Survey of the Planets

A Survey of the Planets Mercury Difficult to observe - never more than 28 degree angle from the Sun. Mariner 10 flyby (1974) Found cratered terrain. Messenger Orbiter (Launch 2004; Orbit 2009) Rotation is 59 days (discovered by MIT) Thin sodium (Na) atmosphere - recent discovery No Moons. Venus A near twin to Earth in size and mass Dense CO2 atmosphere Surface pressure ~90 bars (earth atm = 1 bar) Surface temperature ~750 K (0 K = -273 C) Retrograde rotation, 243 days (Prograde rotation is West -> East) (Retrograde rotation is East ->West) Surface volcanic features, vast resurfacing of entire planet about 1 billion years ago. No Moons. Mariner, Pioneer, Venera: Flybys, orbiters, landers (1960s, 1970s) Magellan Mission 1989 - Radar mapping to 100m resolution (headed by MIT). Earth N2,O2,H20 atmosphere Surface area 71% H20 Prograde rotation 23hr 56min 04.1sec =>Why do we use a 24 hour clock? Weathered, tectonic, volcanic, and cratered surface. One satellite (large relative to its primary). Moon Cratered surface - formed by impacts Mare - (“seas”) formed by lava flows Regolith - soil Age: 4.5 Gy - same as rest of solar system (Gy = 109 years) 0 - 0.5 Gy -heavy bombardment 1.0 - 2.5 Gy - lava flows forming Mare 2.5-4.5 Gy - less frequent bombardment Origin of the Moon? Mars Thin CO2 atmosphere Surface Pressure ~6 mbar (0.6% of Earth) Surface Temperature: 190 to 240 K (-83 C to -33 C) Rotation is 24.5 hours, prograde Cratered surface, volcanoes, chasms Evidence for water flow! (Where is it now?) Polar caps - CO2 and H20 Missions: Mariner 9 (1971) - first orbiter Viking 1+2 orbiters and landers (1976) No evidence for life Mars Meteorites (1996): Evidence for life? Not. Mars Observer (lost in 1993). Mars Pathfinder (1997). Mars Global Surveyor (1997). Mars Climate Orbiter (lost in 1999). Mars Polar Lander (lost in 1999). Mars Odyssey (2001) Mars Express (Europe, 2003) Mars Exploration Rovers – landing 2004. (Spirit & Opportunity) Mars Reconnaissance Orbiter (arrive 2006) Two small satellites, Phobos and Deimos Asteroids First one (Ceres) discovered in 1801 Location (2.8 AU) fit Bode!s Rule There are >10,000 known asteroids Most orbit between Mars and Jupiter, region called the “asteroid belt” Sizes range from boulders - 1000 km A Disrupted planet? <----No Probably left-over planetesimals from formation of the solar system. Missions: Flybys "Targets of opportunity" 951 Gaspra [12-km] (Galileo 1991) 243 Ida [32-km] (Galileo 1993) 253 Mathilde [52-km] (NEAR 1997) 9969 Braille [2-km] (DS-1 1999) Orbiters: NEAR - launch 1996; arrival 2000. 433 Eros [30-km] near-Earth asteroid. Dawn – to Vesta and Ceres (2007) Sample Return: Hyabusa (MUSES-C) Japan. Destination: 25143 Itokawa Launch 2003, Sample 2005, Return 2007 Jupiter Largest of the Jovian gas giant planets. A “star” that failed. Dynamic atmosphere: H2, He, CH4, NH3 Red Spot - long lived high pressure system (not a hurricane as often described). Rotation 9.8 hours Has a faint ring - discovered by Voyager. Lots of satellites (current count is 16 or more) Galilean satellites (discovered 1610) Ganymede (D=5280 km) Largest moon in the solar system (Larger than Mercury and Pluto!) Icy surface (H2O), some craters. Callisto (D=4840 km, ~Mercury) Heavily cratered rock + ice surface. Europa (D=3130 km, smaller than Moon) Grooved ice terrain, few craters. What does this imply about surface? Evidence for subsurface ocean?? Io (D=3460 km, same as Moon) Most