Unit II Project Life Cycle and Effor Testimation

UNIT II PROJECT LIFE CYCLE AND EFFORT ESTIMATION Software process and Process Models – Choice of Process models - mental delivery – Rapid Application development – Agile methods – Extreme Programming – SCRUM – Managing interactive processes – Basics of Software estimation – Effort and Cost estimation techniques – COSMIC Full function points - COCOMO II A Parametric Productivity Model - Staffing Pattern. ------------------------------------------------------------------------------------------------------------------------------16 MARKS QUESTIONS 1. Explain the Extreme Programming and its advantages and disadvantages in detail. 2. Explain the component of staffing and staffing level estimation 3. Explain how project can be evaluated against strategic, technical and economic criteria. 4. Explain in detail about the Amanda’s decision tree.(Refer Class notes) 5. Explain the “Internal rate of return” method. Also mention its advantages over the NPV method. 6. Where are estimates done and explain the problems with over and under estimates. 7. Explain COCOMO – II model 8. What is incremental delivery? Explain the advantages and disadvantages of the incremental delivery? Explain the incremental delivery plan 9. Explain the Rapid Application Development in detail. 10. Discuss the spiral software development life cycle model with diagrammatic illustration. What are spiral model strengths ? What are the spiral model deficiencies ? When to use spiral model ? Discuss. 11. Components of function point analysis ----------------------------------------------------------------------------------- 1.Structure versus speed of delivery Structured approach Also called „heavyweight‟ approaches Step-by-step methods where each step and intermediate product is carefully defined Emphasis on getting quality right first time Example: use of UML and USDP Future vision: Model-Driven Architecture (MDA). UML supplemented with Object Constraint Language, press the button and application code generated from the UML/OCL model Agile methods Emphasis on speed of delivery rather than documentation RAD Rapid application development emphasized use of quickly developed prototypes JAD Joint application development. Requirements are identified and agreed in intensive workshops with users 2.Choice of process models The word 'process‟ is sometimes used to emphasize the idea of a system in action. In order to achieve an outcome, the system will have to execute one or moe activities: this is its process. This idea can be applied to the development of computer-based systems whee a number of interelated activities have to be undertaken to ceate a final poduct. A major pat of the planning will be the choosing of the development methods to be used and the slotting of these into an overall process model. The planner needs not only to select methods but also to specify how the method is to be applied. With methods such as SSADM. there is a considerable degree of choice about how it is to be applied: not all pats of SSADM are compulsory. SSADM is to be used: in the event, all that is produced as a few SSADM fragments such as a top level data low diagram and a preliminary logical data structue diagram. If this is all the paticular poject equies, it should be stated at the outset. 3.Software process model A software process model is a standardised format for • planning • organising, and • running a development project. Definition. A (software/system) process model is a description of the sequence of activities carried out in an SE project, and the relative order of these activities. It provides a fixed generic framework that can be tailored to a specific project. Project specific parameters will include: • Size, (person-years) • Budget, • Duration. There are hundreds of different process models to choose from, e.g: • waterfall, • code-and-fix • spiral • rapid prototyping • unified process (UP) • agile methods, extreme programming (XP) • COTS … But most are minor variations on a small number of basic models. By changing the process model, we can improve and/or tradeoff: • Development speed (time to market) • Product quality • Project visibility • Administrative overhead • Risk exposure • Customer relations, etc, etc. We can sometimes combine process models e.g. 1. waterfall inside evolutionary – onboard shuttle software 2. Evolutionary inside waterfall – e.g. GUI Prototyping The Waterfall Model The waterfall model is the classic process model – it is widely known, understood and used. • In some respect, waterfall is the ”common sense” approach. the „classical‟ model imposes structure on the project every stage needs to be checked and signed off. BUT limited scope for iteration V model approach is an extension of waterfall where different testing phases are identified which check the quality of different development phases Advantages 1. Easy to understand and implement. 2. Widely used and known (in theory!) 3. Fits other engineering process models: civil, mech etc. 4. Reinforces good habits: define-before- design, designbefore-code 5. Identifies deliverables and milestones Disadvantages 1. Doesn‟t reflect iterative nature of exploratory development. 2. Sometimes unrealistic to expect accurate requirements early in a project 3. Software is delivered late, delays discovery of serious errors. 