6.061 Class Notes, Chapter 3: Polyphase Networks

Massachusetts Institute of Technology Department of Electrical Engineering and Computer Science 6.061 Introduction to Power Systems Class Notes Chapter 3 Polyphase Networks ∗ 1 Introduction Most electric power applications employ three phases. That is, three separate power carrying circuite, with voltages and currents staggered symmetrically in time are used. Two major reasons for the use of three phase power are economical use of conductors and nearly constant power flow. Systems with more than one phase are generally termed polyphase. Three phase systems are the most common, but there are situations in which a different number of phases may be used. Two phase systems have a simplicity that makes them useful for teaching vehicles and for certain servomechanisms. This is why two phase machines show up in laboratories and textbooks. Sys­ tems with a relatively large number of phases are used for certain specialized applications such as controlled rectifiers for aluminum smelters. Six phase systems have been proposed for very high power transmission applications. Polyphase systems are qualitatively different from single phase systems. In some sense, polyphase systems are more complex, but often much easier to analyze. This little paradox will become ob­ vious during the discussion of electric machines. It is interesting to note that physical conversion between polyphase systems of different phase number is always possible. This chapter starts with an elementary discussion of polyphase networks and demonstrates some of their basic features. It ends with a short discussion of per-unit systems and power system representation. 2 Two Phases The two-phase system is the simplest of all polyphase systems to describe. Consider a pair of voltage sources sitting side by side with: v1 = V cos ωt (1) v2 = V sin ωt (2) 1 Suppose this system of sources is connected to al “balanced load”, as shown in Figure 1. To compute the power flows in the system, it is convenient to re-write the voltages in complex form: � �� + − v1 �� � i1 + Z �� + − v1 v2 �� − i2 + Z v2 − Figure 1: Two-Phase System � � � j(ωt− π2 ) v1 = Re V ej ωt � v2 = Re −jV ejωt = Re V e (3) � (4) � (5) � V1 � V2 Figure 2: Phasor Diagram for Two-Phase Source If each source is connected to a load with impedance: Z = |Z |ejψ then the complex amplitudes of currents are: I1 = I2 = V −jψ e |Z| V −jψ −j π e e 2 |Z| Each of the two phase networks has the same value for real and reactive power: P + jQ = 2 |V |2 jψ e 2| Z | (6) or: P = Q = |V |2 cos ψ 2| Z | |V |2 sin ψ 2| Z | (7) (8) The relationship between “complex power” and instantaneous power flow was worked out in Chapter 2 of these notes. For a system with voltage of the form: � v = Re V ejφ ejωt � instantaneous power is given by: p = P [1 + cos 2(ωt + φ)] + Q sin 2(ωt + φ) For the case under consideration here, φ = 0 for phase 1 and φ = − π2 for phase 2. Thus: p1 = p2 = |V |2 |V |2 cos ψ [1 + cos 2ωt] + sin ψ sin 2ωt 2| Z | 2| Z | |V |2 |V |2 cos ψ [1 + cos(2ωt − π)] + sin ψ sin(2ωt − π) 2| Z | 2| Z | Note that the time-varying parts of these two expressions have opposite signs. Added together, they give instantaneous power: |V |2 p = p1 + p2 = cos ψ |Z| At least one of the advantages of polyphase power networks is now apparent. The use of a balanced polyphase system avoids the power flow pulsations due to ac voltage and current, and even the pulsations due to reactive energy flow. This has obvious benefits when dealing with motors and generators or, in fact, any type of source or load which would like to see constant power. 