Packet Tracer - Router and Switch Resilience

Packet Tracer - Router and Switch Resilience Addressing Table Device IP Address Subnet Mask Default Gateway Site HQ_Router 10.44.1.1 255.255.255.0 N/A Metropolis Bank HQ Objectives Part 1: Hardening the IOS Configuration Part 2: Activating the Cisco IOS Resilient Configuration Feature Background In this activity, you will harden the IOS configuration of a router within the Metropolis network. Afterwards, you will enable the IOS resiliency feature on a Cisco router. The IP addressing, network configuration, and service configurations are already complete. You will use the client devices in the Metropolis network to deploy the IOS resiliency configuration. Part 1: Hardening the IOS configuration Step 1: Access the command prompt on Sally’s computer. a. Click the Metropolis Bank HQ site and then click the computer Sally. b. Click the Desktop tab and then click Command Prompt. Step 2: Remotely connect to the router HQ_Router. a. SSH to the HQ_Router by entering ssh –l admin 10.44.1.1 in the command prompt. Use the password of cisco12345 when prompted. b. At the prompt, type enable and enter the enable password class when prompted. Your prompt should display: HQ_Router# c. Were you prompted with any warning message preventing unauthorized users from accessing the HQ_Router? Step 3: Create a legal notification message on the HQ_Router. a. At the HQ_Router# prompt, enter global configuration mode using the configure terminal command. b. At the HQ_Router(config)# prompt, paste in the following commands: banner motd # UNAUTHORIZED ACCESS TO THIS DEVICE IS PROHIBITED You must have explicit, authorized permission to access or configure this device. Unauthorized attempts and actions to access or use this system may result in civil and/or Packet Tracer - Router and Switch Resilience criminal penalties. All activities performed on this device are logged and monitored. # c. At the HQ_Router(config)# prompt use the end and logout command to end your connection to HQ_Router. d. SSH into the HQ_Router again from the computer Sally. The SSH password is cisco12345. Were you prompted with any additional text/information when you connected successfully to the HQ_Router? What is shown? Step 4: Enforce password security on the HQ_Router. a. At the prompt, type enable and enter the enable password class when prompted. b. Enter global configuration mode using the configure terminal command. At the HQ_Router(config)# prompt, paste in the following commands: !encrypts plain-text passwords in the running-config service password-encryption !enforces any new configured passwords to have a minimum of 10 characters security passwords min-length 10 Part 2: Activating the Cisco IOS Resilient Configuration Feature Step 1: View the current IOS image. a. While connected via SSH from Sally’s computer, enter the exit command to return to the HQ_Router# prompt. b. Enter the command dir flash: to view the current IOS.bin file. What is the name of the current .bin file in flash? Step 2: Secure the running image and configuration. a. At the HQ_Router# prompt, enter global configuration mode using the configure terminal command. b. Use the secure boot-image command within the HQ_Router(config)# prompt to activate IOS image resilience and prevent the IOS file from both showing in the directory output and prevents the deletion of the secured IOS file. c. Use the secure boot-config command within the HQ_Router(config)# prompt to store a secure copy of the running configuration and prevent deletion of the secured configuration file. d. Return to privileged EXEC mode by entering the exit command. Now enter the command dir flash: to view the current IOS.bin file. Are there any IOS.bin file listed? e. At the HQ_Router# prompt, enter the command show secure bootset to view the status of the Cisco IOS image and configuration resilience. Packet Tracer - Router and Switch Resilience Suggested Scoring Rubric Question Location Possible Points Part 1: Harden the IOS configuration Step 2 10 Step 3 10 Part 2: Activate the Cisco IOS resilient configuration feature Step 1 10 Step 2 10 Questions 40 Activity Section Packet Tracer Score 60 Total Score 100 Earned Points
