Section 2.4 Definition: A triangle (symbol ) is the union of three line segments that are determined by three noncollinear points. Each of the three noncollinear points is a vertex. Line segments connecting any two points are the sides. Example 1: C E D A B Classifying Triangles Triangles According to the Equality of the Lengths of their Sides 1. Scalene triangle has no congruent sides. 2. Isosceles triangle has at least two congruent sides. 3. Equilateral triangle has three congruent sides. Question: Is equilateral triangle also an isosceles triangle? Triangles According to the Kind of Angles 1. Acute triangle has three acute angles. 2. Obtuse triangle has one obtuse angle. 3. Right triangle has a right angle. 1. 4. Equiangular triangle has three congruent angles. Example 2: Classify the triangle. a) In ∆ABC , AB = 5 , BC = 5 , and m∠B = 90o . b) In ∆DEF , DE = 5 , EF = 6 , and DF = 7 . Theorem(Angle Sum Theorem): The sum of the measures of the interior angles of a triangle is 180˚. Example 3: In ∆NMQ , m∠N = 40o and m∠M = 55o . Find m∠Q . Corollary: Each angle in an equiangular triangle measures 60˚. Corollary: The acute angles in a right triangle are complementary. Example 4: 57° 49° 49 + 41 = 90 57 + 33 = 90 41° 33° Example 5: ∠B is a right angle in ∆ABC ; m∠A = 43 . Find m∠C . Corollary (Third Angle Theorem): If two angles of one triangle are congruent to two angles of a second triangle, then the third angles of the triangles are congruent. 1 If 4 ∠1 ≅ ∠4 And ∠2 ≅ ∠5 3 2 Then ∠3 ≅ ∠6 5 6 Definition: An exterior angle is formed by one side of a triangle and the extension of another side. Remote interior angles are the interior angles of a triangle that are not adjacent to a given angle. Example 6: In the figure below, ∠CBD is an exterior angle of ∆ABC . ∠A and ∠C are remote interior angles. They will not touch the exterior angles. C A B • D Corollary (Exterior Angle Theorem): The measure of an exterior angel of a triangle is equal to the sum of the measures of the two remote interior angles. Example 7: A surveyor has drawn a triangle on a map. One angle measures 42° and another measures 53°. Find the measure of the third angle. Corollary: There can be at most one right or obtuse angle in a triangle. Example 8: Can a triangle have angles of the following measures? a) 38, 70, and 72 b) 91, 90, and “something” suur suur Example 9: Find the measure of each of the angles below. AB ll CD . B A • • 60° 5 2 • 135° 1 3 C m∠1 = _____ m∠2 = _____ 4 • D m∠3 = _____ m∠4 = _____ m∠5 = _____ Example 10: If AB is perpendicular to BC , find the measure of each angle in the figure below. m∠1 = _____ m∠2 = _____ m∠3 = _____ m∠4 = _____ m∠5 = _____ m∠6 = _____ m∠7 = _____ m∠8 = _____ A 2 36 ° 1 104 °3 5 6 B 4 40 7 ° 8 C Example 11: Given: m ∠ 1 = 8(x + 2) m ∠ 3 = 5x – 3 m ∠ 5 = 5(x + 1) – 2 Find x and measures of angles 1, 2, 3, 4 and 5. x = _____ m∠1 = _____ m∠2 = _____ m∠3 = _____ m∠4 = _____ m∠5 = _____
