI @ 4 GHz = 1.75, CPI @ 3 GHz = 1.26, ratio = 1.38 They are different because although the number of instructions has been reduced by 15%, the CPU time has been reduced by a lower percentage. 1.13.3 a. 700/750 = 0.933. CPU time reduction: 6.7% b. 620/700 = 0.886. CPU time reduction: 11.4% 1.13.4 No. instr = CPU time × clock rate/CPI a. No. instr = 960 × 0.9 × 4 × 109/1.61 = 2,146 × 109 b. No. instr = 690 × 0.9 × 4 × 109/1.79 = 1,387 × 109 1.13.5 Clock rate = no. instr × CPI/CPU time. Clock ratenew = no. instr × CPI/0.9 × CPU time = 1/0.9 clock rateold = 3.33 GHz Chapter 1 Solutions 1.13.6 Clock rate = no. instr × CPI/CPU time. Clock ratenew = no. instr × 0.85 × CPI/0.80 CPU time = 0.85/0.80 clock rateold = 3.18 GHz Solution 1.14 1.14.1 No. instr = 106 a. T(P1) = 5 × 106 × 0.9/(4 × 109) = 1.125 × 10–3 s T(P2) = 106 × 0.75/(3 × 109) = 0.25 × 10–3 s clock rate (P1) > clock rate (P2), performance (P1) < performance (P2) b. T(P1) = 3 × 106 × 1.1/(3 × 109) = 1.1 × 10–3 s T(P2) = 0.5 × 106 × 1/(2.5 × 109) = 0.2 × 10–3 s clock rate (P1) > clock rate (P2), performance (P1) < performance (P2) 1.14.2 a. 106 instructions, T(P1) = No. Intr × CPI/clock rate T(P1) = 2.25 × 10–4 s T(P2) = N × 0.75/(3 × 109) then N = 9 × 105 b. 106 instructions, T(P1) = No. Intr × CPI/clock rate T(P1) = 3.66 × 10–4 s T(P2) = N × 1/(3 × 109) then N = 9.15 × 105 1.14.3 MIPS = Clock rate × 10−6/CPI a. MIPS(P1) = 4 × 109 × 10–6/0.9 = 4.44 × 103 MIPS(P2) = 3 × 109 × 10–6/0.75 = 4.0 × 103 MIPS(P1) > MIPS(P2), performance(P1) < performance(P2) (from 1.14.1) b. MIPS(P1) = 3 × 109 × 10–6/1.1 = 2.72 × 103 MIPS(P2) = 2.5 × 109 × 10–6/1 = 2.5 × 103 MIPS(P1) > MIPS(P2), performance(P1) < performance(P2) (from 1.14.1) 1.14.4 MFLOPS = No. FP operations × 10−6/T a. T(P1) = (5 × 105 × 0.75 + 4 × 105 × 1 + 10 × 105 × 1.5)/(4 × 109) = 5.86 × 10–4 s MFLOPS(P1) = 4 × 105 × 10–6/(5.86 × 10–4 ) = 6.82 × 102 T(P2) = (2 × 106 × 1.25 + 2 × 106 × 0.8 + 1 × 106 × 1.25)/(3 × 109) = 1.78 × 10–3 s MFLOPS(P1) = 3 × 105 × 10–6/(1.78 × 10–3) = 1.68 × 102 b. T(P1) = (1.5 × 106 × 1.5 + 1.5 × 106 × 1 + 2 × 106 × 2)/(4 × 109) = 1.93 × 10–3 s MFLOPS(P1) = 1.5 × 106 × 10–6/(1.93 × 10–3) = 0.77 × 102 T(P2) = (0.8 × 106 × 1.25 + 0.6 × 106 × 1 + 0.6 × 106 × 2.5)/(3 × 109) = 1.03 × 10–3 s MFLOPS(P2) = 0.6 × 106 × 10–6/(1.03 × 10–3) = 5.82 × 102 S15 S16 Chapter 1 Solutions 1.14.5 a. T(P1) = (5 × 105 × 0.75 + 4 × 105 × 1 + 10 × 105 × 1.5)/(4 × 109) = 5.86 × 10–4 s