3 Three Phase Systems Now consider the arrangement of three voltage sources illustrated in Figure 3. The three phase voltages are: va = � = Re V ejωt V cos ωt vb = V cos(ωt − 2π 3 ) vc = V cos(ωt + 2π 3 ) � � = Re V ej(ωt− � = Re V e (9) 2π ) 3 ) j(ωt+ 2π 3 � � (10) (11) These three phase voltages are illustrated in the time domain in Figure 4 and as complex phasors in Figure 5. Note the symmetrical spacing in time of the voltages. As in earlier examples, the instantaneous voltages may be visualized by imagining Figure 5 spinning counterclockwise with 3 + + �� �� ��+ vb − − + − V ej 2π 3 + − V e−j 2π 3 + − V va �� �� �� vc − Figure 3: Three- Phase Voltage Source 1 0.8 0.6 0.4 Va, Vb, Vc 0.2 0 −0.2 −0.4 −0.6 −0.8 −1 0 5 10 15 t Figure 4: Three Phase Voltages angular velocity ω. The instantaneous voltages are just projections of the vectors of this “pinwheel” onto the horizontal axis. Consider connecting these three voltage sources to three identical loads, each with complex impedance Z, as shown in Figure 6. If voltages are as given by (9 - 11), then currents in the three phases are: V jωt e Z � � V j(ωt− 2π ) 3 = Re e Z � � V j(ωt+ 2π ) 3 e = Re Z ia = Re ib ic � 4 � (12) (13) (14) Vc � � � � � � � � � � � V �a Vb � Figure 5: Phasor Diagram: Three Phase Voltages � �� �� �� + − va + − vb + − vc �� �� �� � Z in � vc � ib + ic + Z − vb ia + va Z − − Figure 6: Three- Phase Source Connected To Balanced Load Complex power in each of the three phases is: P + jQ = |V |2 (cos ψ + j sin ψ) 2| Z | (15) Then, remembering the time phase of the three sources, it is possible to write the values of instan­ taneous power in the three phases: pa = pb = pc = |V |2 {cos ψ [1 + cos 2ωt] + sin ψ sin 2ωt} 2| Z | � � � 2π |V |2 cos ψ 1 + cos(2ωt − ) + sin ψ sin(2ωt − 2| Z | 3 � � � |V |2 2π cos ψ 1 + cos(2ωt + ) + sin ψ sin(2ωt + 2| Z | 3 (16) 2π ) 3 � 2π ) 3 � (17) (18) The sum of these three expressions is total instantaneous power, which is constant: p = pa + pb + pc = 5 3 |V |2 cos ψ 2 |Z | (19) It is useful, in dealing with three phase systems, to remember that cos x + cos(x − 2π 2π ) + cos(x + )=0 3 3 regardless of the value of x. Now consider the current in the neutral wire, in in Figure 6. This current is given by: �� V � jωt j(ωt− 2π ) j(ωt+ 2π ) 3 3 e +e in = ia + ib + ic = Re +e =0 Z � (20) This shows the most important advantage of three-phase systems over two-phase systems: a wire with no current in it does not have to be very large. In fact, the neutral connection may be eliminated completely in many cases. The network shown in Figure 7 will work as well as the network in Figure 6 in most cases in which the voltages and load impedances are balanced. va �� i� a + va −+ − −+ Z vb − −+ Z vc − �� vb �� ib + � �� vc �� ic + � �� Z Figure 7: Ungrounded Three-Phase Source and Load There is a fundamental difference between grounded and undgrounded systems if perfectly balanced conditions are not maintained. In effect, the ground wire provides isolation between the phases by fixing the neutral voltage a the star point to be zero. If the load impedances are not equal the load is said to be unbalanced. If the system is grounded there will be current in the neutral. If an unbalanced load is not grounded, the star point voltage will not be zero, and the voltages will be different in the three phases at the load, even if the voltage sources all have the same magnitude. 4 Line-Line Voltages A balanced three-phase set of voltages has a well defined set of line-line voltages. If the line-to­ neutral voltages are given by (9 - 11), then line-line voltages are: � � vab = va − vb = Re V 1 − e−j � � vbc = vb − vc = Re V e � � −j 2π 3 vca = vc − va = Re V ej 6 2π 3 2π 3 −e � � ejωt j 2π 3 � − 1 ejωt � ejωt � (21) � (22) (23) and these reduce to: vab = Re vbc = Re vca = Re �√ �√ �√ π 3V ej 6 ejωt 3V e −j π2 3V e j 5π 6 � ejωt ejωt (24) � (25) � (26) The phasor relationship of line-to-neutral and line-to-line voltages is shown in Figure 8. Two things