Geodynamics - Course Overview

1 Geodynamics (Continuum mechanics applied to geological problems) Lecture 1 Handouts - Course description & reserve list • Instructor background • Student background • Scheduling Mechanics: the study of the motion of matter and the forces that cause such motion. Based on concepts of time, space, force, energy, matter. Applications to point masses, solid bodies familiar from introductory physics. Continuum mechanics - mechanics of parts of "bodies." Continuum - define values of fields (e.g., density) as functions of position, i.e., at points. Mn Example : density ρ (P) = lim Vn → 0 V n Vi —> Sequence of volumes converging on P Mi —> Mass enclosed by Vi Fig. 1_1 2 Breakdown at small V (e.g., gas) Fig. 1_2 Ignore fine structure. Assume: • Continuity: completely fills space (no pores or voids) and has properties describable by continuous functions. [Scale dependent. E.g., sand will be treated as a continuum] • Homogeneity - identical properties at all points [Scale dependent.] • Isotropy - properties same in all directions. [Often not true. e.g., schist] Behavior describable in terms of partial differential equations subject to boundary conditions. All functions will be "well behaved," except at a finite # of surfaces. 3 Logical contradiction between mathematical process of taking limits & physical breakdown of continuum description at small scales ignored. (Assume - fields varying slowly enough that math defined before description falls apart.) At core: Newton's 2nd Law: F = ma, or F -ma = 0. for this course, a = 0 => the governing equation is F = 0! • Applies not just to particles, entire bodies, but to regions within bodies. • Free-body diagram - cut open body (thought experiment), examine forces of interaction between surfaces. Description of forces acting in the continuum - For taking limits, etc, forces/unit area make sense. Consider tractions T: Force/unit area on faces (vector quantities). Units: SI - Pascal (Pa); 1 Pa = 1 N/m2 cgs: dyne/cm2 "geophysics": bar ( 1 atmosphere): 1 bar = 106 dynes/cm2 = 0.1 MPa A general description of the tractions acting on planes of arbitrary orientation requires: • stress - forces of interaction (2nd rank tensor) Newton's 2nd —> τij,j + fi = 0. • strain & rotation - kinematics of motion & deformation (2nd rank tensors) • rheology (constitutive law) - relationship between stress & strain solids - elastic, plastic, brittle fluids - viscous, ideal other - e.g., Silly putty, paint, We will quantify these quantities soon, but first a digression to a concrete example to bring things into focus. When I moved to southern CA ~ 1980, I was impressed by press coverage of a set of law suits pending against various governments (state & local). The question to be settled was who was responsible for an expensive housing development "sliding into the ocean." Briefly, the sequence of events was: 1) "Nature" deposited a terrace (mainly sand) beside the ocean. 2) The highway department made a road cut into the base of the sea cliff to put in a coastal highway. 4 3) Expensive houses were built on top of the terrace. 4) Lawns were watered lavishly. 5) Landslides started wrecking the expensive houses. Fig. 1_3 We will examine the "continuum mechanics" of this situation & come up with some "expert opinion" about responsibility. We need to do two things: first, understand how sand responds to "internal forces," then understand how to describe these forces. Assertion: Sand pile behavior, as a first approximation, is governed by friction. So are earthquake faults. (reading: T & S, pp 351-353) Consider an experiment to measure the frictional behavior of sand. One approach would be to place some sand between a block & a table, subjecting the block to a downward force F and a horizontal force V (in T&S notation). If the block has area A, there is a normal traction σn = F/A and a shear traction τ = V/A 5 Fig. 1_4 Admonton's law (to summarize a lot of experiments) states that the shear force needed to cause sliding is related to the normal force pressing the block down as V = fs F or, in terms of tractions τ = fs σn Digression: One very sensitive way of measuring fs (developed at MIT) is to use an inclined plane & vary the inclination angle θ. Suppose this is done & loading is carried out by varying the # of bricks squeezing the sand. How will θ depend on the # of bricks? Fig. 1_5 6 Another digression: An amazing result from rock mechanics, "Byerlee's law," is that fs is essentially independent of rock type! Fig. 1_6 Now, back to the sand pile. Admonton's law tells us that any time the shear traction on a plane reaches a value of fs σn, the sand pile will fail. The complication is that we no 7 longer have a brick & a bench to work with — what we need is a mathematical description of normal and shear tractions on arbitrary planes in a continuum. We start out with a special description of the tractions on a surface oriented with the coordinate system, then will go on to generalize. It is useful to break tractions into their component parts (normal & shear): Define σij as force/unit area acting on face with normal ni in direction nj. Consider now a small parallelepiped with faces in the co-ordinate planes and dimensions dx1, dx2, and dx3. The tractions on the three faces can be resolved into their Cartesian components, one normal and two tangential to the face on which the traction acts: T(1)i = (σ 11 , σ 12 , σ 13 ) T(2)i = (σ 21 , σ 22 , σ 23 ) T(3)i = (σ 31 , σ 32 , σ 33 ) where T(1)i denotes the traction on the face normal to the axis x1, and so on. The nine components of the tractions form a 3 × 3 matrix ⎛ σ 11 σ 12 σ ij = ⎜ σ 21 σ 22 ⎜ ⎝ σ 31 σ 32 σ 13 ⎞ σ 23 ⎟ ⎟ σ 33 ⎠ where for each component the first subscript denotes the co-ordinate axis to which the surface is normal, and the second subscript denotes the direction in which the component acts. For example, σ 23 denotes the component acting on the face normal to x2 in the direction of x3 . 8 Fig. 1_7 Case 1: Water at rest: What are the relations among components? Case 2: A cube at the corner of the table: What are the relations among components?
