6.034 Notes: Section 10.1

6.034 Notes: Section 10.1 Slide 10.1.1 So far, we've only talked about binary features. But real problems are typically characterized by much more complex features. Slide 10.1.2 Some features can take on values in a discrete set that has more than two elements. Examples might be the make of a car, or the age of a person. Slide 10.1.3 When the set doesn't have a natural order (actually, when it doesn't have a natural distance between the elements), then the easiest way to deal with it is to convert it into a bunch of binary attributes. Your first thought might be to convert it using binary numbers, so that if you have four elements, you can encode them as 00, 01, 10, and 11. Although that could work, it makes hard work for the learning algorithm, which, in order to select out a particular value in the set will have to do some hard work to decode the bits in these features. Instead, we typically make it easier on our algorithms by encoding such sets in unary, with one bit per element in the set. Then, for each value, we turn on one bit and set the rest to zero. So, we could encode a four-item set as 1000, 0100, 0010, 0001. Slide 10.1.4 On the other hand, when the set has a natural order, like someone's age, or the number of bedrooms in a house, it can usually be treated as if it were a real-valued attribute using methods we're about to explore. Slide 10.1.5 We'll spend this segment and the next looking at methods for dealing with real-valued attributes. The main goal will be to take advantage of the notion of distance between values that the reals affords us in order to build in a very deep bias that inputs whose features have "nearby" values ought, in general, to have "nearby" outputs. Slide 10.1.6 We'll use the example of predicting whether someone is going to go bankrupt. It only has two features, to make it easy to visualize. One feature, L, is the number of late payments they have made on their credit card this year. This is a discrete value that we're treating as a real. The other feature, R, is the ratio of their expenses to their income. The higher it is, the more likely you'd think the person would be to go bankrupt. We have a set of examples of people who did, in fact go bankrupt, and a set who did not. We can plot the points in a two-dimensional space, with a dimension for each attribute. We've colored the "positive" (bankrupt) points blue and the negative points red. Slide 10.1.7 We took a brief look at the nearest neighbor algorithm in the first segment on learning. The idea is that you remember all the data points you've ever seen and, when you're given a query point, you find the old point that's nearest to the query point and predict its y value as your output. Slide 10.1.8 In order to say what point is nearest, we have to define what we mean by "near". Typically, we use Euclidean distance between two points, which is just the square root of the sum of the squared differences between corresponding feature values. Slide 10.1.9 In other machine learning applications, the inputs can be something other than fixed-length vectors of numbers. We can often still use nearest neighbor, with creative use of distance metrics. The distance between two DNA strings, for example, might be the number of single-character edits required to turn one into the other. Slide 10.1.10 The naive Euclidean distance isn't always appropriate, though. Consider the case where we have two features describing a car. One is its weight in pounds and the other is the number of cylinders. The first will tend to have values in the thousands, whereas the second will have values between 4 and 8. Slide 10.1.11 If we just use Euclidean distance in this space, the number of cylinders will have essentially no influence on nearness. A difference of 4 pounds in a car's weight will swamp a difference between 4 and 8 cylinders. Slide 10.1.12 One standard method for addressing this problem is to re-scale the features. In the simplest case, you might, for each feature, compute its range (the difference between its maximum and minimum values). Then scale the feature by subtracting the minimum value and dividing by the range. All features values would be between 0 and 1. Slide 10.1.13 A somewhat more robust method (in case you have a crazy measurement, perhaps due to a noise in a sensor, that would make the range huge) is to scale the inputs to have 0 mean and standard deviation 1. If you haven't seen this before, it means to compute the average value of the feature, xbar, and subtract it from each feature value, which will give you features all centered at 0. Then, to deal with the range, you compute the standard deviation (which is the square root of the variance, which we'll talk about in detail in the segment on regression) and divide each value by that. This transformation, called normalization, puts all of the features on about equal footing. Slide 10.1.14 Of course, you may not want to have all your features on equal footing. It may be that you happen to know, based on the nature of the domain, that some features are more important than others. In such cases, you might want to multiply them by a weight that will increase their influence in the distance calculation. Slide 10.1.15 Another popular, but somewhat advanced, technique is to use cross validation and gradient descent to choose weightings of the features that generate the best performance on the particular data set. Slide 10.1.16 Okay. Let's see how nearest neighbor works on our bankruptcy example. Let's say we've thought about the domain and decided that the R feature (ratio between expenses and income) needs to be scaled up by 5 in order to be appropriately balanced against the L feature (number of late payments). So we'll use Euclidian distance, but with the R values multiplied by 5 first. We've scaled the axes on the slide so that the two dimensions are graphically equal. This means that locus of points at a particular distance d from a point on our graph will appear as a circle. Slide 10.1.17 Now, let's say we have a new person with R equal 0.3 and L equal to 2. What y value should we predict? Slide 10.1.18 We look for the nearest point, which is the red point at the edge of the yellow circle. The fact that there are no old points in the circle means that this red point is indeed the nearest neighbor of our query point. Slide 10.1.19 And so our answer would be "no". Slide 10.1.20 Similarly, for another query point, Slide 10.1.21 we find the nearest neighbor, which has output "yes" Slide 10.1.22 and generate "yes" as our prediction. Slide 10.1.23 So, what is the hypothesis of the nearest neighbor algorithm? It's sort of different from our other algorithms, in that it isn't explicitly constructing a description of a hypothesis based on the data it sees. Given a set of points and a distance metric, you can divide the space up into regions, one for each point, which represent the set of points in space that are nearer to this designated point than to any of the others. In this figure, I've drawn a (somewhat inaccurate) picture