should be noted about this relationship: • The line-t√o-line voltage set has a magnitude that is larger than the line-ground voltage by a factor of 3. • Line-to-line voltages are phase shifted by 30◦ ahead of line-to-neutral voltages. Clearly, line-to-line voltages themselves form a three-phase set just as do line-to-neutral voltages. Power system components (sources, transformer windings, loads, etc.) may be connected either between lines and neutral or between lines. The former connection of often called wye, the latter is called delta, for obvious reasons. Vc Vca Vab Vca Vc Va Vbc Va Vab Vb Vb Vbc Figure 8: Line-Neutral and Line-Line Voltages It should be noted that the wye connection is at least potentially a four-terminal connection, while the delta connection is inherently three-terminal. The difference is the availability of a neutral point. Under balanced operating conditions this is unimportant, but the difference is apparent and important under unbalanced conditions. 4.1 Example: Wye and Delta Connected Loads Loads may be connected in either line-to-neutral or line-to-line configuration. An example of the use of this flexibility is in a fairly commonly used distribution system with a line-to-neutral voltage of 120 V, RMS. In this system the line-to-line voltage is 208 V, RMS. Single phase loads may be connected either line-to-line or line-to-neutral. 7 + - Va - Vab Vca - Vb + + - + + Vc - Vbc + Figure 9: Wye And Delta Connected Voltage Sources a a Za Zca Zab Zb c Zc b c Z bc b Figure 10: Wye And Delta Connected Impedances Suppose it is necessary to build a resistive heater to deliver 6 kW, to be made of three elements which may be connected in either wye or delta. Each of the three elements must dissipate 2000 W. 2 Thus, since P = VR , the wye connected resistors would be: Ry = 1202 = 7.2Ω 2000 while the delta connected resistors would be: 2082 = 21.6Ω 2000 As is suggested by this example, wye and delta connected impedances are often directly equiv­ alent. In fact, ungrounded connections are three-terminal networks which may be represented in two ways. The two networks shown in Figure 10, combinations of three passive impedances, are directly equivalent and identical in their terminal behavior if the relationships between elements are as given in (27 - 32). RΔ = Z ab = Z aZ b + Z bZ c + Z cZ a Zc 8 (27) Z bc = Z ca = Za = Zb = Zc = Z aZ b + Z bZ c + Z cZ a Za Z aZ b + Z bZ c + Z cZ a Zb Z ab Z ca Z ab + Z bc + Z ca Z ab Z bc Z ab + Z bc + Z ca Z bc Z ca Z ab + Z bc + Z ca (28) (29) (30) (31) (32) A special case of the wye-delta equivalence is that of balanced loads, in which: Za = Zb = Zc = Zy and Z ab = Z bc = Z ca = Z Δ in which case: Z Δ = 3Z y 4.2 Example: Use of Wye-Delta for Unbalanced Loads The unbalanced load shown in Figure 11 is connected to a balanced voltage source. The problem is to determine the line currents. Note that his load is ungrounded (if it were grounded, this would be a trivial problem). The voltages are given by: va = V cos ωt 2π ) 3 2π ) = V cos(ωt + 3 vb = V cos(ωt − vc To solve this problem, convert both the source and load to delta equivalent connections, as shown in Figure 12. The values of the three resistors are: rab = rca = rbc = 2+4+2 =4 2 2+4+2 =8 1 The complex amplitudes of the equivalent voltage sources are: √ jπ 3e 6 � � √ π 2π 2π = V b − V c = V e−j 3 − ej 3 = V 3e−j 2 � 2π � √ 5π = V c − V a = V ej 3 − 1 = V 3ej 6 V ab = V bc V ca � V a − V b = V 1 − e−j 9 2π 3 � = V Ia + R a= 1 Va Vc - - + Vb + Rb = 2 Rc = 2 Ib Ic Figure 11: Unbalanced Load - + Vca Ia Vab + - Vbc + R ca = 4 R ab = 4 Ib R bc = 8 Ic Figure 12: Delta Equivalent 10 Currents in each of the equivalent resistors are: I1 = V ab rab I2 = V bc rbc I3 = V ca rca The line curents are then just the difference between current in the legs of the delta: Ia = I1 − I3 = Ib = I2 − I1 = √ 3V π ej 6 4 − ej √ � e−j π2 3V 8 − √ 3V Im(·) 1 Ic = I3 − I2 = � � ej 5π 6 4 5π 6 4 � = 3 V 4 3 1 = − +j V 8 4 � � � −j π 3 1 − e 82 = − V −j 8 4 π ej 6 4 � � � These are shown in Figure 13. 