HST 725 Assignment 1 with Solutions

HST 725 Music Perception & Cognition Assignment #1 http://www2.siba.fi/akustiikka/?id=39&la=en ================================================================= 1. Harmonic series. A. What are the first 10 harmonics of a 200 Hz fundamental (F0)? 1st harmonic (fundamental):200 Hz, 2nd: 400 Hz, 3:600 Hz, 4:800 Hz, 5:1000 Hz, 6:1200 Hz, 7: 1400 Hz, 8:1600 Hz, 9:1800 Hz, 10:2000 Hz. B. Which partials can be "heard out" or "resolved" as individual pitches? (Partials are not divisible by whole numbers, usually interpreted by auditory system as noise). The partials that are harmonics of lower frequencies can be “resolved” as individual pitches. For example, the 1.5 partial of 200 Hz is the same as 3rd harmonic of 100 Hz (300 Hz in both cases), so it can be resolved. C. What would be the first 10 subharmonics of 200 Hz? Subharmonic-frequencies below the fundamental, 1/(harmonic #). 1: 200 Hz, 2:100 Hz, 3: 66.7 Hz, 4: 50 Hz, 5: 40 Hz, 6: 33.3 Hz, 7: 28.6 Hz, 8: 25 Hz, 9: 22.2 Hz, 10: 20 Hz D. What would be the fundamental of 400, 500, 600 and 700 Hz? 100 Hz. They are the 4th, 5th, 6th, and 7th harmonics of the fundamental. E. What are subharmonics 1-10 of 400, 500, 600, and 700 Hz. *400 Hz- 1: 400 Hz, 2: 200 Hz, 3: 133.3 Hz, 4: 100 Hz, 5: 80 Hz, 6: 66.7 Hz, 7: 57.1 Hz, 8: 50 Hz, 9: 44.4 Hz, 10: 40 Hz *500 Hz- 1: 500 Hz, 2: 250 Hz, 3: 166.7 Hz, 4: 125 Hz, 5: 100 Hz, 6: 83.3 Hz, 7: 71.4 Hz, 8: 62.5 Hz, 9: 55.6 Hz, 10: 50 Hz *600 Hz- 1: 600 Hz, 2: 300 Hz, 3: 200 Hz, 4: 150 Hz, 5: 120 Hz, 6:100 Hz, 7: 85.7 Hz, 8: 75 Hz, 9: 66.7 Hz, 10: 60 Hz *700 Hz- 1: 700 Hz, 2: 350 Hz, 3: 233.3 Hz, 4: 175 Hz, 5: 140 Hz, 6: 116.7 Hz, 7:100 Hz, 8:87.5 Hz, 9: 77.8 Hz, 10: 70 Hz F. Which subharmonic(s) do the partials have in common? G. How is this related to the fundamental frequency? 2. Common harmonics We will assume that each note consists of a harmonic complex of harmonics 1-12. Let the lower note F0 = 200 Hz. A musical interval of an octave in just tuning is a frequency ratio of 2/1. A musical interval of a fifth in just tuning is a frequency ratio of 3/2. A musical interval of a fourth in just tuning is a frequency ratio of 4/3. A musical interval of a major third in just tuning is a frequency ratio of 5/4. For 200 Hz: Harmonics-1: 200 Hz, 2nd: 400 Hz, 3:600 Hz, 4:800 Hz, 5:1000 Hz, 6:1200 Hz, 7: 1400 Hz, 8:1600 Hz, 9:1800 Hz, 10:2000 Hz, 11: 2200, 12:2400 Subharmonics-1: 200 Hz, 2:100 Hz, 3: 66.7 Hz, 4: 50 Hz, 5: 40 Hz, 6: 33.3 Hz, 7: 28.6 Hz, 8: 25 Hz, 9: 22.2 Hz, 10: 20 Hz, 11: 18.2 Hz, 12: 16.7 Hz A. What is the fundamental frequency of a note an octave above 200 Hz? 2/1*200 Hz=400 Hz (2nd ) harmonic How many harmonics do the two notes share? (harmonics 1-12) 6 (400 Hz, 800 Hz, 1200 Hz, 1600 Hz, 2000 Hz, 2400 Hz) How many subharmonics do the two notes share above 30 Hz? What are they? 4 (200 Hz, 100 Hz, 66.7 Hz, 33.3 Hz) B. What is the fundamental frequency of a note a fifth above 200 Hz? 3/2*200 Hz=300 Hz (3rd harmonic) How many harmonics do the two notes share? For 300 Hz-1: 300 Hz, 2: 600 Hz, 3: 900 Hz, 4:1200 Hz, 5:1500 Hz, 6:1800 Hz, 7:2100 Hz, 8: 2400 Hz, 9: 2700 Hz, 10: 3000 Hz, 11: 3300 Hz, 12: 3600 Hz 4 (600 Hz, 1200 Hz, 1800 Hz, 2400 Hz) How many subharmonics do the two notes share above 30 Hz? What are they? 3 (100 Hz, 50 Hz, 33.3 Hz) C. What is the fundamental frequency of a note a fourth above 200 Hz? 4/3*200 Hz= 266.7 Hz How many harmonics do the two notes share? 3 (800 Hz, 1600 Hz, 2400 Hz) How many subharmonics do the two notes share above 30 Hz? What are they? 2 (66.7 Hz, 33.3 Hz) D. What is the fundamental frequency of a note a major third above 200 Hz? 5/4*200 Hz=250 Hz How many harmonics do the two notes share? 2 (1000 Hz, 2000 Hz) How many subharmonics do the two notes share above 30 Hz? What are they? 1 (50 Hz) E. Do you see any patterns emerging here? Yes, the number of shared harmonics is the total number of harmonics in a note (12) divided by the number in the numerator of the frequency ratio. For example, the shared harmonics for a note a fifth above is 12/(numerator in frequency ratio)=12/3=4. Likewise, the number of subharmonics shared is 5-(number in the denominator of the frequency ratio) as 5 may symbolize halfway point of the octave. total number thirds (the major unit, as it is the smallest harmonic in this example and the harmonic with the lowest number that is consonant, unlike the 2nd)? 3. Tuning systems We have decided to devise a tuning system in which we divide the octave into 12 logarithmically spaced semitones (equally temperament tuning, chromatic scale). There are several ways of doing this. One is to take the twelfth root of 2. The first note in the scale is 1, the second note is 21/12 the third 22/12, the fourth 23/12 and so on up to the octave 212/12= 2. These frequency ratios are multiplied by the frequency of the first note in the scale (the tonic). Frequency ratios can be expressed in cents. There are 1200 cents to the octave. A semitone is 100 cents, a perfect fifth is 800 cents, a tritone is 600 cents. A. If (F0) note A = 440 Hz, what are the frequencies of the other notes in the octave that spans 440 to 880 Hz? What are the frequencies in the octave below it? B. How big is a semitone (one step in the scale) in terms of percent change in frequency? What percent change in frequency is 50 cents? 