Unit Testing Concurrent Software The MultithreadedTC Framework Introduction Why concurrent software testing? The roadmap of future CPUs lead to multicore chips. The burden of utilizing multiple CPUs falls on the software developer. Everyone will, at some point, write software for a multiple CPU system in their near future. “Unit Testing Concurrent Software” by William Pugh & Nathaniel Ayewah, the developers behind MultithreadedTC. By viewing & studying an existing framework, we can be more concrete and less abstract. Learn some tools already available to us. Good starting point. Concurrency Testing is Different New types of defects exist such as deadlocks and race conditions. Concerns exist over how the system interleaves threads, not so much about input/output. Even single-threaded applications have a large number of paths of execution, the move to multi-threaded applications causes this to explode rapidly. Concurrency Testing is Different The demands of testing a multithreaded system call for new tools and frameworks. JUnit is great, but we lack a way to control multiple threads such that we are then able interleave threads in a particular fashion for the SUT. Enter: MultithreadedTC MultithreadedTC You will most likely use commonly available tools and frameworks while developing software. JUnit, Cobertura, JavaNCSS, etc. MultithreadedTC is the Java framework which allows the developer to write a specific sequence of interleaving threads to test the system for concurrency conditions. Motivated by the philosophy that multithreaded applications should be built using small abstractions: semaphores, bounded buffers, latches, etc. This means it’s possible to exercise/test all the possible combinations since the abstractions are small. The application logic and concurrency logic are separated. MultithreadedTC Features Open source: http://code.google.com/p/multithreadedtc/ Already developers are adding in features. Well documented. Easy to read and understand. Pure Java, no scripting language required (unlike ConAn). Eliminates “scaffolding code” needed to run multithreaded tests. No “.start()” or “.join()”, among others. MultithreadedTC Documentation MultithreadedTC Code Example Stays in loop until condition is met by 2nd thread Both threads start at the same time. thread1() runs until thread2() sets the AtomicInteger to 2, then thread1() sets the ai to 3, and both threads join, then the final finish() method asserts that the ai is now 3. MultithreadedTC Clock MultithreadedTC is able to provide a nice platform for writing test cases for concurrent software, making the job of the software developer easier when test time comes. This is due to a “metronome” the framework runs on a separate thread. The clock advances in “ticks” (from 0 to n). This allows the developer to correctly interleave threads. The metronome only advances to next tick when all threads are in a blocked state, and at least 1 thread is for a future tick. MultithreadedTC Example Framework Evaluation Authors evaluate the performance of MultithreadedTC by reproducing some test code used in the TCK for JSR 166. Results of Evaluation Of those tests in the TCK, the authors looked at 258 tests which attempted to use a specific interleaving of threads in 33 classes, and implemented those tests using MultithreadedTC. MultithreadedTC vs ConAn Concurrency Analyzer (ConAn) Testing Tool. Developed by Strooper, Duke, Wildman, Goldson and Long at the University of Queensland, Australia. Based on Roast. Aims for short test cases. Script-based. Uses internal clock for synchronization. Generates Java test driver from test script. Test Driver Generation ConAn Test Script Roast ConAn Test Driver Example Comparison ConAn MultithreadedTC Ticks at regular intervals Advances when all threads are blocked Organization by ticks Organization by threads Deterministic Deterministic & Indeterministic Custom Syntax / Scripting Language Pure Java Comparison Line count comparison between MultithreadedTC and ConAn for tests on the WriterPreferenceReadWriteLock Java Class. Other Testing Tools JUnit, TestNG, GroboUtils, ConTest JUnit junit.extensions.ActiveTestSuite Build a suite of tests that run concurrently Run each test in a separate thread Suite does not finish until all test threads are complete Can be used with RepeatedTest to uncover threading problems public static Test suite() { TestSuite suite = new ActiveTestSuite(); suite.addTest(new TestGame(“testCreateFighter”)); suite.addTest(new TestGame(“testGameInitialState”)); suite.addTest(new TestGame(“testSameFighters”)); return suite; } TestNG Inspired by JUnit Tests are run in parallel Parallel parameter must be set Thread-count Specifies size of thread pool @Test(threadPoolSize = 3, invocationCount = 10, timeOut = 200) public void shouldHandleRequestSwiftly() { //make request } GroboUtils Extension of JUnit. Thread is specified by extending TestRunnable class and implementing runTest() method. Classes are provided to run multiple instances of the thread simultaneously. Monitors execution of threads to look for inconsistent states. ConTest Developed by IBM. Records and replays interleavings that lead to faults. Uses sleep() and yield() to test different interleavings each time a test is run. Conclusion MultithreadedTC Short test cases. JUnit compatible. Involves very little overhead.