4V �� � � − 38 V � � � � � � � � − 14 V 3 V 4 � Re(·) Figure 13: Line Currents 5 Transformers Transformers are essential parts of most power systems. Their role is to convert electrical energy at one voltage to some other voltage. We will deal with transformers as electromagnetic elements later on in this subject, but for now it will be sufficient to use a simplified model for the transformer which we will call the ideal transformer. This is a two-port circuit element, shown in Figure 14. i� 1 + v1 − N 1 : N2 ⊃ ⊃ ⊃ ⊃ ⊂ ⊂ ⊂ ⊂ i2 � + v2 − Figure 14: Ideal Transformer The ideal transformer as a network element constrains its terminal variables in the following way: 11 v2 v1 = N1 N2 N1 i1 = −N2 i2 (33) (34) As it turns out, this is not a terribly bad model for the behavior of a real transformer under most circumstances. Of course, we will be interested in fine points of transformer behavior and behavior under pathological operating conditions, and so will eventually want a better model. For now, it is sufficient to note just a few things about how the transformer works. 1 1. In normal operation, we select a transformer turns ratio N N2 so that the desired voltages appear at the proper terminals. For example, to convert 13.8 kV distribution voltage to the 120/240 volt level suitable for residential or commercial single phase service, we would use a transformer with turns ratio of 13800 240 = 57.5. To split the low voltage in half, a center tap on the low voltage winding would be used. 2. The transformer, at least in its ideal form, does not consume, produce nor store energy. Note that, according to (33) and (34), the sum of power flows into a transformer is identically zero: p1 + p2 = v1 i1 + v2 i2 = 0 (35) 3. The transformer also tends to transform impedances. To show how this is, look at Figure 15. Here, some impedance is connected to one side of an ideal transformer. See that it is possible to find an equivalent impedance viewed from the other side of the transformer. I�1 + V1 − I�2 N1 : N2 ⊃ ⊃ ⊃ ⊃ ⊂ ⊂ ⊂ ⊂ Z Figure 15: Impedance Transformation Noting that I2 = − N1 I N2 1 and that V 2 = −ZI 2 Then the ratio between input voltage and current is: V1 = N1 V = N2 2 12 � N1 N2 �2 I1 (36) 6 Three-Phase Transformers A three-phase transformer is simply three single phase transformers. The complication in these things is that there are a number of ways of winding them, and a number of ways of interconnecting them. We will have more to say about windings later. For now, consider interconnections. On either “side” of a transformer connection (i.e. the high voltage and low voltage sides), it is possible to connect transformer windings either line to neutral (wye), or line to line (delta). Thus we may speak of transformer connections being wye-wye, delta-delta, wye-delta, or delta-wye. Ignoring certain complications that we will have more to say about shortly, connection of trans­ formers in either wye-wye or delta-delta is reasonably easy to understand. Each of the line-to-neutral (in the case of wye-wye), or line-to-line (in the case of delta-delta) voltages is transformed by one of the three transformers. On the other hand, the interconnections of a wye-delta or delta-wye transformer are a little more complex. Figure 16 shows a delta-wye connection, in what might be called “wiring diagram” form. A more schematic (and more common) form of the same picture is shown in Figure 17. In that picture, winding elements that appear parallel are wound on the same core segment, and so constitute a single phase transformer. Xc Xb Hc