4. No inherent risk management 4. Incremental Model Incremental delivery This is similar to the 'incremental prototyping' appoach mentioned above. The approach involves beaking the system down into small components which are then implemented and deliveed in sequence. Advantages of this approach These ac some of the justifications given for the approach: • the feedback fom early increments can inluence the later stages; • the possibility of changes in requirements is not so great as with large monolithic projects because of the shorter timespan between the design of a component and its delivery; • users get beneits earlier than with a conventional approach; • early delivery of some useful components improves cash low, because you get some retun on investment early on; • smaller sub-pojects ac easier to contol and manage; • 'gold-plating', the requesting of features that ae unnecessary and not in fact used, should be less as users vv ill know that they get moe than one oppotunity to make their requiements known: if a feature is not in the curent incement then it can be included in the next; • the project can be temporaily abandoned if more urgent work crops up; • job satisfaction is inceased for developers who see their labours beaing fruit at regular, short, intervals. Disadvantages On the other hand these disadvantages have been put forward: • 'softwae breakage‟, that is, later incements might requie the earlier incements to be modified; • developers might be moe poductive working on one large system than on a seies of smaller ones. The incremental delivery plan The content of each increment and the order in which the increments ac to be delivered to the users of the system have to be planned at the outset. Basically the same process has to be undetaken as in strategic planning but at a more detailed level where the attention is given to incements of a user application rather than whole applications. The elements of the inctemeni.il plan ae the system objectives, incremental plan and the open technology plan. Identify system objectives The purpose is to give an idea of the 'big pictue*, that is, the overall objectives that the system is to achieve. These can then expanded into more speciic functional goals and quality goals.  Functional goals will include  objectives it is intended to achieve  jobs the system is to do  computer/non-computer functions to achieve them. Plan increments Having defined the overall objectives, the next stage is to plan the incements using the following guidelines: • steps typically should consist of 1 to 5% of the total poject: • non-computer steps may be included - but these must deliver beneits directly to the users; • ideally, an incement should take one month or less and should never take moe than three months; • each increment should deliver some benefit to the user; • some incements will be physically dependent on others; • valuc-to-cost ratios may be used to decide piorities. Create open technology plan If the system is to be able to cope with new components being continually added then it has to be built so that it is extendible. portable and maintainable. As a minimum this will equire the use of: • a standard high level language; • a standard operating system; • small modules; • variable parameters, for example. Here such as organization name, department names and charge rates ae held in a parameter ile that can be amended without programmer intervention; • a standard database management system. These are all things that might be expected as a matter of course in a modern IS development envionment. 5. Evolutionary Development Types Type 1: Exploratory Development: customer assisted development that evolves a product from ignorance to insight, starting from core, well understood components (e.g. GUI?). Spiral model Type 1: Spiral Model Extends waterfall model by adding iteration to explore /manage risk Project risk is a moving target. Natural to progress a project cyclically in four step phases 1. Consider alternative scenarios, constraints 2. Identify and resolve risks 3. Execute the phase 4. Plan next phase: e.g. user req, software req, architecture … then goto 1 Advantages 1. Realism: the model accurately reflects the iterative nature of software development on projects with unclear requirements 2. Flexible: incoporates the advantages of the waterfall and evolutionary methods 3. Comprehensive model decreases risk 4. Good project visibility Disadvantages 1. Needs technical expertise in risk analysis and risk management to work well. 2. Model is poorly understood by nontechnical management, hence not so widely used 3. Complicated model, needs competent professional management. High administrative overhead. Type 2: Throwaway Prototyping: customer assisted development that evolves requirements from ignorance to insight by means of lightweight disposable prototypes. 