25 cents? Equations: A=B*2(n/1200 for finer calculations) where A and B are frequencies of two different notes. N=log2 (A/B) approximately equal to N=log10(A/B) where N is the number of cents A semitone is a half step on the scale (100 cents), so the percent change in frequency is . A/B= 21/12= 1.047. 1.047-1=.047 or 4.7%. Alternatively, 100/1200=1/12=.083 or 8.3%. C. In percentage terms, how much does the equally tempered scale differ from just intonation for the fifth (3/2), fourth (4/3)? You can calculate this out or consult the table in Handel, p. 331. If the jnd for fundamental frequency is in the neighborhood of 0.2% under the best of conditions, do you expect this difference to be audible? Where is the greatest discrepancy between intervals based on just intonation and those based on equal temperament? For the fifth, the equally tempered scale has a frequency ratio of 1.498 and corresponds to 700 cents, versus 1.500 and 702 for the just intonation scale. The equally tempered scale has a lower frequency ratio by .002 and is 2 cents less. No, it is not likely audible as the difference is less than a tenth of the just noticeable difference under the best of conditions. The greatest discrepancy between the two scales occur at the dissonant intervals: major second D and minor seventh A for around 20 cents difference or tritone F# and minor seventh A# with a frequency ratio difference of 0.018 each. D. If one were to devise a tuning system that divided the octave into 10 logarithmically equal steps, what would the frequencies be for the octave that spans 440-880 Hz? How far would these notes diverge from those of just-intonation? William Sethares in his book Tuning, Timbre, and Spectrum discusses such a scale and has written musical compositions based on it. The frequencies would be 44 Hz apart so 484, 528… 4. Major aspects of music A. Which aspects of music depend (most directly) on perception of pitch? (Two or more examples) Frequency and period is dependent on the perception of pitch and are hard to measure otherwise. Sound pressure of the tone and spectrum or harmonic spacing are other aspects. Rate and place of stimulation is affected by pitch, as seen in some cochlear implant studies. B. Which aspects of music depend on perception of distinct events? Echoes serve as an aspect that depends on perception of distinct events. Music depends on perception of distinct events when there are dissonant occurrences, like two sources that produce different sounds (vocals and bells) or a violinist who does not sync up to the rest of the orchestra. C. Which aspects of music depend on memory processes (musical contexts, kinds of expectations)? Expectations of timing and rhythm may depend on memory processes. Music associated with traditions (such as the wedding march or military fanfares) or widely used musical pieces (like the religious “Amazing Grace”) can depend on context. For example, the wedding song and “Amazing Grace” are thought to be slower and more calming than the more bright brass notes of the military wake-up trumpet call). 5. Pitch and the limits of musical tonality A. Roughly, what is the range of pure tone frequencies that we can hear? We can hear the frequencies from about 20 to 20,000 Hz. B. What is the range of pitch (f, F0) frequencies for musical tonality (i.e. over which octaves, musical intervals, and melodies can be readily recognized). Most of music occurs within two octaves in the frequency range of 220 to 880 Hz. Components of an orchestra (brass, winds, and strings) produce sounds within this range. The range of vocal perception a bit larger in the 30 to 5000 Hz. C. What would constitute an explanation (neural or psychological) for why these ranges are different? The range of frequencies we can hear and those that are observed in easily recognized melodies are different because we are only able to make meaning of certain patterned sounds, such as those that contain uniform waveforms and expected, ‘musically pleasing’ note and rhythm combinations. We may hear static or alarm noises at lower or higher frequencies but cannot construct a meaningful interpretation. D. Provide a possible (neural or psychological) explanation for why we hear the missing fundamental. The phenomenon that Licklider described for hearing the missing fundamental may be the ability of the higher cognitive functions to perceive pitch by subtracting frequencies of the harmonic (instead of hearing each harmonic separately), resulting in filling in of the missing fundamental (a part of the expected harmonic pattern). Neurologically, some theories point to the ability to infer activity from the patterns of the basilar membrane. E. What does it mean to say that musical pitch is highly invariant with respect to tone intensity, location, and duration? What is metamery? What would be an example of pitch metamery? Musical pitch is not dependent to tone intensity, location, or duration as it is dependent on frequency; a C sharp sounds like a C sharp no matter how intensely it is played on the piano, if it is played an octave higher, or if it is held onto longer. An equation confirms this: I=P/A (amplitude does not affect frequency, only wavelength and speed of sound). 