Hb � ⊃ ⊃ ⊃ ⊃ ⊂ ⊂ ⊂ ⊂ Xa � � � � � � ⊃ ⊃ ⊃ ⊃ ⊂ ⊂ ⊂ ⊂ � � � � � Ha ⊃ ⊃ ⊃ ⊃ ⊂ ⊂ ⊂ ⊂ Figure 16: Delta-Wye Transformer Connection Now: assume that NΔ and NY are numbers of turns. If the individual transformers are consid­ ered to be ideal, the following voltage and current constraints exist: vaY = vbY = vcY = iaΔ = ibΔ = icΔ = NY NΔ NY NΔ NY NΔ NY NΔ NY NΔ NY NΔ (vaΔ − vbΔ ) (37) (vbΔ − vcΔ ) (38) (vcΔ − vaΔ ) (39) (iaY − icY ) (40) (ibY − iaY ) (41) (icY − ibY ) (42) 13 AY A N NY C N NY N NY B CY BY Figure 17: Schematic of Delta-Wye Transformer Connection where each of the voltages are line-neutral and the currents are in the lines at the transformer terminals. Now, consider what happens if a Δ − Y transformer is connected to a balanced three- phase voltage source, so that: � vaΔ = Re V ejωt � � vbΔ = Re V ej(ωt− � vcΔ = Re V ej(ωt+ 2π ) 3 2π ) 3 � � Then, complex amplitudes on the wye side are: V aY = V bY = V cY = √ NY π 3 V ej 6 NΔ � � √ π 2π 2π NY NY −j 3 V e−j 2 − ej 3 = 3 NΔ V e NΔ � 2π � √ 5π NY NY j 3 3 V ej 6 −1 = NΔ V e NΔ NY NΔ V � 1 − e−j 2π 3 � = Two observations should be made here: • The ratio of voltages (that√is, the ratio of either line-line or line-neutral) is different from the turns ratio by a factor of 3. • All wye side voltages are shifted in phase by 30◦ with respect to the delta side voltages. 6.1 Example Suppose we have the following problem to solve: 14 A balanced three- phase wye-connected resistor is connected to the Δ side of a Y − Δ transformer with a nominal voltage ratio of vΔ =N vY What is the impedance looking into the wye side of the transformer, assuming drive with a balanced source? The situation is shown in Figure 18. N NY R N NY N R R NY Figure 18: Example It is important to remember the relationship between the voltage ratio and the turns ratio, which is: NΔ vΔ =N = √ vY 3NY so that: Nδ N =√ NY 3 Next, the Y − Δ equivalent transform for the load makes the picture look like figure 19 In this situation, each transformer secondary winding is conected directly across one of the three resistors. Currents in the resistors are given by: i1 = i2 = i3 = vabΔ 3R vbcΔ 3R vcaΔ 3R Line currents are: iaΔ = i1 − i3 = ibΔ = i2 − i1 = icΔ = i3 − i2 = vabΔ −vcaΔ 3R vbcΔ −vabΔ 3R vcaΔ −vbcΔ 3R 15 = i1Δ − i3Δ = i2Δ − i1Δ = i3Δ − i2Δ ia iaY aY − vca − − + icY vcY 3R N i2 − N + vbY + vab + vbc − NY 3R − v + NY i3 N + NY 3R i1 ib ic i bY Figure 19: Equivalent Situation Solving for currents in the legs of the transformer Δ, subtract, for example, the second expression from the first: 2vabΔ − vbcΔ − vcaΔ 2i1Δ − i2Δ − i3Δ = 3R Now, taking advantage of the fact that the system is balanced: i1Δ + i2Δ + i3Δ = 0 vabΔ + vbcΔ + vcaΔ = 0 to find: i1Δ = i2Δ = i3Δ = vabΔ 3R vbcΔ 3R vcaΔ 3R Finally, the ideal transformer relations give: NΔ vaY NY NΔ = vbY NY NΔ = vcY NY NΔ i1Δ NY NΔ = i2Δ NY NΔ = i3Δ NY vabΔ = iaY = vbcΔ ibY vcaΔ icY so that: iaY = � NΔ NY 16 �2 1 vaY 3R ibY icY NΔ 2 = NY � � NΔ 2 = NY � � 1 vbY 3R 1 vcY 3R The apparent resistance (that is, apparent were it to be connected in wye) at the wye terminals of the transformer is: � � NY 2 Req = 3R NΔ Expressed in terms of voltage ratio, this is: Req N = 3R √ 3 � �2 vY =R vΔ � �2 It is important to note that this solution took the long way around. Taken consistently (uni­ formly on a line-neutral or uniformly on a line-line basis), impedances transform across transformers by the square of the voltage ratio, no matter what connection is used. 7 Polyphase Lines and Single-Phase Equivalents By now, one might suspect that a balanced polyphase system may be regarded simply as three single-phase systems, even though the three phases are physically interconnected. This feeling is reinforced by the equivalence between wye and delta connected sources and impedances. One more step is required