6.RAD : Rapid Application Development The RAD RapidApplicationDevelopment model is based on prototyping and iterative development with no specific planning involved. The process of writing the software itself involves the planning required for developing the product. Rapid Application development focuses on gathering customer requirements through workshops or focus groups, early testing of the prototypes by the customer using iterative concept, reuse of the existing prototypes components, continuous integration and rapid delivery. What is RAD? Rapid application development RAD is a software development methodology that uses minimal planning in favor of rapid prototyping. A prototype is a working model that is functionally equivalent to a component of the product. In RAD model the functional modules are developed in parallel as prototypes and are integrated to make the complete product for faster product delivery. Since there is no detailed preplanning, it makes it easier to incorporate the changes within the development process. RAD projects follow iterative and incremental model and have small teams comprising of developers, domain experts, customer representatives and other IT resources working progressively on their component or prototype. The most important aspect for this model to be successful is to make sure that the prototypes developed are reusable. F RAD Model Design RAD model distributes the analysis, design, build, and test phases into a series of short, iterative development cycles. Following are the phases of RAD Model: Business Modeling: The business model for the product under development is designed in terms of flow of information and the distribution of information between various business channels. A complete business analysis is performed to find the vital information for business, how it can be obtained, how and when is the information processed and what are the factors driving successful flow of information. Data Modeling: The information gathered in the Business Modeling phase is reviewed and analyzed to form sets of data objects vital for the business. The attributes of all data sets is identified and defined. The relation between these data objects are established and defined in detail in relevance to the business model. Process Modeling: The data object sets defined in the Data Modeling phase are converted to establish the business information flow needed to achieve specific business objectives as per the business model. The process model for any changes or enhancements to the data object sets is defined in this phase. Process descriptions for adding ,deleting, retrieving or modifying a data object are given. Application Generation: The actual system is built and coding is done by using automation tools to convert process and data models into actual prototypes. Testing and Turnover:The overall testing time is reduced in RAD model as the prototypes are independently tested during every iteration. However the data flow and the interfaces between all the components need to be thoroughly tested with complete test coverage. Since most of the programming components have already been tested, it reduces the risk of any major issues. RAD Model Application RAD model can be applied successfully to the projects in which clear modularization is possible. If the project cannot be broken into modules, RAD may fail. Following are the typical scenarios where RAD can be used:       RAD should be used only when a system can be modularized to be delivered in incremental manner. It should be used if there.s high availability of designers for modeling. It should be used only if the budget permits use of automated code generating tools. RAD SDLC model should be chosen only if domain experts are available with relevant business knowledge. Should be used where the requirements change during the course of the project and working prototypes are to be presented to customer in small iterations of 2-3 months. Advantages 1. Reduces risk of incorrect user requirements 2. Good where requirements are changing/ uncommitted 3. Regular visible progress aids management 4. Supports early product marketing Disadvantages 1. An unstable/badly implemented prototype often becomes the final product. 2. Requires extensive customer collaboration – Costs customers time/money – Needs committed customers – Difficult to finish if customer withdraws – May be too customer specific 12. Agile Software Processes Need for an adaptive process model suited to changes in: • User requirements • Customer business models • Technology • In-house environment De-emphasise documentation, esp. URD! Emphasise change management e.g. reverse engineering design Examples include XP, Scrum, Agile modeling etc Agile Principles • Incremental delivery of software • Continuous collaboration with customer • Embrace change • Value participants and their interaction • Simplicity in code, Agile methods 13. “eXtreme Programming” - XP eXtreme Programming (XP) is a software development process as well as a methodology. XP is also a process framework because it can be (and most likely will be) tailored to the specific needs of teams, projects, companies etc. XP is also a lightweight methodology or what Alistair Cockburn calls a “Crystal Methodology”. In short, methodologies of this family have high productivity and high tolerance. Communication is usually strong with short paths, especially informal (not documented). There the is only a small range of deliverables (artifacts), but these are delivered frequently (releases). Processes of the Crystal family identify only a few roles and activities. To date, XP has been applied to business problems only, e.g. projects with a external customer