of the decomposition of the space into such regions. It's called a "Voronoi partition" of the space. Slide 10.1.24 Now, we can think of our hypothesis as being represented by the edges in the Voronoi partition that separate a region associated with a positive point from a region associated with a negative one. In our example, that generates this bold boundary. It's important to note that we never explicitly compute this boundary; it just arises out of the "nearest neighbor" query process. Slide 10.1.25 It's useful to spend a little bit of time thinking about how complex this algorithm is. Learning is very fast. All you have to do is remember all the data you've seen! Slide 10.1.26 What takes longer is answering a query. Naively, you have to, for each point in your training set (and there are m of them) compute the distance to the query point (which takes about n computations, since there are n features to compare). So, overall, this takes about m * n time. Slide 10.1.27 It's possible to organize your data into a clever data structure (one such structure is called a K-D tree). It will allow you to find the nearest neighbor to a query point in time that's, on average, proportional to the log of m, which is a huge savings. Slide 10.1.28 Another issue is memory. If you gather data over time, you might worry about your memory filling up, since you have to remember it all. Slide 10.1.29 There are a number of variations on nearest neighbor that allow you to forget some of the data points; typically the ones that are most forgettable are those that are far from the current boundary between positive and negative. Slide 10.1.30 In our example so far, there has not been much (apparent) noise; the boundary between positives and negatives is clean and simple. Let's now consider the case where there's a blue point down among the reds. Someone with an apparently healthy financial record goes bankrupt. There are, of course, two ways to deal with this data point. One is to assume that it is not noise; that is, that there is some regularity that makes people like this one go bankrupt in general. The other is to say that this example is an "outlier". It represents an unusual case that we would prefer largely to ignore, and not to incorporate it into our hypothesis. Slide 10.1.31 So, what happens in nearest neighbor if we get a query point next to this point? Slide 10.1.32 We find the nearest neighbor, which is a "yes" point, and predict the answer "yes". This outcome is consistent with the first view; that is, that this blue point represents some important property of the problem. Slide 10.1.33 But if we think there might be noise in the data, we can change the algorithm a bit to try to ignore it. We'll move to the k-nearest neighbor algorithm. It's just like the old algorithm, except that when we get a query, we'll search for the k closest points to the query points. And we'll generate, as output, the output associated with the majority of the k closest elements. Slide 10.1.34 In this case, we've chosen k to be 3. The three closest points consist of two "no"s and a "yes", so our answer would be "no". Slide 10.1.35 It's not entirely obvious how to choose k. The smaller the k, the more noise-sensitive your hypothesis is. The larger the k, the more "smeared out" it is. In the limit of large k, you would always just predict the output value that's associated with the majority of your training points. So, k functions kind of like a complexity-control parameter, exactly analogous to epsilon in DNF and minleaf-size in decision trees. With smaller k, you have high variance and risk overfitting; with large k, you have high bias and risk not being able to express the hypotheses you need. It's common to choose k using cross-validation. Slide 10.1.36 Nearest neighbor works very well (and is often the method of choice) for problems in relatively lowdimensional real-valued spaces. But as the dimensionality of a space increases, its geometry gets weird. Here are some suprising (to me, at least) facts about high-dimensional spaces. Slide 10.1.37 In high dimensions, almost all points are far away from one another. If you make a cube or sphere in high dimensions, then almost all the points within that cube or sphere are near the boundaries. Slide 10.1.38 Imagine sprinkling data points uniformly within a 10-dimensional unit cube (cube whose sides are of length 1). To capture 10% of the points, you'd need a cube with sides of length .63! Slide 10.1.39 All this means that the notions of nearness providing a good generalization principle, which are very effective in low-dimensional spaces, become fairly ineffective in high-dimensional spaces. There are two ways to handle this problem. One is to do "feature selection", and try to reduce the problem back down to a lower-dimensional one. The other is to fit hypotheses from a much smaller hypothesis class, such as linear separators, which we will see in the next chapter. Slide 10.1.40 We'll look at how nearest neighbor performs on two different test domains. Slide 10.1.41 The first domain is predicting whether a person has heart disease, represented by a significant narrowing of the arteries, based on the results of a variety of tests. This domains has 297 different data points, each of which is characterized by 26 features. A lot of these features are actually boolean, which means that although the dimensionality is high, the curse of dimensionality, which really only bites us badly in the case of real-valued features, doesn't cause too much problem. Slide 10.1.42 In the second domain, we're trying to predict whether a car gets more than 22 miles-per-gallon fuel efficiency. We have 385 data points, characterized by 12 features. Again, a number of the features are binary. Slide 10.1.43 Here's a graph of the cross-validation accuracy of nearest neighbor on the heart disease data, shown as a function of k. Looking at the data, we can see that the performance is relatively insensitive to the choice of k, though it seems like maybe it's useful to have k be greater than about 5. Slide 10.1.44 The red curve is the performance of nearest neighbor using the features directly as they are measured, without any scaling. We then normalized all of the features to have mean 0 and standard deviation 1, and re-ran the algorithm. You can see here that it makes a noticable increase in performance. Slide 10.1.45 We ran nearest neighbor with both normalized and un-normalized inputs on the auto-MPG data. It seems to perform pretty well in all cases. It is still relatively insensitive to k, and normalization only seems to help a tiny amount. Slide 10.1.46 Watch out for tricky graphing! It's always possible to make your algorithm look much better than the other leading brand (as long as it's a little bit better), by changing the scale on your graphs. The previous graph had a scale of 0 to 1. This graph has a scale of 0.85 to 0.95. Now the normalized version looks much better! Be careful of such tactics when you read other peoples' papers; and certainly don't practice them in yours.