to show that single phase equivalence is indeed useful, and this concerns situations in which the phases have mutual coupling. In speaking of lines, we mean such system elements as transmission or distribution lines: over­ head wires, cables or even in-plant buswork. Such elements have impedance, so that there is some voltage drop between the sending and receiving ends of the line. This impedance is more than just conductor resistance: the conductors have both self and mutual inductance, because currents in the conductors make magnetic flux which, in turn, is linked by all conductors of the line. A schematic view of a line is shown in Figure 20. Actually, only the inductance components of line impedance are shown, since they are the most interesting parts of line impedance. Working in complex amplitudes, it is possible to write the voltage drops for the three phases by: V a1 − V a2 = jωLI a + jωM (I b + I c ) (43) V c1 − V c2 = jωLI c + jωM (I a + I b ) (45) V b1 − V b2 = jωLI b + jωM (I a + I c ) (44) If the currents form a balanced set: Ia + Ib + Ic = 0 Then the voltage drops are simply: V a1 − V a2 = jω (L − M ) I a V b1 − V b2 = jω (L − M ) I b V c1 − V c2 = jω (L − M ) I c 17 (46) L va1 i va2 a M L v vb2 b1 i b M L M vc1 i vc2 c Figure 20: Schematic Of A Balanced Three-Phase Line With Mutual Coupling L + R N NY Va - M R N NY - Vb + L + N L M R NY Vc Voltage Source M Primary Secondary Transmission Line Load Transformer Figure 21: Example In this case, an apparent inductance, suitable for the balanced case, has been defined: L1 = L − M (47) which describes the behavior of one phase in terms of its own current. It is most important to note that this inductance is a valid description of the line only if (46) holds, which it does, of course, in the balanced case. 7.1 Example To show how the analytical techniques which come from the network simplification resulting from single phase equivalents and wye-delta transformations, consider the following problem: A three-phase resistive load is connected to a balanced three-phase source through a transformer connected in delta-wye and a polyphase line, as shown in Figure 21. The problem is to calculate power dissipated in the load resistors. The three- phase voltage source has: � �√ va = Re 2VRM S ejωt � �√ 2π vb = Re 2VRM S ej(ωt− 3 ) � �√ 2π vc = Re 2VRM S ej(ωt+ 3 ) 18 This problem is worked by a succession of simple transformations. First, the delta connected resistive load is converted to its equivalent wye with RY = R3 . Next, since the problem is balanced, the self- and mutual inductances of the line are directly equivalent to self inductances in each phase of L1 = L − M . Now, the transformer secondary is facing an impedance in each phase of: Z Y s = jωL1 + RY The delta-wye transformer has a voltage ratio of: vp NΔ =√ vs 3NY so that, on the primary side of the transformer, the line and load impedance is: Z p = jωLeq + Req where the equivalent elements are: Leq = Req = 1 NΔ 2 (L − M ) 3 NY � �2 1 NΔ R 3 NY 3 � � Magnitude of current flowing in each phase of the source is: √ 2VRM S |I| = � 2 (ωLeq )2 + Req Dissipation in one phase is: P1 = = 1 2 |I| Req 2 2 VRM S Req 2 2 (ωLeq ) + Req And, of course, total power dissipated is just three times the single phase dissipation. 8 Introduction To Per-Unit Systems Strictly speaking, per-unit systems are nothing more than normalizations of voltage, current, impedance and power. These normalizations of system parameters because they provide sim­ plifications in many network calculations. As we will discover, while certain ordinary parameters have very wide ranges of value, the equivalent per-unit parameters fall in a much narrower range. This helps in understanding how certain types of system behave. 