CPI(P1) = 5.86 × 10–4 × 4 × 109/106 = 2.27 MIPS(P1) = 4 × 109/(2.27 ×106) = 1.76 × 103 T(P2) = (2 × 106 × 1.25 + 2 × 106 × 0.8 + 1 × 106 × 1.25)/(3 × 109) = 1.78 × 10–3 s CPI(P2) = 1.78 × 10–3 × 3 × 109/(5 × 106) = 1.068 s MIPS(P2) = 3 × 109/(1.068 × 106) = 2.78 × 103 b. T(P1) = (1.5 × 106 × 1.5 + 1.5 × 106 × 1 + 2 × 106 × 2)/(4 × 109) = 1.93 × 10–3 s CPI(P1) = 1.93 × 10–3 × 4 × 109/(5 × 106) = 1.54 MIPS(P1) = 4 × 109/(1.54 × 106) = 2.59 × 103 T(P2) = (0.8 × 106 × 1.25 + 0.6 × 106 × 1 + 0.6 × 106 × 2.5)/(3 × 109) = 1.03 × 10–3 s CPI(P2) = 1.03 × 10–3 × 3 × 109/(2 ×106) = 1.54 MIPS(P1) = 3 × 109/(1.54 × 106) = 1.94 × 103 1.14.6 a. T(P1) = 5.86 × 10–4 s (see problem 1.14.5) performance(P1) = 1/T(P1) = 1.7 × 103 T(P2) = 1.78 × 10–3 s (see problem 1.14.5) performance(P2) = 1/T(P2) = 5.6 × 102 perf(P1) > perf(P2), MIPS(P1) > MIPS(P2), MFLOPS(P1) < MFLOPS(P2) b. T(P1) = 1.93 × 10–3 s (see problem 1.14.5) performance(P1) = 1/T(P1) = 5.1 × 102 T(P2) = 1.03 × 10–3 s (see problem 1.14.5) performance(P2) = 1/T(P2) = 9.7 × 102 perf(P1) < perf(P2), MIPS(P1) < MIPS(P2), MFLOPS(P1) > MFLOPS(P2) Solution 1.15 1.15.1 a. Tfp = 70 × 0.8 = 56 s. Tnew= 56 + 85 + 55 + 40 = 236 s. Reduction: 5.6% b. Tfp = 40 × 0.8 = 32 s. Tnew= 32 + 90 + 60 + 20 = 202 s. Reduction: 3.8% 1.15.2 a. Tnew = 250 × 0.8 = 200 s, Tfp + Tl/s + Tbranch = 165 s, Tint = 35 s. Reduction time INT: 58.8% b. Tnew = 210 × 0.8 = 168 s, Tfp + Tl/s + Tbranch = 120 s, Tint = 48 s. Reduction time INT: 46.6% Chapter 1 Solutions 1.15.3 a. Tnew = 250 × 0.8 = 200 s, Tfp + Tint + Tl/s = 210 s. NO b. Tnew = 210 × 0.8 = 168 s, Tfp + Tint + Tl/s = 190 s. NO 1.15.4 Clock cyles = CPIfp × No. FP instr. + CPIint × No. INT instr. + CPIl/s × No. L/S instr. + CPIbranch × No. branch instr. Tcpu = clock cycles/clock rate = clock cycles/2 × 109 a. 2 processors: clock cycles = 4,096 × 106; Tcpu = 2.048 s b. 16 processors: clock cycles = 512 × 106; Tcpu = 0.256 s To half the number of clock cycles by improving the CPI of FP instructions: CPIimproved fp × No. FP instr. + CPIint × No. INT instr. + CPIl/s × No. L/S instr. + CPIbranch × No. branch instr. = clock cycles/2 CPIimproved fp = (clock cycles/2 − (CPIint × No. INT instr. + CPIl/s × No. L/S instr. + CPIbranch × No. branch instr.))/No. FP instr. a. 2 processors: CPIimproved fp = (2,048 – 3,816)/280 < 0 ==> not possible b. 16 processors: CPIimproved fp = (256 – 462)/50 < 0 ==> not possible 1.15.5 Using the clock cycle data from 1.15.4: To half the number of clock cycles improving the CPI of L/S instructions: CPIfp × No. FP instr. + CPIint × No. INT instr. + CPIimproved l/s × No. L/S instr. + CPIbranch × No. branch instr. = clock cycles/2 CPIimproved l/s = (clock cycles/2 − (CPIfp × No. FP instr. + CPIint × No. INT instr. + CPIbranch × No. branch instr.))/No. L/S instr. a. 2 processors: CPIimproved l/s = (2,048 – 1,536)/640 = 0.8 b. 16 processors: CPIimproved l/s = (256 – 198)/80 = 0.725 1.15.6 Clock cyles = CPIfp × No. FP instr. + CPIint × No. INT instr. + CPIl/s × No. L/S instr. + CPIbranch × No. branch instr. Tcpu = clock cycles/clock rate = clock cycles/2 × 109 S17 S18 Chapter 1 Solutions CPIint = 0.6 × 1 = 0.6; CPIfp = 0.6 × 1 = 0.6; CPIl/s = 0.7 × 4 = 2.8; CPIbranch = 0.7 × 2 = 1.4 a. 2 processors: Tcpu (before improv.) = 2.048 s; Tcpu (after improv.) = 1.370 s b. 16 processors: Tcpu (before improv.) = 0.256 s; Tcpu (after improv.) = 0.171 s Solution 1.16 1.16.1 Without reduction in any routine: a. total time 4 proc = 102 ms b. total time 32 proc = 18 ms Reducing time in routines A, C, and E: a. 4 proc: T(A) = 10.2 ms, T(C) = 5.1 ms, T(E) = 2.5 ms, total time = 98.8 ms ==> reduction = 3.1% b. 32 proc: T(A) = 1.7 ns, T(C) = 0.85 ns, T(E) = 1.7 ms, total time = 17.2 ms ==> reduction = 4.4% 1.16.2 a. 4 proc: T(B) = 40.5 ms, total time = 97.5 ms ==> reduction = 4.4% b. 32 proc: T(B) = 6.3 ms, total time = 17.3 ms ==> reduction = 3.8% 1.16.3 a. 4 proc: T(D) = 32.4 ms, total time = 98.4 ms ==> reduction = 3.5% b. 32 proc: T(D) = 5.4 ms, total time = 17.4 ms ==> reduction = 3.3% 1.16.4 No. Processors AQ 5 Computing Time Computing Time Ratio Routing Time Ratio 1.18 2 201 ms 4 131 ms 0.65 8 85 ms 0.65 1.31 16 56 ms 0.66 1.29 32 35 ms 0.62 1.05 64 18.5 ms 0.53 1.13 Chapter 1 Solutions 1.16.5 Geometric mean of computing time ratios = 0.62. Multiplying this by the computing time for a 64-processor system gives a computing time for a 128-processor system of 11.474 ms. Geometric mean of routing time ratios = 1.19. Multiplying this by the routing time for a 64-processor system gives a routing time for a 128-processor system of 30.9 ms. 1.16.6 Computing time = 201/0.62 = 324 ms. Routing time = 0, since no communication is required. S19 Author Query AQ 1: Page S2: As meant t/o? AQ 2: Page S3: As meant t/o? AQ 3: Page S4: Close up t/o? AQ 4: Page S12: Inserted heading OK? AQ 5: Page S18: Blank cells as meant?