that wants a specific product. The projects usually ranged from 6 to 15 months. XP was used by small teams ranging from two to twelve members (and it is likely to be limited to teams of this size). The four values XP defines four “values” which are used as guidelines throughout development. These are Communication Good communication is one of the key factors necessary for the success of software projects. Customers need to communicate the requirements to the developers. Developers communicate ideas and design to each other and so on. Simplicity XP strives for simple systems. This means, they should be as simple as possible but they must work. XP also strives for simplicity in the methodology. It reduces the amount of artifacts to an absolute minimum – the requirements (User Stories), plans (Planning Game) and the product (code). The practices and techniques can be learned in a matter of hours (although mastering them of course takes more time). The main reason for the desire for simplicity is that XP tries to cope with changes and other risks. Feedback XP is a feedback-driven process. You need feedback at all scales, whether you are a customer, manager or developer. While coding you gets immediate feedback from whitebox testing (Unit Tests). The customer defines blackbox tests (Functional Tests) and the team delivers releases frequently. From these practices, both the customers and the developers get feedback about the status of the system. Courage This is a somewhat vague value. It includes courage as well as a certain amount of aggressiveness. Courage is needed because a lot of the rules and practices are “extreme” in the way that they go against “tradition” or “wisdom” of software engineering. Process: Roles and Responsibilities Practices: Advantages 1. Lightweight methods suit small-medium size projects 2. Produces good team cohesion 3. Emphasises final product 4. Iterative 5. Test-based approach to requirements and quality assurance Limitations of extreme programming Reliance on availability of high quality developers Dependence on personal knowledge – after development knowledge of software may decay making future. development less easy. Rationale for decisions may be lost e.g. which test case checks a particular requirement Reuse of existing code less likely 14. Scrum Process: Roles and Responsibilities 15. Managing iterative processes Grady Booch’s concern Booch, an OO authority, is concerned that with requirements driven projects: ‘Conceptual integrity sometimes suffers because this is little motivation to deal with scalability, extensibility, portability, or reusability beyond what any vague requirement might imply’ Tendency towards a large number of discrete functions with little common infrastructure? Macro and Micro processes Macro process-related to water fall model. Within macro process there will be micro activities . System testing done here. Micro process. It is possible for agile projects using XP practices to exist within a more traditional stage –gate project environment. The basis for software estimating The need for historical data Nearly all estimating methods need information about how projects have been implemented in the past. However, care needs to be taken in judging the applicability of data to the estimator's own circumstances because of possible difeences in envionmental factors such as the pogramming languages used, the softwae tools available, the standards enforced and the expeience of the staf. Measure of work It is normally not possible to calculate directly the actual cost or time equired to implement a project. The time taken to wite a pogram might vary according to the competence or experience of the pogrammer. Implementation times might also vary because of envionmental factors such as the softwae tools available. The usual practice is therefoe to express the work content of the system to be implemented independently of effort, using a measue such as source lines of code (SLOC). The eader might also come across the abbreviation KLOC which refers to thousands of lines of code. Complexity Two pograms with the same KLOC will not necessaily take the same time to wite, even if done by the same developer in the same environment. One pogram might be more complex. Because of this. SLOC estimates have to be modified to take complexity into account. Attempts have been made to objective measures of complexity, but often it will depend on the subjective judgement of the estimator. 11.Software Effort Estimation Techniques Barry Boehm. in his classic work on softwae effort models, identiied the main ways of deiving estimates of software development effort as: • algorithmic models - which use 'effort drivers' repesenting characteistics of the target system and the implementation environment to predict effort. • expert judgement - where the advice of knowledgeable staff is solicited. • analogy - whee a similar, completed, project is identified and its actual effort is used as a basis for the new poject. • Parkinson - which identiies the staf effort available to do a poject and uses that as the 'estimate'. • pice to win - where the 'estimate' is a figure that appears to be suficiently low to win a contract. • top-down - where an overall estimate is formulated for the whole poject and is then boken down into the effort requied for component tasks. • bottom-up - where component tasks ae identified and sized and these individual estimates ae aggegated. Clearly, the 'Parkinson' method is not really an effort prediction method, but a method of setting the scope of a project. Similarly, 'price to win' is a way of deciding a pice and not a prediction method. 1.Bottom-up estimating 1. Break project into smaller and smaller components [Stop when you get to what one person can do in one/two weeks] 2. Estimate costs for the lowest level activities 3. At each higher level calculate estimate by adding estimates for lower levels Estimating methods can be generally divided into bottom-up and topdown approaches. With the bottom-up approach, the estimator beaks the poject into its component tasks and then estimates how much effort will be requied to carry out each task. The bottom-up part comes in adding up the calculated effort for each activity to get an overall estimate. The bottom-up appoach is most appropiate at the later, moe detailed, stages ofpoject planning. If this method is used early on in the poject cycle then the estimator will have to make some assumptions about the characteistics of the final svstem, for example the number and size of softwae modules. These will be working assumptions that imply no commitment when it comes to the design of the system. Where a project is completely novel or there is no historical data available, the estimator would be well advised to use the bottom-up approach. 2.The top-down approach and parametric models The top-down approach is normally associated with parametic (or algoithmic) models. These may be explained using the analogy of estimating the cost of rebuilding a house. This would be of practical concern to a house-owner who needs sufficient insurance cover to allow for rebuilding the property if it were destoyed. This is a simple parametic model. f The effort needed to implement a project will be elated mainly to vaiables associated with characteistics of the final system. The form of the parametic model w ill normally be one or moe formulae in the form: effort - (system size) x [productivity rate) For example, system size might be in the form 'thousands of lines of code' (KLOC) and the productivity rate 40 days per KLOC. The values to be used will often be matters of subjective judgement. The top-down and bottom-up approaches ae not mutually exclusive. Project managers will probably try to get a number of different estimates fom difeent people using difeent methods. Some pats of an overall estimate could be derived using a top-dow n approach while other parts could be calculated using a bottomup method. Bottom-up versus top-down • Bottom-up – use when no past project data – identify all tasks that have to be done – so quite time-consuming – use when you have no data about similar past projects • Top-down – produce overall estimate based on project cost drivers – based on past project data – divide overall estimate between jobs to be done 3.Expert judgement This is asking someone who is knowledgeable about cither the application area or the development envionment to give an estimate of the effort needed to carry out a task. This method will most likely be used when estimating the effort needed to change an existing piece of software. The estimator would have to carry out some kind of impact analysis in order to judge the popotion of code that would be afected and fom that deive an estimate. Someone aleady familiar with the software would be in the best position to do this. 4.Estimating by analogy The use of analogy is also called case-based reasoning. The estimator seeks out projects that have been completed (source cases) and that have similar characteristics to the new poject (the target case). The effort that has been recorded for the matching source case can then be used as a base estimate for the target. The estimator should then try to identify any difeences between the target and the source and make adjustments to the base estimate for the new project. A problem here is how you actually identify the similaities and difeences between the diferent systems. Attempts have been made to automate this process. One softwae application that has been developed lo do this is ANGEL. This identifies the souce case that is nearest the target by measuring the Euclidean distance between cases. The source case that is at the shotest Euclidean distance from the target is deemed to be the closest match. The Euclidean distance is calculated: distance = square-root of ((target_parameter1 - source_ 2 2 parameter1) + (target_parametern - source_ parametern) ) The new project is known to requie 7 inputs and 15 outputs. One of the past cases. Project A. has 8 inputs and 17 outputs. The Euclidean distance between the souce 2 2 and the target is therefoe the squae-root of ((7-8) +(l7-l5) ). that is 2.24. Find a similar project:  Type of business  Size of applications  Scope of systems Technical methods and standards.  Must adjust for:  Organizational culture  Users‟ level of computer literacy  Degree of management support for project. 5. Algorithmic/Parametric models ---- Function Point • focus on task or system size • Based on analysis of inputs, outputs and files accessed in system • Starts with unadjusted function points • Then adjusts for: - technical complexity - performance-influencing factors - risks. 6. Algorithmic/Parametric models ---Function Point Mark II 7. Algorithmic/Parametric models ---- COCOMO • Formulae based on thousands of delivered source instructions (KDSI) • Basic, intermediate and detailed versions • • • • • Based on industry productivity standards - database is constantly updated Allows an organization to benchmark its software development productivity Basic model effort = c x sizek C and k depend on the type of system: organic, semi-detached, embedded Size is measured in „kloc‟ ie. Thousands of lines of code 8. Algorithmic/Parametric models ---- COCOMO II • Estimates produced at different stages: – Application composition – based on design from user perspective – Early design – based on top-level design • • – Post architecture – once detailed design in place and construction has started. Uses different methods at different stages. Takes account of innovation, flexibility of approach, fixed or variable scope etc. Development effort multipliers (dem) Product attributes: required reliability, database size, product complexity Computer attributes: execution time constraints, storage constraints, virtual machine (VM) volatility Personnel attributes: analyst capability, application experience, VM experience, programming language experience Project attributes: modern programming practices, software tools, schedule constraints 9. Delphi technique • Several estimators are given specification of work and asked for estimates. • Summarized anonymously and results circulated to estimators. • Can revise estimates in the light of others‟ ideas. • Method reduces personal disagreements and ego-based issues. 12.COSMIC Full Function points The limitations of traditional FPA were the reason to start the COSMIC initiative in 1998. The Common Software Measurement International Consortium (COSMIC), aimed to develop, test, bring to market and to seek acceptance of a new software sizing method to support estimating and performance measurement (productivity, time‐to‐market and quality). The measurement method must be applicable for estimating the effort for developing and maintaining software in various software domains. Not only business business software (MIS) but also real‐time software (avionics, telecom, process control) and embedded software (mobile phones, consumer electronics) can be measured. The basis for measurement must be found, just as in FPA, in the user requirements the software must fulfil. The result of the measurement must be independent of the development environment and the method used to specify these requirements. Sizes depend only on the user requirements for the ultimately delivered software product. COSMIC Concepts The Functional User Requirements (FUR) are, according to the definition of a functional size measurement method, the basis for measurement. They specify user‟s needs and procedures that the software should fulfil. The FUR are analysed to identify the functional processes. A Functional Process is an elementary component of a set of FUR. It is triggered by one or more events in the world of the user of the software being measured. The process is complete when it has executed all that is required to be done in response to the triggering event. Each functional process consists of a set of subprocesses that are either movements or manipulations of data. Since no‐one knows how to measure data manipulation, and since the aim is to measure „datamovement‐ rich‟ software, the simplifying assumption is made that each functional process consists of a set of data movements. A Data Movement moves one Data Group. A Data Group is a unique cohesive set of data (attributes) specifying an „object of interest‟ (i.e. some thing that is „of interest‟ to the user. Each Data Movement is counted as one CFP (COSMIC function point). COSMIC recognises 4 (types of) Data Movements: • Entry --- moves data from outside into the process • Exit ----- moves data from the process to the outside world • Read --- moves data from persistent storage to the process; • Write ---- moves data from the process to persistent storage. • Is based on fundamental software engineering principles, so „future‐proof‟; • supports realistic scheduling and budgeting; • is objective, simple to learn and easy to use; • supports communication between principal, user and supplier; • increasing complexity is rated; • is applicable in most software domains; • is applicable for complete applications and for components, in any layer; • complies with ISO 14143. 13. COCOMO-II--parametric model Empirical model based on project experience  Well-documented, independent model, Independent of a specific software vendor.  Long history – initially published in 1981 (COCOMO-81) and last in 1999 (COCOMOII)  COCOMO-II takes into account different approaches to software development, reuse, etc.  COCOMO (COnstructive COst MOdel) proposed by Boehm.  Divides software product developments into 3 categories: o Organic o Semidetached o Embedded Organic: Relatively small groups working to develop well-understood applications. Semidetached: Project team consists of a mixture of experienced and inexperienced staff. Embedded: The software is strongly coupled to complex hardware, or real-time systems. Gives only an approximate estimation: Effort = a1 * (KLOC) a2 Tdev = b1 * (Effort) b2  KLOC is the estimated kilo lines of source code,  a1,a2,b1,b2 are constants for different categories of software products,  Tdev is the estimated time to develop the software in months,  Effort estimation is obtained in terms of person months (PMs). Development Effort Estimation Organic : Effort = 2.4 (KLOC)1.05 PM Semi-detached: Effort = 3.0(KLOC)1.12 PM Embedded: Effort = 3.6 (KLOC)1.20 PM Development Time Estimation Organic: Tdev = 2.5 (Effort)0.38 Months Semi-detached: Tdev = 2.5 (Effort)0.35 Months Embedded: Tdev = 2.5 (Effort)0.32 Months Effort is somewhat super-linear in problem size. Three-level model that allows increasingly detailed estimates to be prepared as development progresses Early prototyping level  Based on “object points”  Simple formula Early design level  Based on “function points” that are then translated to lines of source code (LOC) Post-architecture level  Estimates based on LOC 1. Early Prototyping Level  Supports prototyping projects and projects where there is extensive reuse  Estimates effort in object points/staff month PM = ( NOP × (1 - %reuse/100 ) ) / PROD,  where:  PM is the effort in person-months  NOP is the number of object points  PROD is the productivity 2. Early Design Level  Estimates made after requirements confirmed PM = A × SizeB × M + πEMi  where:  A = 2.5 in initial calibration  Size in KLOC  B varies from 1.1 to 1.24 depending on novelty of project, development flexibility, risk management approaches, and process maturity  EM = (ASLOC × (AT / 100) ) / ATPROD  M = PERS × RCPX × RUSE × PDIF × PREX × FCIL × SCED Multipliers Multipliers reflect capability of developers, nonfunctional requirements, familiarity with development platform, etc. RCPX - product reliability and complexity RUSE - the reuse required PDIF - platform difficulty PREX - personnel experience PERS - personnel capability SCED - required schedule FCIL - the team support facilities 3.      Post-Architecture Level Uses same formula as early design estimates Estimate of size adjusted to account for: Requirements volatility Rework required to support change Extent of possible reuse ESLOC = ASLOC x (AA + SU +0.4DM + 0.3CM + 0.3IM) / 100        ESLOC is equivalent number of lines of new code ASLOC is the adjusted number of lines of reusable code which must be modified DM is the % of design modified CM is the % of the code that is modified IM is the % of the original integration effort required for integrating the reused software SU is a factor based on the cost of software understanding AA is a factor which reflects the initial assessment costs of deciding if software may be reused Exponent Scale Factors Project Cost Drivers 14. Staffing pattern -Staffing Level Estimation Norden’s work  After the effort required to complete a software project has been estimated, the staffing requirement for the project can be determined.  Norden’s work suggested that starting of R and D project, the activities of the project are planned and investigations are made. At this time the man power requirements are low. As the project progress man power requirements increases until it reach peak. Number of personnel required during any development project: not constant. Norden in 1958 analyzed many R&D projects, and observed: Rayleigh curve represents the number of full-time personnel required at any time. Rayleigh curve is specified by two parameters:  td the time at which the curve reaches its maximum  K the total area under the curve. L=f(K, td) Rayleigh Curve  Very small number of engineers are needed at the beginning of a project carry out planning and specification.  As the project progresses: more detailed work is required, number of engineers slowly increases and reaches a peak. Putnam’s Work: In 1976, Putnam studied the problem of staffing of software projects:     observed that the level of effort required in software development efforts has a similar envelope.found that the Rayleigh-Norden curve relates the number of delivered lines of code to effort and development time. After the effort required to complete a software project has been estimated, the staffing requirement for the project can be determined. Putnam suggested that starting from a small number of developers, there should be a staff build up and after a peak size has been achieved, staff reduction is required. Putnam analyzed a large number of army projects, and derived the expression: L=CkK1/3td4/3     K is the effort expended and L is the size in KLOC. td is the time to develop the software. Ck is the state of technology constant reflects factors that affect programmer productivity. Putnam observed that:  the time at which the Rayleigh curve reaches its maximum value corresponds to system testing and product release.  After system testing, the number of project staff falls till product installation and delivery.  From the Rayleigh curve observe that: approximately 40% of the area under the Rayleigh curve is to the left of td and 60% to the right.  Putnam model indicates extreme penalty for schedule compression and extreme reward for expanding the schedule.  Putnam estimation model works reasonably well for very large systems, but seriously overestimates the effort for medium and small systems. Solved problems