19 � �� + − V �� i1 + Z v1 − Figure 22: Example 8.1 Normalization Of Voltage And Current The basis for the per-unit system of notation is the expression of voltage and current as fractions of base levels. Thus the first step in setting up a per-unit normalization is to pick base voltage and current. Consider the simple situation shown in Figure 22. For this network, the complex amplitudes of voltage and current are: V = IZ (48) We start by defining two base quantities, VB for voltage and IB for current. In many cases, these will be chosen to be nominal or rated values. For generating plants, for example, it is common to use the rated voltage and rated current of the generator as base quantities. In other situations, such as system stability studies, it is common to use a standard, system wide base system. The per-unit voltage and current are then simply: V (49) v = VB I i = (50) IB Applying (49) and (50) to (48), we find: v = iz (51) where the per-unit impedance is: IB VB This leads to a definition for a base impedance for the system: VB ZB = IB Of course there is also a base power, which for a single phase system is: z=Z PB = VB IB (52) (53) (54) as long as VB and IB are expressed in RMS. It is interesting to note that, as long as normalization is carried out in a consistent way, there is no ambiguity in per-unit notation. That is, peak quantities normalized to peak base quantities will be the same, in per-unit, as RMS quantities normalized to RMS bases. This advantage is even more striking in polyphase systems, as we are about to see. 20 8.2 Three Phase Systems When describing polyphase systems, we have the choice of using either line-line or line-neutral voltage and line current or current in delta equivalent loads. In order to keep straight analysis in ordinary variable, it is necessary to carry along information about which of these quantities is being used. There is no such problem with per-unit notation. We may use as base quantities either line to neutral voltage VBl−g or line to line voltage VBl−l . Taking the base current to be line current IBl , we may express base power as: PB = 3VBl−g IBl (55) √ Because line-line voltage is, under normal operation, 3 times line-neutral voltage, an equivalent statement is: √ PB = 3VBl−l IBl (56) If base impedance is expressed by line-neutral voltage and line current (This is the common convention, but is not required), VBl−g (57) ZB = IBl Then, base impedance is, written in terms of base power: ZB = 2 2 VBl−g VBl−l PB = = 3 2 PB PB 3IB (58) Note that a single per-unit voltage applied equally well to line-line, line-neutral, peak and RMS quantities. For a given situation, each of these quantities will have a different ordinary value, but there is only one per-unit value. 8.3 Networks With Transformers One of the most important advantages of the use of per-unit systems arises in the analysis of networks with transformers. Properly applied, a per-unit normalization will cause nearly all ideal transformers to dissapear from the per-unit network, thus greatly simplifying analysis. To show how this comes about, consider the ideal transformer as shown in Figure 23. The I�1 + V1 − 1:N ⊃ ⊃ ⊃ ⊃ ⊂ ⊂ ⊂ ⊂ I�2 + V2 − Figure 23: Ideal Transformer With Voltage And Current Conventions Noted ideal transformer imposes the constraints that: V 2 = NV 1 1 I2 = I N 1 21 Normalized to base quantities on the two sides of the transformer, the per-unit voltage and current are: v1 = i1 = v2 = i2 = V1 VB1 I1 IB1 V2 VB2 I2 IB2 Now: note that if the base quantities are related to each other as if they had been processed by the transformer: VB2 = N VB1 IB1 IB2 = N (59) (60) then v 1 = v 2 and i1 = i2 , as if the ideal transformer were not there (that is, consisted of an ideal wire). Expressions (59) and (60) reflect a general rule in setting up per-unit normalizations for systems with transformers. Each segment of the system should have the same base power. Base voltages transform according to transformer voltage ratios. For three-phase systems, of course, the voltage √ ratios may differ from the physical turns ratios by a factor of 3 if delta-wye or wye-delta connections are used. It is, however, the voltage ratio that must be used in setting base voltages. 