Building Confidence (Testing, Analysis, QA, Reviews)

What is Testing? � Basic Testing Guidelines A test case has two parts: 1. Description of input data 2. Precise description of correct output for that input A programmer should avoid testing his or her programs. A programming organization should not test its own programs. The results of each test should be thoroughly inspected (lots of errors are missed). Test cases must be written for invalid and unexpected as well as valid and expected input conditions.
Basic Testing Guidelines (2) Examining a program to see if it does not do what it is supposed to do is only half the battle. The other half is seeing whether the program does what it is not supposed to do (i.e., must examine for unintended function and side effects. Avoid throw−away test cases unless the program is a throw−away program. Test cases are a valuable investment −− regression testing. Do not plan a testing effort under the tacit assumption that no errors will be found.  Basic Testing Guidelines (3) The probability of the existence of more errors in a section of a program is proportional to the number of errors already found in it. prob. of more errors # errors already found Testing is an extremely creative and challenging task. Exceeds creativity required in designing program. Don’t put your worst or newest people here. A good test case is one that has a high probability of detecting an as−yet undiscovered error.  Building Assurance (Confidence) Dynamic Analysis Static Analysis Quality Assurance (conformance to standards) V&V of non−software lifecycle products (e.g., user manual) Acceptance (user) testing  Dynamic Analysis Testing     Black Box White Box Monitoring run−time behavior Automated test case generation Coverage analysis Assertions Black Box Testing Test data derived solely from specification (i.e., without knowledge of internal structure of program). Need to test every possible input x := y * 2 if x = 5 then y := 3 (since black box, only way to be sure to detect this is to try every input condition)   Valid inputs up to max size of machine (not astronomical)  Also all invalid input (e.g., testing Ada compiler requires all valid and invalid programs) If program has ‘‘memory’’, need to test all possible unique valid and invalid sequences. So for most programs, exhaustive input testing is impractical.  White Box Testing Derive test data by examining program’s logic. Exhaustic path testing: Two flaws 1) Number of unique paths through program is astronomical. loop 20x 5 20 19 18 + 5 + 5 + ... + 5 = 10 14 = 100 trillion If could develop/execute/verify one test case every five minutes = 1 billion years If had magic test processor that could develop/execute/evaluate one test per msec = 3170 years. (control−flow graph)  White Box Testing (con’t) 2) Could test every path and program may still have errors! Does not guarantee program matches specification, i.e., wrong program. Missing paths: would not detect absence of necessary paths Could still have data−sensitivity errors. e.g. program has to compare two numbers for convergence if (A − B) < epsilon ... is wrong because should compare to abs(A − B) Detection of this error dependent on values used for A and B and would not necessarily be found by executing every path through program.  Static Analysis Syntax checks Look for error−prone constructions (enforce standards) Program structure checks Generate graphs and look for structural flaws Module interface checks Detect inconsistencies in declarations of data structures and improper linkages between modules Human Reviews Checklists (inspections) Walkthroughs (reviews) �  Static Analysis (con’t) Event sequence checking Compare event sequences in program with specification of legal sequences Symbolic execution A := X + 5 B = 2 * (X + 5) B := 2 * A if 2 * (X + 5) > 0 If B>0 then C := |B| − 1 else C := |B| + 1 then |2 * (X + 5)| − 1 else |2 * (X + 5)| + 1 Formal verification Use theorem proving methods to show equivalence of code and a formal specification of required behavior. � � Formal Design Reviews Associated with each of documentation phases. Evaluate with respect to: Customer requirements Prescribed standards and practices Contractual requirements Tradeoff priorities Results of previous phases etc. After review, released to configuration control and becomes baseline. �
Structured Walkthroughs ‘‘Egoless programming’’ (Weinberg,The Psychology of Computer Programming) Reviewee and 3−5 reviewers Customers and users should be included. Managers should not. Goal is to discover and note problems. Problems not resolved in walkthrough session. Followup meeting or memo to inform reviewers of actions taken. Major problems only. Successful use dependent on establishing a positive, nonthreatening atmosphere. Moderator should receive training. Must not be used as vehicles for employee evaluation. �  Benefits of Walkthroughs Errors caught at earliest possible time. Greatly improved software quality. Project communication improved. Software easier to maintain. Better project control. Quicker integration of new personnel. Increased programmer expertise. Less disruption with personnel leave. Switch emphasis from individual contemplation to clear, precise communication with others. Enhanced employee morale: social interaction, involvement.  � Software Inspections Started by IBM in 1972 (Fagan) Process driven by a checklist of likely errors Build checklists through experience and feedback. Some companies consider checklists proprietary. Performed after design complete and after coding complete. Last about 2 hours, cover about 100 statements per hour. Evaluation of walkthroughs and inspections: Find about 70−80% of errors. Most errors found before unit testing. �
