Quiz on MPLS Networking

Introduction to MPLS Networking Answers Quiz 1. What is one of the key advantages of using MPLS over traditional IP routing? A. MPLS does not support multiple protocols. B. MPLS uses IP addresses for routing decisions. C. MPLS simplifies complex routing requirements and improves network performance. D. MPLS is less scalable than traditional IP routing. Answer: MPLS simplifies complex routing requirements and improves network performance. (C) MPLS uses labels for routing, which streamlines the routing process compared to the slower IP address-based traditional routing. 2. Which limitation of MPLS is associated with maintaining label maps across the network? A. Vendor dependence. B. Incompatibility with traditional protocols. C. Complexity. D. Reduced performance. Answer: Complexity. (C) Maintaining label maps can be complex due to the specialized knowledge required for MPLS. 3. How does RSVP-TE differ from LDP in terms of functionality? A. RSVP-TE does not support multiple protocols. B. RSVP-TE is primarily concerned with label exchange. C. RSVP-TE is simpler and easier to implement. D. RSVP-TE provides advanced functionalities like traffic engineering. Answer: RSVP-TE provides advanced functionalities like traffic engineering. (D) RSVP-TE's capabilities for traffic engineering are crucial for optimizing traffic flows, distinguishing it from LDP. 4. What future trend is MPLS evolving towards? A. Dependency solely on specific vendors. B. Integration into traditional circuit-switched networks. C. Integration into software-defined networking frameworks. D. Complete elimination in favor of IP routing. Answer: Integration into software-defined networking frameworks. (C) Integrating MPLS into SDN frameworks allows for greater control and programmability in network management. 5. What is a notable characteristic of MPLS regarding its support for various protocols? A. It is limited to IP-based protocols only. B. It operates independently of network size. C. It requires separate networks for different protocols. D. It can support multiple protocols over a single, centralized network. Answer: It can support multiple protocols over a single, centralized network. (D) MPLS's design allows it to serve multiple protocols efficiently within a centralized framework. 6. What is the primary advantage of using short labels in MPLS over long IP addresses? A. Faster forwarding process B. Reduction in network scalability C. Increased complexity in routing tables D. Slower packet forwarding Answer: Faster forwarding process (A) Using short labels allows for a quicker identification of the next hop for data packets, significantly speeding up the forwarding process. 7. Which component of MPLS is responsible for forwarding packets based on the label? A. Label Edge Routers (LERs) B. Label Switching Routers (LSRs) C. Label Distribution Protocol (LDP) D. Label Switched Path (LSP) Answer: Label Switching Routers (LSRs) (B) Label Switching Routers (LSRs) are core network routers that forward packets based on the labels assigned to them. 8. What role does the Label Distribution Protocol (LDP) serve in MPLS? A. Routing based on IP addresses B. Establishing and maintaining data traffic flow C. Encrypting data packets for security D. Maintaining label mappings between routers Answer: Maintaining label mappings between routers (D) LDP is responsible for establishing and maintaining label mappings between routers in an MPLS network. 9. In MPLS, what is a Label Switched Path (LSP)? A. A type of encryption for secure data B. A predetermined route established for data packets C. A protocol for distributing IP addresses D. A physical connection between routers Answer: A predetermined route established for data packets (B) A Label Switched Path (LSP) is a predetermined path that is established and maintained for communication between two nodes. 10. What is one of the security benefits provided by MPLS? A. Enhanced IP routing B. Public network exposure C. Increased data visibility D. Virtual Private Networks (VPNs) Answer: Virtual Private Networks (VPNs) (D) MPLS enhances security through the creation of Virtual Private Networks (VPNs) that provide secure communication channels. 11. Which of the following is NOT a benefit of MPLS? A. Increased network flexibility B. Improved network performance C. Simplified data complexity D. Reduced data traffic handling Answer: Reduced data traffic handling (D) MPLS handles large amounts of data traffic with reduced complexity, rather than reducing the capacity for handling data. 12. What does a Label Stack in MPLS enable? A. Complex routing requirements through stacking multiple labels B. Single label usage for all packet types C. Streamlining data flow in a linear way D. No need for label switching Answer: Complex routing requirements through stacking multiple labels (A) A Label Stack allows for multiple labels to be stacked on top of one another, enabling complex routing needs. 13. Which protocol provides traffic engineering functions in an MPLS environment? A. IGRP (Interior Gateway Routing Protocol) B. LDP (Label Distribution Protocol) C. OSPF (Open Shortest Path First) D. RSVP-TE (Resource Reservation Protocol – Traffic Engineering) Answer: RSVP-TE (Resource Reservation Protocol – Traffic Engineering) (D) RSVP-TE is designed specifically to enable traffic engineering functions within MPLS networks.