8.4 Transforming From One Base To Another Very often data such as transformer leakage inductance is given in per-unit terms, on some base (perhaps the units rating), while in order to do a system study it is necessary to express the same data in per-unit in some other base (perhaps a unified system base). It is always possible to do this by the two step process of converting the per-unit data to its ordinary form, then re-normalizing it in the new base. However, it is easier to just convert it to the new base in the following way. Note that impedance in Ohms (ordinary units) is given by: Z = z 1 ZB1 = z 2 ZB2 (61) Here, of course, z 1 and z 2 are the same per-unit impedance expressed in different bases. This could be written as: V2 V2 (62) z 1 B1 = z 2 B2 PB1 PB2 This yields a convenient rule for converting from one base system to another: PB1 z1 = PB2 � 22 VB2 VB1 �2 z2 (63) Load G 1 T1 L T2 3-Phase Fault Figure 24: One-Line Diagram Of Faulted System 8.5 Example: Fault Study To illustrate some of the concepts with which we have been dealing, we will do a short circuit analysis of a simple power system. This system is illustrated, in one-line diagram form, in Figure 24. A one-line diagram is a way of conveying a lot of information about a power system without becoming cluttered with repetitive pieces of data. Drawing all three phases of a system would involve quite a lot of repetition that is not needed for most studies. Further, the three phases can be re-constructed from the one-line diagram if necessary. It is usual to use special symbols for different components of the network. For our network, we have the following pieces of data: Symbol Component Base P Base V Impedance (MVA) (kV) (per-unit) G1 Generator 200 13.8 j.18 T1 Transformer 200 13.8/138 j.12 L1 Trans. Line 100 138 .02 + j.05 T2 Transformer 50 138/34.5 j.08 A three-phase fault is assumed to occur on the 34.5 kV side of the transformer T2 . This is a symmetrical situation, so that only one phase must be represented. The per-unit impedance diagram is shown in Figure 25. It is necessary to proceed now to determine the value of the components in this circuit. xg ∩∩∩∩ �� + − xT 1 ∩∩∩∩ xl ∩∩∩∩ rl ∧∧∧ ∨∨ xT 2 ∩∩∩∩ � eg �� � Figure 25: Impedance Diagram For Fault Example First, it is necessary to establish a uniform base an per-unit value for each of the system components. Somewhat arbitrarily, we choose as the base segment the transmission line. Thus all of the parameters must be put into a base power of 100 MVA and voltage bases of 138 kV on the 23 line, 13.8 kV at the generator, and 34.5 kV at the fault. Using (62): xg = xT 1 = xT 2 = 100 200 100 200 100 50 rl = × .18 = .09per-unit × .12 = .06per-unit × .08 = .16per-unit = .02per-unit xl = = .05per-unit Total impedance is: z = j (xg + xT 1 + xl + xT 2 ) + rl = j.36 + .02per-unit |z| = .361per-unit Now, if eg is equal to one per-unit (generator internal voltage equal to base voltage), then the per-unit current is: 1 |i| = = .277per-unit .361 This may be translated back into ordinary units by getting base current levels. These are: • On the base at the generator: IB = √ • On the line base: • On the base at the fault: 100MVA = 4.18kA 3 × 13.8kV 100MVA IB = √ = 418A 3 × 138kV IB = √ 100MVA = 1.67kA 3 × 34.5kV Then the actual fault currents are: • At the generator |I f | = 11, 595A • On the transmission line |I f | = 1159A • At the fault |I f | = 4633A 24