active volcanoes in the solar system. Induced by tidal stresses. Pioneer 10, 11, Voyager 1, 2 flybys (1970s) Galileo Orbiter / Probe (1995-2003). Extensive Galilean satellite tour. Saturn Gas planet, H2, He, CH4, NH3 atmosphere Density < 1 gm / cm3 Complex Ring System Lots of satellites (current count is 18 or more) Titan (D=5120 km, second largest) Has a substantial atmosphere! Composition N2, CH4 Pressure ~1.6 bar Iapetus (D=1440 km) Half-light, half-dark hemispheres How did this occur? Hyperion (D=150 km) Chaotic rotation - it “tumbles” along in its orbit. (Discovered by MIT) Pioneer 11, Voyager 1,2 flybys (1970s, 1980s) Cassini Orbiter Mission Launch 1997 Saturn orbit 2004. (Four year mission.) Huygens Titan Probe Extensive satellite tour. Uranus Discovered 1781 by Herschel Gas planet, H2, CH4 atmosphere [Obliquity - angle between rotation axis and the orbit plane.] Obliquity of Uranus is 98 degrees the planet “lies on its side” in the orbit plane. Ring system discovered 1977 by MIT. (Current count is 11 rings or more.) Lots of satellites (current count is 17 or more) Miranda (D=235 km) Very strange body - once disrupted and then recombined? Voyager 2 (flyby 1986) Neptune Existence first suspected based on perturbations to Uranus! orbit. Discovered near predicted position (1846) A triumph for celestial mechanics. Gas planet, H2, CH4 atmosphere. Ring “arcs” first suspected 1984. Complete ring system confirmed by Voyager 2 (1989). (Five rings known.) Satellites -- current known total is 8 Two prior to Voyager (Nereid, Triton) Voyager discovered six Triton (D=2700 km) In a retrograde orbit! (Captured?) Thin N2, CH4 atmosphere Bright icy (N2, CH4) surface Geyser-like eruptions? Voyager 2 flyby, 1989. Neptune Orbiter MissionConcept studies underway. Pluto Existence suspected based on possible perturbations to Neptune!s orbit. Discovered by Tombaugh (1930) Eccentric orbit - crosses that of Neptune Closer to sun than Neptune 1979-1999 Orbital period is 248 years Diameter (2300 km) too small and distance too far to see surface. Mass too low to have perturbed Neptune Is there a tenth planet? Probable composition -- rock + ice (CH-4, H20) Rotation 6.4 days Large Satellite, Charon (1978, Christy) D=1200 km (more than one-half Pluto!) Synchronous orbit Once-per-century series of eclipses First detected 1985 by RPB Solving for diameters, densities, and mapping Pluto!s surface Thin atmosphere - discovered by MIT (1988) Composition CH4, N2, CO. Multiple missions proposed/approved/cancelled PLUTO NEW HORIZONS - launched 2006 Arrival: 14 July 2015 Comets Small icy, rocky bodies (D<5 km) in highly eccentric orbits. Made of H20,"CH4, NH3 ice? Probably remnant planetesimals stored in the outer regions of the solar system. Called the “Oort cloud” at 10,000 AU. Also the "Kuiper Belt" > 30 AU. Occasionally perturbed into the inner solar system. Orbits altered by Jupiter. Comet Shoemaker-Levy 9 (impact 1994). Display bright heads, long tails due to evaporation of ice when near sun. Example: Comet Halley. 76 year orbit. Last Earth passage 1986. Next return 2062. Recent Bright Comets: Hyukatake (1996) Hale-Bopp (1997) Vega / Giotto flybys of Halley (1986) CONTOUR - multiple flybys (launch failure 2002) Stardust - sample return from comet tail. Launch1999; Wild 2 sample 2004; Return 2006 Deep Impact - Impact probe, test interiors. Launch 2002; Impact comet Tempel 1 2005. Comet Nucleus Sample Return - (2010-2020?) {Hartmann Figure 2-34}