6. Timbres of musical instruments A. What is the main functional role that timbre plays in most western tonal music? Timbre gives music texture in tonal music. It is similar to the onset of homophony and polyphony after the monophony of chants in Western music, which gave more rich texture with more vocal or instrumental parts. B. What is the acoustic dimension that distinguishes timbres of stationary sounds? Stationary sounds do not refer to temporal qualities (timing, such as the envelope qualities of attack time and decay) that distinguish between the different sound textures made by instruments C. What are two factors that distinguish timbres of non-stationary (time-varying) sounds? Spectrum and envelope (coloration, tonal character, vibratos, tremolos, etc) are used to perceive timbre Classes of instruments: 1. pipe organ (vibrating air column), 2. violin (bowed string), 3. piano (struck string), 4. bells (struck, metal), 5. snare drum (struck, membrane) D. Which classes produce harmonic tones? inharmonic tones? Harmonic tones are produced by violins, pianos, and pipe organs. Inharmonic tones can be created by bells and snare drums. E. Which classes can produce a melody? rhythm? Pipe organs, violins and pianos can produce a melody. Bells and snare drums can produce rhythms. Bells may also be able to produce rhythm if there is a series of bells with different pitches (similar to a xylophone). 7. Scales and musical intervals A. What is a scale? A scale is a series of musical notes in ascending or descending order, usually with the same step size between each note. B. What role do scales play in music perception? Scales give a dimension of order in music perception and serve as the basis for how we perceive pitch. For example intervals and perception in differences between harmonics can be better understood if one has heard scales played, especially on a piano. C. What is the tonic? What functional role does the tonic play in perception of melody and harmony? A tonic is the first note in a musical scale. The musical piece is based on the tonic, and the chord including the tonic is also usually prevalent; it can be thought of as the ‘home key.’ Melody and harmony of the piece may change to different keys and produce different moods, and the tonic serves a benchmark for comparison. For example, a symphony may start in C minor and switch to E flat major during the exposition or development and conclude in the tonic key of C minor. D. Why do melodies played in different modes have distinctive qualities, despite their use of the same set of notes? Melodies in different modes have distinctive qualities because the pitch relationships between the notes may be somewhat different. Comparing major and minor modes, F in the major mode includes an F# while that of F minor includes the white key. The medieval modes also exemplify this; the fourth interval is augmented in Lydian mode while it is perfect in the other modes, the Locrian fifth is diminished while the others are perfect, and there is a mix of major and minor intervals (except for the prime and octave) in the different modes. 8. Consonance A. What defines a musical interval? Does an interval depend on the absolute (F0) frequency of its root? A musical interval is defined by the space (number of half steps) between one note and the other note or notes. An interval does not depend on the absolute frequency of the root. B. "Consonance" is associated with 1) euphony and tonal preference on one hand and 2) stability/instability and tension/resolution on the other. Dependence of consonance on musical context notwithstanding, which isolated intervals (octaves, seconds, fourths, fifths, sevenths) are perceived as more consonant or dissident? Octaves, thirds, fourths, and fifths are interpreted as more consonant, while seconds and sevents are interpreted as more dissonant. C. Two rival theories of consonance were proposed by Helmholtz and Stumpf in the 19th century. What perceptual aspect of tone combinations does each rely on? Helmholtz proposed that the more mismatched the harmonic (the more beats between the notes), the more dissonant the sound, which explains why whole whole tones
